Official File parts/s/92409s01.dat
File Header:
0 ~Tyre 6.4/ 75 x 8 Shallow Offset Tread with Centre Band - Profile
0 Name: s\92409s01.dat
0 Author: Massimo Maso [Sirio]
0 !LDRAW_ORG Subpart UPDATE 2018-01
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2018-01-30 [PTadmin] Official Update 2018-01
Show contents
4 16 5.4352 -20.2842 1.0667 5.4352 -20.2842 8 1.8303 -20.9198 8 1.8303 -20.9198 1.0667
2 24 5.4352 -20.2842 8 1.8303 -20.9198 8
2 24 -1.8303 -20.9198 1.0667 -1.8303 -20.9198 8
2 24 1.8303 -20.9198 1.0667 1.8303 -20.9198 8
2 24 5.4352 -20.2842 1.0667 5.4352 -20.2842 8
2 24 5.4352 -20.2842 1.0667 1.8303 -20.9198 1.0667
2 24 -1.8303 -20.9198 -1.0667 1.8303 -20.9198 -1.0667
4 16 1.9174 -21.916 8 1.8303 -20.9198 8 -1.8303 -20.9198 8 -1.9174 -21.916 8
4 16 -1.9174 -21.916 1.0667 -1.9174 -21.916 8 -1.8303 -20.9198 8 -1.8303 -20.9198 1.0667
4 16 1.9174 -21.916 1.0667 1.8303 -20.9198 1.0667 1.8303 -20.9198 8 1.9174 -21.916 8
4 16 1.9174 -21.916 -1.0667 -1.9174 -21.916 -1.0667 -1.8303 -20.9198 -1.0667 1.8303 -20.9198 -1.0667
2 24 -1.9174 -21.916 8 -1.8303 -20.9198 8
2 24 1.9174 -21.916 8 1.8303 -20.9198 8
2 24 -1.9174 -21.916 -1.0667 -1.8303 -20.9198 -1.0667
2 24 1.9174 -21.916 -1.0667 1.8303 -20.9198 -1.0667
4 16 1.9174 -21.916 8 -1.9174 -21.916 8 -1.9174 -21.916 1.0667 1.9174 -21.916 1.0667
4 16 1.9174 -21.916 1.0667 -1.9174 -21.916 1.0667 -1.9174 -21.916 -1.0667 1.9174 -21.916 -1.0667
2 24 1.9174 -21.916 8 -1.9174 -21.916 8
2 24 -1.9174 -21.916 1.0667 -1.9174 -21.916 8
2 24 1.9174 -21.916 1.0667 1.9174 -21.916 8
2 24 1.9174 -21.916 -1.0667 -1.9174 -21.916 -1.0667
5 24 -1.9174 -21.916 1.0667 -1.9174 -21.916 -1.0667 1.9174 -21.916 1.0667 -5.69394 -21.2501 -1.0667
5 24 1.9174 -21.916 -1.0667 1.9174 -21.916 1.0667 -1.9174 -21.916 1.0667 5.69394 -21.2501 -1.0667
Status:
Official
This part has the following warnings
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 5 24 -1.9174 -21.916 1.0667 -1.9174 -21.916 -1.0667 1.9174 -21.916 1.0667 -5.69394 -21.2501 -1.0667
-
5 decimal places exceeds the recommendation for Subpart in the library specificationLine text: 5 24 1.9174 -21.916 -1.0667 1.9174 -21.916 1.0667 -1.9174 -21.916 1.0667 5.69394 -21.2501 -1.0667
Unofficial parents
Part Events:
Archived Part Events:
Creative Commons Attribution License information
This part is copyright © Massimo Maso
Licensed under CC BY 4.0
