0 Stud Tube Open 0.500 Sloped
0 Name: stud4s2.dat
0 Author: Willy Tschager [Holly-Wood]
0 !LDRAW_ORG Primitive UPDATE 2024-05
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 !HELP For use between a stud4a and a half-sloped surface. It is enough
0 !HELP to know coordinates Y of the centre and that of the outside circle.
0 !HELP The difference of both coordinates is the height of the primitive
0 !HELP to be applied. Finally, this primitive can be used with all the
0 !HELP parts sloped using a STUD4A. H = Y center sloped - Y common border.
0 BFC CERTIFY CCW
0 !HISTORY 2012-08-09 [PTadmin] Official Update 2012-02
0 !HISTORY 2024-02-08 [Holly-Wood] Complete re-write, original by gregteft
0 !HISTORY 2024-06-30 [OrionP] Official Update 2024-05
