Official File parts/s/32193s01.dat
File Header:
0 ~Wheel 14 x 21 Solid Rubber with Axlehole - 1/15 Tread
0 Name: s\32193s01.dat
0 Author: Michael Heidemann [mikeheide]
0 !LDRAW_ORG Subpart UPDATE 2025-09
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2012-08-09 [PTadmin] Official Update 2012-02
0 !HISTORY 2025-09-27 [OrionP] Changed winding to CCW
0 !HISTORY 2025-09-29 [OrionP] Official Update 2025-09
Show contents
4 16 26 -1 0 25.431 -1 5.405 25.431 -15 5.405 26 -15 0
4 16 21 -17 0 21 -1 0 26 -1 0 26 -15 0
4 16 25.431 -15 5.405 25.431 -1 5.405 20.45 -1 4.366 20.45 -17 4.366
0 // conditional lines
2 24 26 -1 0 26 -15 0
2 24 25.431 -1 5.405 25.431 -15 5.405
0
4 16 20.5411 -1 4.36615 19.1834 -1 8.5411 19.1834 -17 8.5411 20.5411 -17 4.36615
0 // conditional lines
2 24 20.5411 -1 4.36615 20.5411 -17 4.36615
2 24 19.1834 -1 8.5411 19.1834 -17 8.5411
0
4 16 20.9989 -17 0 25.999 -15 0.000514427 25.4318 -15 5.4057 20.5411 -17 4.36615
4 16 20.54 -1 4.36583 25.4308 -1 5.40601 23.7522 -1 10.5752 19.1845 -1 8.54147
0 // conditional lines
2 24 20.5411 -17 4.36615 25.4318 -15 5.4057
2 24 20.5411 -1 4.36615 25.4318 -1 5.4057
2 24 20.9989 -17 0 25.999 -15 0.000514427
2 24 20.9989 -1 0 25.999 -1 0.000514427
0
2 24 21 -17 0 20.54 -17 4.366
2 24 20.5411 -17 4.36615 19.1834 -17 8.5411
2 24 20.5411 -1 4.36615 19.1834 -1 8.5411
0
2 24 26 -15 0 25.431 -15 5.405
0
2 24 25.4318 -1 5.4057 23.7515 -1 10.5743
0
Status:
Official
This part has the following errors
-
Decimal precision exceeds 5 significant placesLine text: 4 16 20.9989 -17 0 25.999 -15 0.000514427 25.4318 -15 5.4057 20.5411 -17 4.36615
-
Decimal precision exceeds 5 significant placesLine text: 2 24 20.9989 -17 0 25.999 -15 0.000514427
-
Decimal precision exceeds 5 significant placesLine text: 2 24 20.9989 -1 0 25.999 -1 0.000514427
This part has the following warnings
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 4 16 20.5411 -1 4.36615 19.1834 -1 8.5411 19.1834 -17 8.5411 20.5411 -17 4.36615
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 2 24 20.5411 -1 4.36615 20.5411 -17 4.36615
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 4 16 20.54 -1 4.36583 25.4308 -1 5.40601 23.7522 -1 10.5752 19.1845 -1 8.54147
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 2 24 20.5411 -17 4.36615 25.4318 -15 5.4057
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 2 24 20.5411 -1 4.36615 25.4318 -1 5.4057
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 2 24 20.5411 -17 4.36615 19.1834 -17 8.5411
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 2 24 20.5411 -1 4.36615 19.1834 -1 8.5411
