0 Duplo Brick  2 x  2 x  2 with Inside Curve
0 Name: 11169.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Part UPDATE 2024-11
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !CATEGORY Arch

0 !HISTORY 2020-12-12 {LEGO/Unity Microgame} Original part shape
0 !HISTORY 2021-01-14 [Philo] File preparation for LDraw Parts Tracker
0 !HISTORY 2024-12-30 [OrionP] Official Update 2024-11

Show contents

0 BFC INVERTNEXT
1 16 40 0 -67 0 -80 0 0 0 48.3 47 0 0 48\5-24cylo.dat
1 16 0 0 0 1 0 0 0 2.75 0 0 0 1 stug7-1x2.dat
1 16 0 36 0 40 0 0 0 -36 0 0 0 20 box2-5.dat
4 16 -40 72 -60 -36 72 -56 36 72 -56 40 72 -60
4 16 -40 72 20 -36 72 16 -36 72 -56 -40 72 -60
4 16 40 72 20 36 72 16 -36 72 16 -40 72 20
4 16 40 72 -60 36 72 -56 36 72 16 40 72 20
1 16 0 40 -20 1 0 0 0 -7 0 0 0 1 stud8a.dat
1 16 20 37.5 16 1.5 0 0 0 0 33.5 0 -4 0 box4-1.dat
1 16 -20 37.5 16 1.5 0 0 0 0 33.5 0 -4 0 box4-1.dat
1 16 36 37.5 0 0 -4 0 0 0 33.5 -1.5 0 0 box4-1.dat
1 16 -36 37.5 0 0 4 0 0 0 33.5 -1.5 0 0 box4-1.dat
1 16 0 4 5.8 0 0 1.5 0 40 0 -10.2 0 0 box3u5p.dat
1 16 0 4 0 0 0 36 0 -1 0 16 0 0 rect.dat
1 16 0 38 16 -36 0 0 0 0 34 0 1 0 rect3.dat
1 16 36 4 -63 0 -72 0 0 0 48 47 0 0 3-16cylo.dat
1 16 0 40 -20 16 0 0 0 -36 0 0 0 16 2-4cyli.dat
1 16 0 4 -20 14.78207 0 -6.12293 0 -1 0 6.12293 0 14.78207 3-8edge.dat
0 BFC INVERTNEXT
1 16 0 40 -20 14 0 0 0 -36 0 0 0 14 2-4cyli.dat
1 16 0 40 -20 6.12293 0 14.78207 0 -30 0 -14.78207 0 6.12293 3-16cyls.dat
0 BFC INVERTNEXT
1 16 0 40 -20 5.35757 0 12.93431 0 -31 0 -12.93431 0 5.35757 3-16cyls.dat
2 24 9.8998 38.0318 -29.8997 5.5836 40 -32.7833
2 24 12.9342 31.2035 -25.3575 9.9889 37.9408 -29.7663
2 24 9.8998 38.0318 -29.8997 9.9889 37.9408 -29.7663
2 24 14.0004 23.0166 -20 12.9342 31.2035 -25.3575
2 24 5.3578 40.1033 -32.9346 0 40.8304 -34
2 24 5.5842 40 -32.7833 5.3578 40.1033 -32.9346
2 24 13.9158 22.3696 -19.5767 13.2046 4 -16
2 24 13.9158 22.3696 -19.5767 14 23.0165 -20
2 24 0 42.1955 -36 6.1232 41.3644 -34.7824
2 24 6.1232 41.3644 -34.7824 11.3141 38.9971 -31.3139
2 24 16.0004 23.0166 -20 14.7819 32.3731 -26.1229
2 24 12.348 37.9408 -29.7663 14.7819 32.3731 -26.1229
2 24 11.3141 38.9971 -31.3139 12.348 37.9408 -29.7663
2 24 15.9158 22.3696 -19.5767 15.2046 4 -16
2 24 15.9158 22.3696 -19.5767 16 23.0165 -20
1 16 0 40 -20 -6.12293 0 -14.78207 0 -30 0 -14.78207 0 6.12293 3-16cyls.dat
0 BFC INVERTNEXT
1 16 0 40 -20 -5.35757 0 -12.93431 0 -31 0 -12.93431 0 5.35757 3-16cyls.dat
2 24 -9.8998 38.0318 -29.8997 -5.5836 40 -32.7833
2 24 -12.9342 31.2035 -25.3575 -9.9889 37.9408 -29.7663
2 24 -9.8998 38.0318 -29.8997 -9.9889 37.9408 -29.7663
