Official File parts/u9229.dat
~Pin for Electric Plug (Type 3) Twin
0 ~Pin for Electric Plug (Type 3) Twin
0 Name: u9229.dat
0 Author: Steffen [Steffen]
0 !LDRAW_ORG Part UPDATE 2024-10
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !CATEGORY Electric

0 !HISTORY 2018-12-08 [PTadmin] Official Update 2018-02
0 !HISTORY 2023-10-05 [kuramapika1] Adapted to new plug34 shape and added edged primitives
0 !HISTORY 2024-08-20 [Holly-Wood] Oriented slots vertical/horizontal again
0 !HISTORY 2024-12-01 [OrionP] Official Update 2024-10
Show file code:
1 16 0 0 0 1 0 0 0 1 0 0 0 1 plug34.dat

1 16 0 0 0 3.43275 0 -0.682816 -0.682816 0 -3.43275 0 1 0 3-16edge.dat
1 16 0 0 0 0.682816 0 3.43275 3.43275 0 -0.682816 0 1 0 3-16edge.dat
1 16 0 0 0 -3.43275 0 0.682816 0.682816 0 3.43275 0 1 0 3-16edge.dat
1 16 0 0 0 -0.682816 0 -3.43275 -3.43275 0 0.682816 0 1 0 3-16edge.dat

1 16 0 0 0 1.5 0 0 0 0 1.5 0 1 0 4-4ring2.dat

1 16 0 0 10 3.5 0 0 0 0 3.5 0 -1 0 4-4disc.dat
1 16 0 0 23 3.5 0 0 0 0 -3.5 0 1 0 4-4edge.dat
0 BFC INVERTNEXT
1 16 0 0 23 -3.5 0 0 0 0 -3.5 0 -13 0 4-4cyli.dat
1 16 0 0 10 3.5 0 0 0 0 -3.5 0 1 0 4-4edge.dat
1 16 0 0 23 0.5 0 0 0 0 0.5 0 -1 0 4-4ring7.dat
1 16 0 0 23 0.5 0 0 0 0 0.5 0 -1 0 4-4ring8.dat
1 16 0 0 23 4.5 0 0 0 0 -4.5 0 1 0 4-4edge.dat
1 16 0 0 0 4.5 0 0 0 0 -4.5 0 23 0 4-4cyli.dat
1 16 0 0 0 4.5 0 0 0 0 4.5 0 1 0 4-4edge.dat

Status

Official Official
This part has the following errors
  • Decimal precision exceeds 5 significant places
    Line 19: 1 16 0 0 0 0.682816 0 3.43275 3.43275 0 -0.682816 0 1 0 3-16edge.dat
    Line 21: 1 16 0 0 0 -0.682816 0 -3.43275 -3.43275 0 0.682816 0 1 0 3-16edge.dat
