Official File parts/s/4266s01.dat
File Header:
0 ~Wheel 20 x 30 Smooth with 6 Pegholes - 1/6 with Axlehole
0 Name: s\4266s01.dat
0 Author: Niels Bugge [SirBugge]
0 !LDRAW_ORG Subpart UPDATE 2025-09
0 !LICENSE Licensed under CC BY 2.0 and CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2010-05-31 [Philo] Closed gaps around axlehole, changed hires to normal where not needed
0 !HISTORY 2012-12-28 [PTadmin] Official Update 2012-03
0 !HISTORY 2024-03-23 [OrionP] Updated ring primitives
0 !HISTORY 2024-03-24 [OrionP] Official Update 2024-02
0 !HISTORY 2025-09-27 [OrionP] Changed winding to CCW
0 !HISTORY 2025-09-29 [OrionP] Official Update 2025-09
Show contents
1 16 0 -11.5 27 1 0 0 0 -1 0 0 0 9 rect.dat
2 24 -1 -5.8 18 -1 -11.5 18
2 24 -1 -5.8 18 -2 -5.55 18
2 24 1 -5.8 18 1 -11.5 18
2 24 1 -5.8 18 2 -5.55 18
2 24 -1 -5.8 36 -2 -5.55 36
2 24 1 -5.8 36 2 -5.55 36
2 24 -1 -5.8 36 -1 -11.5 36
2 24 1 -5.8 36 1 -11.5 36
4 16 -2 -5.55 36 -1 -5.8 36 -1 -5.8 18 -2 -5.55 18
4 16 2 -5.55 18 1 -5.8 18 1 -5.8 36 2 -5.55 36
2 24 2 -5.55 36 2 -5.55 18
2 24 1 -5.8 36 1 -5.8 18
2 24 -2 -5.55 36 -2 -5.55 18
2 24 -1 -5.8 36 -1 -5.8 18
4 16 1 -11.5 36 1 -5.8 36 1 -5.8 18 1 -11.5 18
4 16 -1 -11.5 18 -1 -5.8 18 -1 -5.8 36 -1 -11.5 36
1 16 0 0 36 -0.39018 0 -1.96157 1.96157 0 -0.39018 0 -18 0 48\7-16ring3.dat
1 16 0 0 36 -0.57402 0 -1.38582 1.38582 0 -0.57402 0 -18 0 3-8ring4.dat
1 16 0 0 18 -0.57402 0 -1.38582 1.38582 0 -0.57402 0 1 0 3-8ring4.dat
1 16 0 0 18 -0.39018 0 -1.96157 -1.96157 0 0.39018 0 18 0 48\7-16ring3.dat
2 24 -1.5 -14 36 -1.5 -14 18
2 24 1.5 -14 36 1.5 -14 18
1 16 0 -12.75 36 0 0 1.5 -1.25 0 0 0 -1 0 rect1.dat
4 16 -4 -10.5 18 -4 -5 18 -1 -5.8 18 -1 -10.5 18
4 16 1 -10.5 18 1 -5.8 18 4 -5 18 4 -10.5 18
4 16 4 -11.5 36 4 -5 36 1 -5.8 36 1 -11.5 36
4 16 -1 -11.5 36 -1 -5.8 36 -4 -5 36 -4 -11.5 36
1 16 -4 -9.2 27 0 1 0 0 0 2.3 9 0 0 rect3.dat
1 16 4 -9.2 27 0 -1 0 0 0 2.3 -9 0 0 rect3.dat
1 16 1.5 -11.5 36 2.5 0 0 0 0 -2.5 0 -18 0 1-4cylc.dat
1 16 -1.5 -11.5 36 -2.5 0 0 0 0 -2.5 0 -18 0 1-4cylc.dat
2 24 -1.5 -20 24 -1.5 -14 36
2 24 -1.5 -20 18 -1.5 -14 18
2 24 1.5 -20 24 1.5 -14 36
2 24 1.5 -20 18 1.5 -14 18
4 16 1.5 -20 24 1.5 -14 36 -1.5 -14 36 -1.5 -20 24
4 16 -1.5 -20 24 -1.5 -14 36 -1.5 -14 18 -1.5 -20 18
4 16 1.5 -20 18 1.5 -14 18 1.5 -14 36 1.5 -20 24
1 16 0 -20 21 1.5 0 0 0 1 0 0 0 3 rect3.dat
Status:
Official
This part has the following warnings
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 0 0 36 -0.39018 0 -1.96157 1.96157 0 -0.39018 0 -18 0 48\7-16ring3.dat
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 0 0 36 -0.57402 0 -1.38582 1.38582 0 -0.57402 0 -18 0 3-8ring4.dat
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 0 0 18 -0.57402 0 -1.38582 1.38582 0 -0.57402 0 1 0 3-8ring4.dat
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 1 16 0 0 18 -0.39018 0 -1.96157 -1.96157 0 0.39018 0 18 0 48\7-16ring3.dat
- Number in description may need a leading space
Unofficial parents
Part Events:
Archived Part Events:
Creative Commons Attribution License information
This part is copyright © Niels Bugge
Licensed under CC BY 2.0