2 24 -14.0004 23.0166 -20 -12.9342 31.2035 -25.3575
2 24 -5.3578 40.1033 -32.9346 0 40.8304 -34
2 24 -5.5842 40 -32.7833 -5.3578 40.1033 -32.9346
2 24 -13.9158 22.3696 -19.5767 -13.2046 4 -16
2 24 -13.9158 22.3696 -19.5767 -14 23.0165 -20
2 24 0 42.1955 -36 -6.1232 41.3644 -34.7824
2 24 -6.1232 41.3644 -34.7824 -11.3141 38.9971 -31.3139
2 24 -16.0004 23.0166 -20 -14.7819 32.3731 -26.1229
2 24 -12.348 37.9408 -29.7663 -14.7819 32.3731 -26.1229
2 24 -11.3141 38.9971 -31.3139 -12.348 37.9408 -29.7663
2 24 -15.9158 22.3696 -19.5767 -15.2046 4 -16
2 24 -15.9158 22.3696 -19.5767 -16 23.0165 -20
1 16 0 60 -60 40 0 0 0 0 12 0 1 0 rect.dat
1 16 0 47.3265 -57.4182 0 0 40 0.6735 1 0 -2.5818 0 0 rect2p.dat
1 16 0 62 -56 36 0 0 0 0 10 0 -1 0 rect.dat
1 16 0 50.1736 -50.5066 0 0 -36 1.8264 -1 0 -5.49345 0 0 rect2p.dat
2 24 36 72 -56 36 72 16
2 24 -36 72 -56 -36 72 16
1 16 0 4 -20 12.93431 0 -5.35757 0 1 0 5.35757 0 12.93431 3-8edge.dat
2 24 14.7821 4 -13.8771 15.2046 4 -16
2 24 -15.2046 4 -16 -14.7824 4 -13.8768
2 24 12.9343 4 -14.6424 13.2046 4 -16
2 24 -13.2046 4 -16 -12.9346 4 -14.6422
1 16 36 57 -40 0 -4 0 0 0 14 -1.5 0 0 box4-4a.dat
2 24 32 43.9018 -38.5 32 45.9494 -41.5
2 24 32 43.9018 -38.5 36 43.9018 -38.5
2 24 32 45.9494 -41.5 36 45.9494 -41.5
1 16 20 60.5 -56 1.5 0 0 0 0 10.5 0 4 0 box4-4a.dat
2 24 21.5 50.6701 -52 18.5 50.6701 -52
2 24 21.5 50.6701 -52 21.5 52 -56
2 24 18.5 52 -56 18.5 50.6701 -52
4 16 36 37.9408 -29.7663 36 4 -16 36 4 16 36 72 16
4 16 36 37.9408 -29.7663 36 72 16 36 72 -56 36 52 -56
1 16 40 0 -67 0 -1 0 0 0 48.3 47 0 0 48\5-24ndis.dat
4 16 40 46.653 -54.8364 40 48 -60 40 72 -60 40 48.3 -20
4 16 40 0 20 40 0 -20 40 48.3 -20 40 72 20
3 16 40 48.3 -20 40 72 -60 40 72 20
1 16 -36 57 -40 0 4 0 0 0 14 -1.5 0 0 box4-4a.dat
2 24 -32 43.9018 -38.5 -32 45.9494 -41.5
2 24 -32 43.9018 -38.5 -36 43.9018 -38.5
2 24 -32 45.9494 -41.5 -36 45.9494 -41.5
1 16 -20 60.5 -56 -1.5 0 0 0 0 10.5 0 4 0 box4-4a.dat
2 24 -21.5 50.6701 -52 -18.5 50.6701 -52
2 24 -21.5 50.6701 -52 -21.5 52 -56
2 24 -18.5 52 -56 -18.5 50.6701 -52
4 16 -36 4 16 -36 4 -16 -36 37.9408 -29.7663 -36 72 16
4 16 -36 72 -56 -36 72 16 -36 37.9408 -29.7663 -36 52 -56
1 16 -40 0 -67 0 1 0 0 0 48.3 47 0 0 48\5-24ndis.dat
4 16 -40 72 -60 -40 48 -60 -40 46.653 -54.8364 -40 48.3 -20
4 16 -40 48.3 -20 -40 0 -20 -40 0 20 -40 72 20
3 16 -40 72 -60 -40 48.3 -20 -40 72 20
2 24 40 72 -60 40 72 20
2 24 -40 72 -60 -40 72 20
2 24 1.5 44 -4.2983 0 44 -4
2 24 1.5 4 -4.2983 1.5 44 -4.2983
2 24 0 44 -4 -1.5 44 -4.2983
2 24 -1.5 44 -4.2983 -1.5 4 -4.2983
