Official File parts/s/3739b.dat
File Header:
0 ~Wheel 24 x 43 Technic - 1/2 Axle Mount
0 Name: s\3739b.dat
0 Author: Alex Taylor [anathema]
0 !LDRAW_ORG Subpart UPDATE 2012-02
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2012-08-09 [PTadmin] Official Update 2012-02
Show contents
2 24 -10 -5.602 -2 -10 -5.74 -1.25
2 24 -50 -5.602 -2 -50 -5.74 -1.25
2 24 -10 -5.602 -2 -50 -5.602 -2
2 24 -50 -5.751 -1.25 -10 -5.751 -1.25
4 16 -50 -5.751 -1.25 -10 -5.751 -1.25 -10 -5.602 -2 -50 -5.602 -2
4 16 -50 5.602 -2 -10 5.602 -2 -10 5.751 -1.25 -50 5.751 -1.25
2 24 -10 -6.364 -6.364 -50 -6.364 -6.364
2 24 -10 5.602 -2 -10 5.74 -1.25
2 24 -50 5.602 -2 -50 5.74 -1.25
2 24 -10 5.602 -2 -50 5.602 -2
2 24 -50 5.751 -1.25 -10 5.751 -1.25
2 24 -10 6.364 -6.364 -50 6.364 -6.364
4 16 -50 -5.74 -1.25 -50 -5.543 -2.296 -50 -6.364 -6.364 -50 -6.364 -1.25
4 16 -50 6.364 -1.25 -50 6.364 -6.364 -50 5.543 -2.296 -50 5.74 -1.25
4 16 -10 -6.364 -1.25 -10 -6.364 -6.364 -10 -5.543 -2.296 -10 -5.74 -1.25
4 16 -10 5.74 -1.25 -10 5.543 -2.296 -10 6.364 -6.364 -10 6.364 -1.25
3 16 -10 -4 -4 -10 -5.543 -2.296 -10 -6.364 -6.364
3 16 -10 6.364 -6.364 -10 5.543 -2.296 -10 4 -4
3 16 -50 -6.364 -6.364 -50 -5.543 -2.296 -50 -4 -4
3 16 -50 4 -4 -50 5.543 -2.296 -50 6.364 -6.364
2 24 -10 5.74 -1.25 -10 21.1 -1.25
2 24 -10 6.364 -6.364 -10 20.236 -6.364
2 24 -50 5.751 -1.25 -50 21.168 -1.25
2 24 -50 6.364 -6.364 -50 20.236 -6.364
2 24 -10 -5.74 -1.25 -10 -21.1 -1.25
2 24 -10 -6.364 -6.364 -10 -20.236 -6.364
2 24 -50 -5.751 -1.25 -50 -21.168 -1.25
2 24 -50 -6.364 -6.364 -50 -20.236 -6.364
4 16 -50 -6.364 -6.364 -10 -6.364 -6.364 -10 -20.236 -6.364 -50 -20.236 -6.364
4 16 -50 -5.74 -1.25 -50 -21.168 -1.25 -10 -21.168 -1.25 -10 -5.74 -1.25
4 16 -50 20.236 -6.364 -10 20.236 -6.364 -10 6.364 -6.364 -50 6.364 -6.364
4 16 -10 5.74 -1.25 -10 21.168 -1.25 -50 21.168 -1.25 -50 5.74 -1.25
4 16 -10 -6.364 -6.364 -10 -6.364 -1.25 -10 -21.168 -1.25 -10 -21.168 -6.364
2 24 -10 -21.168 -1.25 -10 -21.25 0
2 24 -10 21.168 -1.25 -10 21.25 0
2 24 -50 -21.168 -1.25 -50 -21.25 0
2 24 -50 21.168 -1.25 -50 21.25 0
4 16 -10 21.168 -6.364 -10 21.168 -1.25 -10 6.364 -1.25 -10 6.364 -6.364
4 16 -50 -21.168 -6.364 -50 -21.168 -1.25 -50 -6.364 -1.25 -50 -6.364 -6.364
4 16 -50 6.364 -6.364 -50 6.364 -1.25 -50 21.168 -1.25 -50 21.168 -6.364
1 16 -10 0 0 0 -40 0 -6.36396 0 6.36396 -6.36396 0 -6.36396 1-4cyli.dat
1 16 -10 0 0 0 -1 0 -6.36396 0 6.36396 -6.36396 0 -6.36396 1-4edge.dat
1 16 -50 0 0 0 -1 0 -6.36396 0 6.36396 -6.36396 0 -6.36396 1-4edge.dat
1 16 -10 0 0 0 -1 0 -2.12132 0 2.12132 -2.12132 0 -2.12132 1-4ring2.dat
1 16 -50 0 0 0 1 0 2.12132 0 -2.12132 -2.12132 0 -2.12132 1-4ring2.dat
4 16 -10 0 -6 -10 -2.296 -5.543 -10 -2 -5.8 -10 -1 -6
4 16 -50 -1 -6 -50 -2 -5.8 -50 -2.296 -5.543 -50 0 -6
4 16 -10 1 -6 -10 2 -5.8 -10 2.296 -5.543 -10 0 -6
4 16 -50 0 -6 -50 2.296 -5.543 -50 2 -5.8 -50 1 -6
2 24 -10 -20.236 -6.364 -50 -20.236 -6.364
2 24 -10 -21.168 -1.25 -50 -21.168 -1.25
2 24 -10 20.236 -6.364 -50 20.236 -6.364
2 24 -10 21.168 -1.25 -50 21.168 -1.25
2 24 -10 19.632 -8.133 -10 20.236 -6.364
2 24 -10 -19.632 -8.133 -10 -20.236 -6.364
1 16 -10 0 0 0 1 0 19.6324 0 -8.13202 -8.13202 0 -19.6324 48\3-8edge.dat
2 24 -50 19.632 -8.133 -50 20.236 -6.364
2 24 -50 -19.632 -8.133 -50 -20.236 -6.364
1 16 -50 0 0 0 1 0 19.6324 0 -8.13202 -8.13202 0 -19.6324 48\3-8edge.dat
0
Status:
Official
This part has the following warnings
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 -10 0 0 0 -40 0 -6.36396 0 6.36396 -6.36396 0 -6.36396 1-4cyli.dat
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 -10 0 0 0 -1 0 -6.36396 0 6.36396 -6.36396 0 -6.36396 1-4edge.dat
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 -50 0 0 0 -1 0 -6.36396 0 6.36396 -6.36396 0 -6.36396 1-4edge.dat
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 -10 0 0 0 -1 0 -2.12132 0 2.12132 -2.12132 0 -2.12132 1-4ring2.dat
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 -50 0 0 0 1 0 2.12132 0 -2.12132 -2.12132 0 -2.12132 1-4ring2.dat
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 -10 0 0 0 1 0 19.6324 0 -8.13202 -8.13202 0 -19.6324 48\3-8edge.dat
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 -50 0 0 0 1 0 19.6324 0 -8.13202 -8.13202 0 -19.6324 48\3-8edge.dat
Unofficial parents
Part Events:
Archived Part Events:
Creative Commons Attribution License information
This part is copyright © Alex Taylor
Licensed under CC BY 4.0
