File Detail parts/15317.dat

Official File parts/15317.dat

Part Attributes:

File Header:

0 ~Duplo Tyre 13 / 50 x 21
0 Name: 15317.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Part UPDATE 2024-08
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !CATEGORY Wheel

0 !HISTORY 2020-12-12 {LEGO/Unity Microgame} Original part shape
0 !HISTORY 2021-02-15 [Philo] File preparation for LDraw Parts Tracker
0 !HISTORY 2024-03-23 [OrionP] Updated ring primitives
0 !HISTORY 2024-09-30 [OrionP] Official Update 2024-08

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.96858 -0.24869 0 0.24869 0.96858 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.87631 -0.48175 0 0.48175 0.87631 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.72897 -0.68455 0 0.68455 0.72897 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.53583 -0.84433 0 0.84433 0.53583 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.30902 -0.95106 0 0.95106 0.30902 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.06279 -0.99803 0 0.99803 0.06279 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.18738 -0.98229 0 0.98229 -0.18738 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.42578 -0.90483 0 0.90483 -0.42578 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.63742 -0.77051 0 0.77051 -0.63742 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.80902 -0.58779 0 0.58779 -0.80902 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.92978 -0.36812 0 0.36812 -0.92978 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.99211 -0.12533 0 0.12533 -0.99211 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.99211 0.12533 0 -0.12533 -0.99211 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.92978 0.36812 0 -0.36812 -0.92978 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.80902 0.58779 0 -0.58779 -0.80902 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.63742 0.77051 0 -0.77051 -0.63742 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.42578 0.90483 0 -0.90483 -0.42578 0 0 0 1 s\15317s01.dat
1 16 0 0 0 -0.18738 0.98229 0 -0.98229 -0.18738 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.06279 0.99803 0 -0.99803 0.06279 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.30902 0.95106 0 -0.95106 0.30902 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.53583 0.84433 0 -0.84433 0.53583 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.72897 0.68455 0 -0.68455 0.72897 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.87631 0.48175 0 -0.48175 0.87631 0 0 0 1 s\15317s01.dat
1 16 0 0 0 0.96858 0.24869 0 -0.24869 0.96858 0 0 0 1 s\15317s01.dat
0 BFC INVERTNEXT
1 16 0 0 -4 0 0 36 36 0 0 0 -28 0 4-4cylo.dat
0 BFC INVERTNEXT
1 16 0 0 -4 0 0 24 24 0 0 0 -23 0 4-4cylo.dat
1 16 0 0 -27 0 0 3 3 0 0 0 1 0 4-4ring8.dat
1 16 0 0 -4 0 0 4 4 0 0 0 -1 0 4-4ring6.dat
1 16 0 0 -4 0 0 28 28 0 0 0 -1 0 4-4edge.dat
1 16 0 0 -32 0 0 4 4 0 0 0 28 0 4-4con7.dat
1 16 0 0 -32 0 0 4 4 0 0 0 -1 0 4-4ring8.dat
1 16 0 0 -32 0 0 32 32 0 0 0 -1 0 4-4edge.dat

