File Detail parts/87913.dat

Official File parts/87913.dat

Part Attributes:

External Sites:

View on Rebrickable View on BrickLink View on Brickset View on BrickOwl

File Header:

0 Ladder Holder  2 x  6
0 Name: 87913.dat
0 Author: Magnus Forsberg [MagFors]
0 !LDRAW_ORG Part UPDATE 2023-05
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 !HELP 1 15 -80 0 0 1 0 0 0 1 0 0 0 1 4207a.dat

0 BFC CERTIFY CCW

0 !HISTORY 2010-12-31 [PTadmin] Official Update 2010-03
0 !HISTORY 2013-11-03 [MMR1988] Reworked to match corrected Ladders
0 !HISTORY 2023-10-31 [OrionP] Official Update 2023-05

Show contents

1 16 0 4 0 1 0 0 0 -1 0 0 0 1 stug4-1x5.dat
0 BFC INVERTNEXT
1 16 0 8 0 56 0 0 0 -4 0 0 0 16 box5.dat

3 16 56 8 20 56 8 16 42 8 20
3 16 38 8 20 42 8 20 56 8 16
3 16 22 8 20 38 8 20 56 8 16
3 16 18 8 20 22 8 20 56 8 16
3 16 2 8 20 18 8 20 56 8 16
4 16 -56 8 16 -2 8 20 2 8 20 56 8 16
3 16 -56 8 16 -18 8 20 -2 8 20
3 16 -56 8 16 -22 8 20 -18 8 20
3 16 -56 8 16 -38 8 20 -22 8 20
3 16 -56 8 16 -42 8 20 -38 8 20
3 16 -42 8 20 -56 8 16 -56 8 20
3 16 42 8 -20 56 8 -16 56 8 -20
3 16 56 8 -16 42 8 -20 38 8 -20
3 16 56 8 -16 38 8 -20 22 8 -20
3 16 56 8 -16 22 8 -20 18 8 -20
3 16 56 8 -16 18 8 -20 2 8 -20
4 16 56 8 -16 2 8 -20 -2 8 -20 -56 8 -16
3 16 -2 8 -20 -18 8 -20 -56 8 -16
3 16 -18 8 -20 -22 8 -20 -56 8 -16
3 16 -22 8 -20 -38 8 -20 -56 8 -16
3 16 -38 8 -20 -42 8 -20 -56 8 -16
3 16 -56 8 -20 -56 8 -16 -42 8 -20
3 16 56 8 20 56 8 22 60 8 22
3 16 56 8 16 56 8 20 60 8 22
4 16 60 8 -22 56 8 -16 56 8 16 60 8 22
3 16 60 8 -22 56 8 -20 56 8 -16
3 16 60 8 -22 56 8 -22 56 8 -20
3 16 -60 8 22 -56 8 22 -56 8 20
3 16 -60 8 22 -56 8 20 -56 8 16
4 16 -60 8 22 -56 8 16 -56 8 -16 -60 8 -22
3 16 -56 8 -16 -56 8 -20 -60 8 -22
3 16 -56 8 -20 -56 8 -22 -60 8 -22

0 // corner slopes
2 24 56 8 -22 56 8 -20
1 16 58 5.5 -24.5 -2 0 0 0 -1 2.5 0 1 2.5 rect3.dat
4 16 56 8 -22 56 3 -27 56 3 -20 56 8 -20
2 24 -56 8 -22 -56 8 -20
1 16 -58 5.5 -24.5 2 0 0 0 -1 2.5 0 1 2.5 rect3.dat
4 16 -56 8 -20 -56 3 -20 -56 3 -27 -56 8 -22
2 24 56 8 22 56 8 20
1 16 58 5.5 24.5 -2 0 0 0 -1 2.5 0 -1 -2.5 rect3.dat
4 16 56 8 20 56 3 20 56 3 27 56 8 22
2 24 -56 8 22 -56 8 20
1 16 -58 5.5 24.5 2 0 0 0 -1 2.5 0 -1 -2.5 rect3.dat
4 16 -56 8 22 -56 3 27 -56 3 20 -56 8 20

