File Detail parts/6134.dat

Official File parts/6134.dat

Part Attributes:

External Sites:

View on Rebrickable View on BrickLink View on Brickset View on BrickOwl

File Header:

0 Hinge  2 x  2 Top
0 Name: 6134.dat
0 Author: Chris Böhnke [KnightOfTarenta]
0 !LDRAW_ORG Part UPDATE 2025-04
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 1997-09-29 [PTadmin] Official Update 1997-15
0 !HISTORY 2004-11-16 [guyvivan] Made BFC Compliant
0 !HISTORY 2005-12-28 [PTadmin] Official Update 2005-01
0 !HISTORY 2007-07-16 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2024-11-11 [KnightOfTarenta] Complete rewrite
0 !HISTORY 2024-11-11 [KnightOfTarenta] Original file by Lutz Uhlmann [El-Lutzo]
0 !HISTORY 2025-04-27 [OrionP] Official Update 2025-04

Show contents

0 // Top Plate
1 16 0 1 10 20 0 0 0 1 0 0 0 20 box.dat
1 16 10 0 0 1 0 0 0 1 0 0 0 1 stud2.dat
1 16 -10 0 0 1 0 0 0 1 0 0 0 1 stud2.dat
1 16 10 0 20 1 0 0 0 1 0 0 0 1 stud2.dat
1 16 -10 0 20 1 0 0 0 1 0 0 0 1 stud2.dat

0 // Center
1 16 0 2 0 2 0 0 0 2 0 0 0 -2 box3u2p.dat
1 16 2 10 0 0 1 0 0 0 6 6 0 0 2-4disc.dat
1 16 4 10 0 0 -2 0 0 0 6 6 0 0 2-4cylc.dat
1 16 3 6 -6 1 0 0 0 0 -4 0 1 0 rect3.dat
1 16 3 6 6 1 0 0 0 0 -4 0 -1 0 rect3.dat
3 16 4 4 2 4 4 -2 4 10 0
3 16 4 10 -6 4 10 0 4 4 -2
4 16 4 2 -2 4 2 -6 4 10 -6 4 4 -2
3 16 4 10 0 4 10 6 4 4 2
4 16 4 10 6 4 2 6 4 2 2 4 4 2
3 16 2 4 -2 2 4 2 2 10 0
3 16 2 10 0 2 10 -6 2 4 -2
4 16 2 10 -6 2 2 -6 2 2 -2 2 4 -2
3 16 2 10 6 2 10 0 2 4 2
4 16 2 2 2 2 2 6 2 10 6 2 4 2
1 16 -2 10 0 0 -1 0 0 0 6 6 0 0 2-4disc.dat
1 16 -4 10 0 0 2 0 0 0 6 6 0 0 2-4cylc.dat
1 16 -3 6 -6 -1 0 0 0 0 -4 0 1 0 rect3.dat
1 16 -3 6 6 -1 0 0 0 0 -4 0 -1 0 rect3.dat
3 16 -4 4 -2 -4 4 2 -4 10 0
3 16 -4 10 0 -4 10 -6 -4 4 -2
4 16 -4 10 -6 -4 2 -6 -4 2 -2 -4 4 -2
3 16 -4 10 6 -4 10 0 -4 4 2
4 16 -4 2 2 -4 2 6 -4 10 6 -4 4 2
3 16 -2 4 2 -2 4 -2 -2 10 0
3 16 -2 10 -6 -2 10 0 -2 4 -2
4 16 -2 2 -2 -2 2 -6 -2 10 -6 -2 4 -2
3 16 -2 10 0 -2 10 6 -2 4 2
4 16 -2 10 6 -2 2 6 -2 2 2 -2 4 2

0 // Right Side
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\3938s01.dat
1 16 10 9.75 0 0 0 -4 0 5.75 0 -2 0 0 box2-5.dat
1 16 5 2 0 1 0 0 0 2 0 0 0 2 box3u5p.dat
3 16 6 4 2 6 2 2 14 2 2
4 16 6 4 2 14 2 2 14 15.5 2 6 15.5 2
2 24 6 2 2 14 2 2
3 16 6 2 -2 6 4 -2 14 2 -2
4 16 14 15.5 -2 14 2 -2 6 4 -2 6 15.5 -2
2 24 14 2 -2 6 2 -2
2 24 2 2 2 2 2 6
2 24 4 2 6 4 2 2
2 24 4 2 -2 4 2 -6
2 24 2 2 -6 2 2 -2

0 // Left Side
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\3938s01.dat
1 16 -10 9.75 0 0 0 4 0 5.75 0 -2 0 0 box2-5.dat
1 16 -5 2 0 -1 0 0 0 2 0 0 0 2 box3u5p.dat
3 16 -6 2 2 -6 4 2 -14 2 2
4 16 -14 15.5 2 -14 2 2 -6 4 2 -6 15.5 2
2 24 -14 2 2 -6 2 2
3 16 -6 4 -2 -6 2 -2 -14 2 -2
4 16 -6 4 -2 -14 2 -2 -14 15.5 -2 -6 15.5 -2
2 24 -6 2 -2 -14 2 -2
2 24 -2 2 6 -2 2 2
2 24 -4 2 2 -4 2 6
2 24 -4 2 -6 -4 2 -2
2 24 -2 2 -2 -2 2 -6