3 16 0 -38.201 -4 0 -36 -4 -7.16 -36 -4
4 16 0 -38.201 -4 -7.16 -36 -4 -9.5 -37.001 -4 -4.787 -37.898 -4
4 16 -14.062 -35.517 -4 -9.5 -37.001 -4 -7.16 -36 -4 -13.777 -33.26 -4
4 16 -14.062 -35.517 -4 -13.777 -33.26 -4 -20.394 -30.521 -4 -18.403 -33.476 -4
3 16 -18.403 -33.476 -4 -20.394 -30.521 -4 -22.454 -30.905 -4
4 16 -20.394 -30.521 -4 -25.456 -25.456 -4 -26.15 -27.848 -4 -22.454 -30.905 -4
4 16 -30.521 -20.394 -4 -29.434 -24.349 -4 -26.15 -27.848 -4 -25.456 -25.456 -4
4 16 -34.563 -16.265 -4 -32.254 -20.469 -4 -29.434 -24.349 -4 -30.521 -20.394 -4
4 16 -30.521 -20.394 -4 -33.26 -13.777 -4 -36.331 -11.805 -4 -34.563 -16.265 -4
4 16 -33.26 -13.777 -4 -36 -7.16 -4 -37.523 -7.158 -4 -36.331 -11.805 -4
4 16 -36 0 -4 -38.125 -2.399 -4 -37.523 -7.158 -4 -36 -7.16 -4
3 16 -38.125 -2.399 -4 -36 0 -4 -38.123 2.398 -4
1 16 0 0 -4 0 0 -36 -36 0 0 0 -1 0 1-4tang.dat
3 16 38.125 -2.398 -4 36 0 -4 36 -7.16 -4
4 16 38.125 -2.398 -4 36 -7.16 -4 36.331 -11.804 -4 37.522 -7.157 -4
4 16 34.564 -16.264 -4 36.331 -11.804 -4 36 -7.16 -4 33.26 -13.777 -4
4 16 34.564 -16.264 -4 33.26 -13.777 -4 30.521 -20.394 -4 32.254 -20.469 -4
3 16 32.254 -20.469 -4 30.521 -20.394 -4 29.433 -24.349 -4
4 16 30.521 -20.394 -4 25.456 -25.456 -4 26.151 -27.847 -4 29.433 -24.349 -4
4 16 20.394 -30.521 -4 22.453 -30.903 -4 26.151 -27.847 -4 25.456 -25.456 -4
4 16 20.394 -30.521 -4 13.777 -33.26 -4 9.501 -37 -4 14.063 -35.516 -4
4 16 13.777 -33.26 -4 7.16 -36 -4 4.788 -37.898 -4 9.501 -37 -4
4 16 0 -36 -4 .001 -38.201 -4 4.788 -37.898 -4 7.16 -36 -4
1 16 0 0 -4 36 0 0 0 0 -36 0 -1 0 1-4tang.dat
3 16 0 38.2 -4 0 36 -4 7.16 36 -4
4 16 0 38.2 -4 7.16 36 -4 9.499 36.999 -4 4.787 37.9 -4
4 16 14.062 35.518 -4 9.499 36.999 -4 7.16 36 -4 13.777 33.26 -4
4 16 14.062 35.518 -4 13.777 33.26 -4 20.394 30.521 -4 18.402 33.474 -4
3 16 18.402 33.474 -4 20.394 30.521 -4 22.453 30.905 -4
4 16 20.394 30.521 -4 25.456 25.456 -4 26.149 27.846 -4 22.453 30.905 -4
4 16 30.521 20.394 -4 29.434 24.35 -4 26.149 27.846 -4 25.456 25.456 -4
4 16 34.565 16.266 -4 32.252 20.468 -4 29.434 24.35 -4 30.521 20.394 -4
4 16 30.521 20.394 -4 33.26 13.777 -4 36.329 11.805 -4 34.565 16.266 -4
4 16 33.26 13.777 -4 36 7.16 -4 37.524 7.159 -4 36.329 11.805 -4
4 16 36 0 -4 38.124 2.399 -4 37.524 7.159 -4 36 7.16 -4
3 16 38.124 2.399 -4 36 0 -4 38.125 -2.398 -4
1 16 0 0 -4 0 0 36 36 0 0 0 -1 0 1-4tang.dat
3 16 -38.123 2.398 -4 -36 0 -4 -36 7.16 -4
4 16 -38.123 2.398 -4 -36 7.16 -4 -36.33 11.804 -4 -37.524 7.157 -4
4 16 -34.565 16.265 -4 -36.33 11.804 -4 -36 7.16 -4 -33.26 13.777 -4
4 16 -34.565 16.265 -4 -33.26 13.777 -4 -30.521 20.394 -4 -32.253 20.469 -4
3 16 -32.253 20.469 -4 -30.521 20.394 -4 -29.434 24.349 -4
4 16 -30.521 20.394 -4 -25.456 25.456 -4 -26.15 27.847 -4 -29.434 24.349 -4
4 16 -20.394 30.521 -4 -22.454 30.905 -4 -26.15 27.847 -4 -25.456 25.456 -4
4 16 -14.063 35.518 -4 -18.403 33.475 -4 -22.454 30.905 -4 -20.394 30.521 -4
4 16 -20.394 30.521 -4 -13.777 33.26 -4 -9.5 37 -4 -14.063 35.518 -4
4 16 -13.777 33.26 -4 -7.16 36 -4 -4.788 37.899 -4 -9.5 37 -4
4 16 0 36 -4 0 38.2 -4 -4.788 37.899 -4 -7.16 36 -4
1 16 0 0 -4 -36 0 0 0 0 36 0 -1 0 1-4tang.dat
4 16 20.394 -30.521 -4 14.062 -35.518 -4 18.404 -33.475 -4 22.453 -30.903 -4

