Official File parts/t1052c08.dat
Part Attributes:
Base Part: t1052.dat
File Header:
0 | Circuit Cubes High Speed Motor
0 Name: t1052c08.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Shortcut UPDATE 2022-05
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !CATEGORY Electric
0 !HISTORY 2022-09-15 [PTadmin] Official Update 2022-05
Show contents
0 // Cover
1 16 0 0 0 1 0 0 0 1 0 0 0 1 t1052.dat
0 // Base
1 47 0 48 0 -1 0 0 0 1 0 0 0 -1 t1044.dat
0 // Metal Posts
1 494 30 0 -30 -1 0 0 0 1 0 0 0 -1 t1045.dat
1 494 -30 0 -30 -1 0 0 0 1 0 0 0 -1 t1045.dat
0 // Side contacts
1 494 -30 34 -30 -1 0 0 0 1 0 0 0 -1 t1048.dat
1 494 30 34 -30 0 0 1 0 1 0 -1 0 0 t1048.dat
0 // PCB
1 15 0 34 0 -1 0 0 0 1 0 0 0 -1 t1053.dat
0 // bottom contacts
1 494 30 34 -30 0.70711 0 0.70711 0 1 0 -0.70711 0 0.70711 t1049.dat
1 494 -30 34 -30 -0.70711 0 0.70711 0 1 0 -0.70711 0 -0.70711 t1049.dat
1 494 -30 34 30 -0.70711 0 -0.70711 0 1 0 0.70711 0 -0.70711 t1049.dat
1 494 30 34 30 0.70711 0 -0.70711 0 1 0 0.70711 0 0.70711 t1049.dat
0 // Magnets
1 494 30 34 -30 0.70711 0 0.70711 0 1 0 -0.70711 0 0.70711 t1050.dat
1 494 -30 34 -30 -0.70711 0 0.70711 0 1 0 -0.70711 0 -0.70711 t1050.dat
0 // Shims
1 494 -30 34 30 -0.70711 0 -0.70711 0 1 0 0.70711 0 -0.70711 t1054.dat
1 494 30 34 30 0.70711 0 -0.70711 0 1 0 0.70711 0 0.70711 t1054.dat
0 // Motor Cover
1 47 0 29.5 0 -1 0 0 0 1 0 0 0 -1 t1102.dat
0 // Bottom Plate
1 47 0 29.5 0 -1 0 0 0 1 0 0 0 -1 t1103.dat
0 // Motor core
1 494 0 15 11 -1 0 0 0 1 0 0 0 -1 t1105.dat
0 // Output shaft
1 47 0 15 40 1 0 0 0 1 0 0 0 1 t1104.dat
