Official File parts/s/2670s02.dat
File Header:
0 ~Monorail Track Bottom Triangles Subpart
0 Name: s\2670s02.dat
0 Author: Bernd Broich [bbroich]
0 !LDRAW_ORG Subpart UPDATE 2025-09
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2002-11-30 [PTadmin] Official Update 2002-05
0 !HISTORY 2007-08-28 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2008-07-07 [bbroich] BFC'ed (2003-11-09)
0 !HISTORY 2010-07-05 [PTadmin] Official Update 2010-02
0 !HISTORY 2025-09-27 [OrionP] Changed winding to CCW
0 !HISTORY 2025-09-29 [OrionP] Official Update 2025-09
Show contents
2 24 0 -3.5 2.5 28.75 -3.5 2.5
2 24 0 19.5 2.5 28.75 19.5 2.5
2 24 0 19.5 28 22 19.5 6
2 24 0 5 28 22 5 6
2 24 0 19.5 36 1 19.5 36
2 24 1 19.5 31 1 19.5 36
2 24 1 19.5 31 1 5 31
2 24 1 19.5 31 26 19.5 6
2 24 1 19.5 36 1 5 36
2 24 1 5 31 1 5 36
2 24 1 5 31 26 5 6
2 24 22 19.5 6 0 19.5 6
2 24 22 19.5 6 22 5 6
2 24 22 5 6 0 5 6
2 24 26 19.5 6 26 5 6
2 24 28.75 -3.5 0 28.75 -3.5 2.5
2 24 28.75 19.5 0 28.75 19.5 2.5
2 24 28.75 19.5 2.5 28.75 -3.5 2.5
2 24 30 19.5 6 26 19.5 6
2 24 30 5 6 26 5 6
3 16 0 5 28 22 5 6 0 5 6
4 16 0 19.5 2.5 28.75 19.5 2.5 28.75 -3.5 2.5 0 -3.5 2.5
4 16 0 19.5 36 1 19.5 36 1 19.5 31 0 19.5 28
4 16 1 19.5 31 26 19.5 6 22 19.5 6 0 19.5 28
4 16 0 19.5 28 22 19.5 6 22 5 6 0 5 28
4 16 26 5 6 26 19.5 6 1 19.5 31 1 5 31
4 16 1 19.5 31 1 19.5 36 1 5 36 1 5 31
4 16 22 19.5 6 0 19.5 6 0 5 6 22 5 6
4 16 0 -3.5 0 0 -3.5 2.5 28.75 -3.5 2.5 28.75 -3.5 0
4 16 28.75 -3.5 2.5 28.75 19.5 2.5 28.75 19.5 0 28.75 -3.5 0
4 16 30 19.5 2.5 0 19.5 2.5 0 19.5 6 30 19.5 6
4 16 30 19.5 0 28.75 19.5 0 28.75 19.5 6 30 19.5 6
4 16 30 5 6 26 5 6 1 5 31 30 5 31
4 16 1 5 31 1 5 36 30 5 36 30 5 31
4 16 30 19.5 6 26 19.5 6 26 5 6 30 5 6
0
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
Creative Commons Attribution License information
This part is copyright © Bernd Broich
Licensed under CC BY 4.0
