File Detail parts/u9013.dat

Official File parts/u9013.dat

Part Attributes:

File Header:

0 ~Screw 12 x  6 Pan Cruciform
0 Name: u9013.dat
0 Author: Guy Vivan [guyvivan]
0 !LDRAW_ORG Part UPDATE 2011-02
0 !LICENSE Licensed under CC BY 2.0 and CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS Phillips

0 !HISTORY 2010-07-05 [PTadmin] Official Update 2010-02
0 !HISTORY 2011-07-01 [PTadmin] Standardise title
0 !HISTORY 2011-12-29 [PTadmin] Official Update 2011-02

Show contents

0 // Nomenclature: Screw length_(LDu) x thread_diameter_(LDu) {head type} {slot type}

1 16 0 0 0 5 0 0 0 1 0 0 0 5 4-4edge.dat
1 16 0 0 0 5 0 0 0 -2 0 0 0 5 4-4cyli.dat
1 16 0 -2 0 4 0 0 0 -4 0 0 0 4 t04o2500.dat
1 16 0 -2 0 0 0 4 0 -4 0 -4 0 0 t04o2500.dat
1 16 0 -2 0 -4 0 0 0 -4 0 0 0 -4 t04o2500.dat
1 16 0 -2 0 0 0 -4 0 -4 0 4 0 0 t04o2500.dat
1 16 0 -3 0 1.53073 0 -3.69552 0 1 0 -3.69552 0 -1.53073 1-8chrd.dat
1 16 0 -3 0 3.69552 0 -1.53073 0 1 0 -1.53073 0 -3.69552 1-8chrd.dat
1 16 0 -3 0 3.69552 0 1.53073 0 1 0 1.53073 0 -3.69552 1-8chrd.dat
1 16 0 -3 0 1.53073 0 3.69552 0 1 0 3.69552 0 -1.53073 1-8chrd.dat
1 16 0 -3 0 -1.53073 0 3.69552 0 1 0 3.69552 0 1.53073 1-8chrd.dat
1 16 0 -3 0 -3.69552 0 1.53073 0 1 0 1.53073 0 3.69552 1-8chrd.dat
1 16 0 -3 0 -3.69552 0 -1.53073 0 1 0 -1.53073 0 3.69552 1-8chrd.dat
1 16 0 -3 0 -1.53073 0 -3.69552 0 1 0 -3.69552 0 1.53073 1-8chrd.dat
1 16 0 0 0 3 0 0 0 1 0 0 0 3 4-4edge.dat
1 16 0 0 0 1 0 0 0 -1 0 0 0 1 4-4ring3.dat
1 16 0 0 0 1 0 0 0 -1 0 0 0 1 4-4ring4.dat
1 16 0 12 0 3 0 0 0 1 0 0 0 3 4-4edge.dat
1 16 0 12 0 3 0 0 0 -12 0 0 0 3 4-4cyli.dat
1 16 0 12 0 3 0 0 0 -1 0 0 0 3 4-4disc.dat
2 24 1 -3 3.696 1 -3 1
3 16 1 -3 3.696 1 -3 1 1.532 -3 3.696
3 16 1 -3 1 3.696 -3 1 3.696 -3 1.532
3 16 3.696 -3 1.532 1.532 -3 3.696 1 -3 1
3 16 1 -3 1 1 -3 3.696 0 0 0
3 16 -1 -3 3.696 -1 -3 1 0 0 0
2 24 -1 -3 3.696 -1 -3 1
2 24 1 -3 3.696 -1 -3 3.696
3 16 1 -3 3.696 -1 -3 3.696 0 0 0
2 24 1 -3 3.696 0 0 0
2 24 -1 -3 3.696 0 0 0
2 24 0 0 0 1 -3 1
2 24 -3.696 -3 1 -1 -3 1
3 16 -3.696 -3 1 -1 -3 1 -3.696 -3 1.532
3 16 -1 -3 1 -1 -3 3.696 -1.532 -3 3.696
3 16 -1.532 -3 3.696 -3.696 -3 1.532 -1 -3 1
3 16 -1 -3 1 -3.696 -3 1 0 0 0
3 16 -3.696 -3 -1 -1 -3 -1 0 0 0
2 24 -3.696 -3 -1 -1 -3 -1
2 24 -3.696 -3 1 -3.696 -3 -1
3 16 -3.696 -3 1 -3.696 -3 -1 0 0 0
2 24 -3.696 -3 1 0 0 0
2 24 -3.696 -3 -1 0 0 0
2 24 0 0 0 -1 -3 1
2 24 -1 -3 -3.696 -1 -3 -1
3 16 -1 -3 -3.696 -1 -3 -1 -1.532 -3 -3.696
3 16 -1 -3 -1 -3.696 -3 -1 -3.696 -3 -1.532
3 16 -3.696 -3 -1.532 -1.532 -3 -3.696 -1 -3 -1
3 16 -1 -3 -1 -1 -3 -3.696 0 0 0
3 16 1 -3 -3.696 1 -3 -1 0 0 0
2 24 1 -3 -3.696 1 -3 -1
2 24 -1 -3 -3.696 1 -3 -3.696
3 16 -1 -3 -3.696 1 -3 -3.696 0 0 0
2 24 -1 -3 -3.696 0 0 0
2 24 1 -3 -3.696 0 0 0
2 24 0 0 0 -1 -3 -1
2 24 3.696 -3 -1 1 -3 -1
3 16 3.696 -3 -1 1 -3 -1 3.696 -3 -1.532
3 16 1 -3 -1 1 -3 -3.696 1.532 -3 -3.696
3 16 1.532 -3 -3.696 3.696 -3 -1.532 1 -3 -1
3 16 1 -3 -1 3.696 -3 -1 0 0 0
3 16 3.696 -3 1 1 -3 1 0 0 0
2 24 3.696 -3 1 1 -3 1
2 24 3.696 -3 -1 3.696 -3 1
3 16 3.696 -3 -1 3.696 -3 1 0 0 0
2 24 3.696 -3 -1 0 0 0
2 24 3.696 -3 1 0 0 0
2 24 0 0 0 1 -3 -1