0 // side slopes x 10
4 16 42 3 -20 42 3 -27 42 8 -22 42 8 -20
1 16 40 5.5 -23.5 2 0 0 0 2.5 0 0 2.5 -1 box2-7.dat
4 16 38 8 -22 38 3 -27 38 3 -20 38 8 -20
4 16 22 3 -20 22 3 -27 22 8 -22 22 8 -20
1 16 20 5.5 -23.5 2 0 0 0 2.5 0 0 2.5 -1 box2-7.dat
4 16 18 8 -22 18 3 -27 18 3 -20 18 8 -20
4 16 2 3 -20 2 3 -27 2 8 -22 2 8 -20
1 16 0 5.5 -23.5 2 0 0 0 2.5 0 0 2.5 -1 box2-7.dat
4 16 -2 8 -22 -2 3 -27 -2 3 -20 -2 8 -20
4 16 -18 3 -20 -18 3 -27 -18 8 -22 -18 8 -20
1 16 -20 5.5 -23.5 2 0 0 0 2.5 0 0 2.5 -1 box2-7.dat
4 16 -22 8 -22 -22 3 -27 -22 3 -20 -22 8 -20
4 16 -38 3 -20 -38 3 -27 -38 8 -22 -38 8 -20
1 16 -40 5.5 -23.5 2 0 0 0 2.5 0 0 2.5 -1 box2-7.dat
4 16 -42 8 -22 -42 3 -27 -42 3 -20 -42 8 -20
4 16 -42 3 20 -42 3 27 -42 8 22 -42 8 20
1 16 -40 5.5 23.5 -2 0 0 0 2.5 0 0 -2.5 1 box2-7.dat
4 16 -38 8 22 -38 3 27 -38 3 20 -38 8 20
4 16 -22 3 20 -22 3 27 -22 8 22 -22 8 20
1 16 -20 5.5 23.5 -2 0 0 0 2.5 0 0 -2.5 1 box2-7.dat
4 16 -18 8 22 -18 3 27 -18 3 20 -18 8 20
4 16 -2 3 20 -2 3 27 -2 8 22 -2 8 20
1 16 0 5.5 23.5 -2 0 0 0 2.5 0 0 -2.5 1 box2-7.dat
4 16 2 8 22 2 3 27 2 3 20 2 8 20
4 16 18 3 20 18 3 27 18 8 22 18 8 20
1 16 20 5.5 23.5 -2 0 0 0 2.5 0 0 -2.5 1 box2-7.dat
4 16 22 8 22 22 3 27 22 3 20 22 8 20
4 16 38 3 20 38 3 27 38 8 22 38 8 20
1 16 40 5.5 23.5 -2 0 0 0 2.5 0 0 -2.5 1 box2-7.dat
4 16 42 8 22 42 3 27 42 3 20 42 8 20