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Philippe Hurbain [Philo]

initially submitted the part.

2021-02-15 17:05:01

Orion Pobursky [OrionP]

submitted a new version of the part.

2024-03-23 00:59:37

Update ring primitives via script. This will not reset the vote status of the part.

Gerald Lasser [GeraldLasser]

posted a vote of Hold.

2024-07-01 17:20:46

THiose
1 10 0 -4 0 0 2 2 0 0 0 -1 0 4-4ring18.dat
1 1 0 0 -4 0 0 38 38 0 0 0 -1 0 48\4-4aring.dat

overlap
the s01 subfiles

Rene Rechthaler [Blechtaler]

made the following comment.

2024-07-01 17:59:56

thats because there are 25 of the s01 subfiles to a 48 ring...
that would need an adapter.

Philippe Hurbain [Philo]

made the following comment.

2024-07-01 18:43:14

This is the way I intended it, as it is the most efficient way of doing it.

Gerald Lasser [GeraldLasser]

made the following comment.

2024-07-02 10:51:24

what about this to replace the 4-4ring18 and the 4-4aring?

3 16 -.00043 37.89913 -4 0 36 -4 7.1604 36 -4
4 16 -.00043 37.89913 -4 7.1604 36 -4 9.42482 36.70858 -4 4.74966 37.60202 -4
4 16 13.95167 35.23946 -4 9.42482 36.70858 -4 7.1604 36 -4 13.7772 33.2604 -4
4 16 13.95167 35.23946 -4 13.7772 33.2604 -4 20.394 30.5208 -4 18.25775 33.21144 -4
3 16 18.25775 33.21144 -4 20.394 30.5208 -4 22.27695 30.66276 -4
4 16 20.394 30.5208 -4 25.4556 25.4556 -4 25.94341 27.62758 -4 22.27695 30.66276 -4
4 16 30.5208 20.394 -4 29.20269 24.15916 -4 25.94341 27.62758 -4 25.4556 25.4556 -4
4 16 34.29314 16.13787 -4 31.99911 20.30751 -4 29.20269 24.15916 -4 30.5208 20.394 -4
4 16 30.5208 20.394 -4 33.2604 13.7772 -4 36.04386 11.71182 -4 34.29314 16.13787 -4
4 16 33.2604 13.7772 -4 36 7.1604 -4 37.2292 7.1025 -4 36.04386 11.71182 -4
4 16 36 0 -4 37.8242 2.3801 -4 37.2292 7.1025 -4 36 7.1604 -4
3 16 37.8242 2.3801 -4 36 0 -4 37.82578 -2.37919 -4
1 16 0 0 -4 0 0 36 36 0 0 0 -1 0 1-4tang.dat

Philippe Hurbain [Philo]

submitted a new version of the part.

2024-07-04 15:23:59

Indeed better this way...

Takeshi Takahashi [RainbowDolphin]

posted a vote of Certify.

2024-08-28 03:16:58

Gerald Lasser [GeraldLasser]

posted a vote of Certify.

2024-09-26 19:45:32

Orion Pobursky [OrionP]

posted a vote of Admin Review.