0 // areas between side slopes
1 16 49 3 -23.5 7 0 0 0 -1 0 0 0 3.5 rect3.dat
1 16 49 5.5 -20 7 0 0 0 0 2.5 0 1 0 rect3.dat
1 16 30 3 -23.5 8 0 0 0 -1 0 0 0 3.5 rect3.dat
1 16 30 5.5 -20 8 0 0 0 0 2.5 0 1 0 rect3.dat
1 16 10 3 -23.5 8 0 0 0 -1 0 0 0 3.5 rect3.dat
1 16 10 5.5 -20 8 0 0 0 0 2.5 0 1 0 rect3.dat
1 16 -10 3 -23.5 8 0 0 0 -1 0 0 0 3.5 rect3.dat
1 16 -10 5.5 -20 8 0 0 0 0 2.5 0 1 0 rect3.dat
1 16 -30 3 -23.5 8 0 0 0 -1 0 0 0 3.5 rect3.dat
1 16 -30 5.5 -20 8 0 0 0 0 2.5 0 1 0 rect3.dat
1 16 -49 3 -23.5 7 0 0 0 -1 0 0 0 3.5 rect3.dat
1 16 -49 5.5 -20 7 0 0 0 0 2.5 0 1 0 rect3.dat
1 16 -49 3 23.5 -7 0 0 0 -1 0 0 0 -3.5 rect3.dat
1 16 -49 5.5 20 -7 0 0 0 0 2.5 0 -1 0 rect3.dat
1 16 -30 3 23.5 -8 0 0 0 -1 0 0 0 -3.5 rect3.dat
1 16 -30 5.5 20 -8 0 0 0 0 2.5 0 -1 0 rect3.dat
1 16 -10 3 23.5 -8 0 0 0 -1 0 0 0 -3.5 rect3.dat
1 16 -10 5.5 20 -8 0 0 0 0 2.5 0 -1 0 rect3.dat
1 16 10 3 23.5 -8 0 0 0 -1 0 0 0 -3.5 rect3.dat
1 16 10 5.5 20 -8 0 0 0 0 2.5 0 -1 0 rect3.dat
1 16 30 3 23.5 -8 0 0 0 -1 0 0 0 -3.5 rect3.dat
1 16 30 5.5 20 -8 0 0 0 0 2.5 0 -1 0 rect3.dat
1 16 49 3 23.5 -7 0 0 0 -1 0 0 0 -3.5 rect3.dat
1 16 49 5.5 20 -7 0 0 0 0 2.5 0 -1 0 rect3.dat

0 // endside
2 24 -60 8 22 -60 8 -22
2 24 60 8 -22 60 8 22
4 16 -60 3 27 -60 8 22 -60 8 -22 -60 3 -27
4 16 60 3 -27 60 8 -22 60 8 22 60 3 27
4 16 -60 3 27 -60 3 -27 -60 0 -24 -60 0 24
4 16 60 0 24 60 0 -24 60 3 -27 60 3 27
1 16 0 0 0 60 0 0 0 1 0 0 0 24 rect.dat

0 // ladderholder
4 16 -60 0 -24 -50 -2.67 -24 50 -2.5 -24 60 0 -24
4 16 60 -5 -24 60 0 -24 50 -2.5 -24 50 -5 -24
4 16 -50 -5 -24 -50 -2.5 -24 -60 0 -24 -60 -5 -24
1 16 47.25 -5 -24 2.75 0 0 0 2.5 0 0 0 2.75 1-4cylo.dat
1 16 -47.25 -5 -24 -2.75 0 0 0 2.5 0 0 0 2.75 1-4cylo.dat
1 16 47.25 -5 -24 2.75 0 0 0 1 0 0 0 2.75 1-4chrd.dat
1 16 47.25 -2.5 -24 2.75 0 0 0 -1 0 0 0 2.75 1-4chrd.dat
1 16 -47.25 -5 -24 -2.75 0 0 0 1 0 0 0 2.75 1-4chrd.dat
1 16 -47.25 -2.5 -24 -2.75 0 0 0 -1 0 0 0 2.75 1-4chrd.dat
4 16 -50 -5 -24 50 -5 -24 47.25 -5 -21.25 -47.25 -5 -21.25
4 16 -47.25 -2.5 -21.25 47.25 -2.5 -21.25 50 -2.5 -24 -50 -2.5 -24
1 16 0 -3.75 -21.25 47.25 0 0 0 0 1.25 0 -1 0 rect2p.dat
1 16 0 -3.75 -24 50 0 0 0 0 1.25 0 -1 0 recte3.dat
4 16 60 -5 -27 50 -5 -24 -50 -5 -24 -60 -5 -27
3 16 60 -5 -24 50 -5 -24 60 -5 -27
3 16 -60 -5 -27 -50 -5 -24 -60 -5 -24
4 16 60 3 -27 60 0 -24 60 -5 -24 60 -5 -27
4 16 -60 -5 -27 -60 -5 -24 -60 0 -24 -60 3 -27
1 16 0 -1 -27 60 0 0 0 0 -4 0 1 0 rect.dat
2 24 60 -5 -24 50 -5 -24
2 24 60 0 -24 60 -5 -24
2 24 -60 -5 -24 -50 -5 -24
2 24 -60 0 -24 -60 -5 -24
2 24 -60 -5 -24 -60 -5 -27
2 24 60 -5 -24 60 -5 -27
4 16 60 0 24 50 -2.67 24 -50 -2.5 24 -60 0 24
4 16 -60 -5 24 -60 0 24 -50 -2.5 24 -50 -5 24
4 16 50 -5 24 50 -2.5 24 60 0 24 60 -5 24
1 16 -47.25 -5 24 -2.75 0 0 0 2.5 0 0 0 -2.75 1-4cylo.dat
1 16 47.25 -5 24 2.75 0 0 0 2.5 0 0 0 -2.75 1-4cylo.dat
1 16 -47.25 -5 24 -2.75 0 0 0 1 0 0 0 -2.75 1-4chrd.dat
1 16 -47.25 -2.5 24 -2.75 0 0 0 -1 0 0 0 -2.75 1-4chrd.dat
1 16 47.25 -5 24 2.75 0 0 0 1 0 0 0 -2.75 1-4chrd.dat
1 16 47.25 -2.5 24 2.75 0 0 0 -1 0 0 0 -2.75 1-4chrd.dat
4 16 50 -5 24 -50 -5 24 -47.25 -5 21.25 47.25 -5 21.25
4 16 47.25 -2.5 21.25 -47.25 -2.5 21.25 -50 -2.5 24 50 -2.5 24
1 16 0 -3.75 21.25 -47.25 0 0 0 0 1.25 0 1 0 rect2p.dat
1 16 0 -3.75 24 -50 0 0 0 0 1.25 0 1 0 recte3.dat
4 16 -60 -5 27 -50 -5 24 50 -5 24 60 -5 27
3 16 -60 -5 24 -50 -5 24 -60 -5 27
3 16 60 -5 27 50 -5 24 60 -5 24
4 16 -60 3 27 -60 0 24 -60 -5 24 -60 -5 27
4 16 60 -5 27 60 -5 24 60 0 24 60 3 27
1 16 0 -1 27 -60 0 0 0 0 -4 0 -1 0 rect.dat
2 24 -60 -5 24 -50 -5 24
2 24 -60 0 24 -60 -5 24
2 24 60 -5 24 50 -5 24
2 24 60 0 24 60 -5 24
2 24 60 -5 24 60 -5 27
2 24 -60 -5 24 -60 -5 27

1 16 30 0 0 1 0 0 0 1 0 0 0 1 s\87913s01.dat
1 16 -30 0 0 1 0 0 0 1 0 0 0 1 s\87913s01.dat

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Max Martin Richter [MMR1988]

initially submitted the part.

2013-11-03 20:35:09

Magnus Forsberg [MagFors]

posted a vote of Hold.

2013-12-03 20:25:02

Let me first say that I like the new bumps. I cheated and simplified them a lot.

But I must object to the changes to the position of the guide rails. How many models will now be broken?
(and no, I don't object because it is "my part". We risk breaking a lot of models made with these parts)

Why should we change the design of official files, ladder 4207 and ladder holder 87913,
if it forces us to renumber them and use Move to-files? (see Steffen's comment at part 15118)

A small error gets amplified by a small move in position if many ladders are stacked on top of each other.
How many fire fighter will be hanging in mid air because we have desided to correct the thickness of the ladder and ladderholder?

It must be better to adapt the new ladder 15118. Or am I wrong?

Max Martin Richter [MMR1988]

made the following comment.

2013-12-03 21:25:01

Actually we have 2 files, that needs a new number / movedto / obsolete.
I think, that it is not such a big problem...
But if another decision (and only then) is made, feel free to modify the ladder and this part.
Actually I'm out of time. So I can only contribute with some very simple shapes and reviewing parts.

Magnus Forsberg [MagFors]

posted a vote of Hold.

2015-05-17 15:20:00

The help info needs to be updated to the new part 4207a.dat

Magnus Forsberg [MagFors]

posted a vote of Hold.

2015-06-07 21:50:01

HELP info refers to a Moved to-file.

[PTadmin]

edited the part header.

2022-03-06 17:00:01

Magnus Forsberg [MagFors]
