File Detail parts/75542c01-f1.dat

Download Download zip file View patterns/composites/shortcuts

Official File parts/75542c01-f1.dat

Part Attributes: Base Part: 75542-f1.dat

Train Track 9V Point Left Straight with Yellow Lever

File Header:

0 Train Track  9V Point Left Straight with Yellow Lever
0 Name: 75542c01-f1.dat
0 Author: Steffen [Steffen]
0 !LDRAW_ORG Shortcut UPDATE 2025-08
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2025-08-23 [MagFors] corrected position of lever
0 !HISTORY 2025-08-24 [MagFors] renumbered from 2861c03
0 !HISTORY 2025-08-31 [OrionP] Official Update 2025-08

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 75542-f1.dat
1 14 -250 -24 170 1 0 0 0 .88064 -.47378 0 .47378 .88064 2866.dat

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Steffen [Steffen]

initially submitted the part.

2012-09-08 21:35:02

Steffen [Steffen]

made the following comment.

2012-09-09 22:00:24

cf. http://ebid.s3.amazonaws.com/upload_big/3/8/4/1322915564-327-11.jpg

[PTadmin]

renamed the part.

2012-09-10 09:53:14

"parts/2861c01.dat" to "parts/2861c03.dat."

Donald Sutter [technog]

made the following comment.

2013-04-06 21:25:07

I do not believe the turnout is to the correct dimensions, needs farther investigation by others.
I have constructed several test track layouts in real world that could not be replicated in LDraw without overlap or misalignment.

Takeshi Takahashi [RainbowDolphin]

posted a vote of Certify.

2021-02-22 12:55:02

Shall we go ahead with this part, if no major flaws are found?
This part are sitting here with no progress for almost 8 years.

Takeshi Takahashi [RainbowDolphin]

posted a vote of Certify.

2021-02-22 12:55:02

Shall we go ahead with this part, if no major flaws are found?
This part are sitting here with no progress for almost 8 years.

Gerald Lasser [GeraldLasser]

made the following comment.

2024-05-28 08:41:27

Concerning the naming, wouldn't that be a -f1 -f2 part?

Nils Schmidt [BlackBrick89]

posted a vote of Certify.

2024-06-07 20:25:16

I second Gerald's suggestion for renaming.
This shortcut is similar to 70028-f1 and 70028-f2 and usually you don't replace 2866 with another part (which leads to a variant of 2861cXX).
This is a "shortcuts with more than one physical configuration".
I would like to certify and let the admin do the renaming...

Javier Orquera [kuramapika1]

made the following comment.

2025-02-12 22:47:22

Part 2866 have a wrong translation/position.

Gerald Lasser [GeraldLasser]

posted a vote of Hold.

2025-02-16 13:56:03

Floating 2866

Gerald Lasser [GeraldLasser]

made the following comment.

2025-08-12 07:52:26

the 2866 is stil not entirely at its correct position

Gerald Lasser [GeraldLasser]

made the following comment.

2025-08-21 10:23:16

Part 2866 is too high and intersects with 2864.

Part 2866 needs to be lowered by 2 LDU and rotated only by 28,28 deg to not intersect
1 14 -250 -24 -170 1 0 0 0 .88064 .47378 0 -.47378 .88064 2866.dat

It will still intersect with 2864, but that needs to be addressed in 2864

Magnus Forsberg [MagFors]

submitted a new version of the part.

2025-08-23 14:40:16

Gerald Lasser [GeraldLasser]

posted a vote of Certify.

2025-08-23 16:30:48

Takeshi Takahashi [RainbowDolphin]

posted a vote of Certify.

2025-08-23 16:38:59

Orion Pobursky [OrionP]

posted a vote of Admin Review.

2025-08-24 15:15:21

Magnus Forsberg [MagFors]

renamed the part.

2025-08-24 21:36:28

"parts/2861c03.dat" to "parts/75542c01-f1.dat"

Magnus Forsberg [MagFors]

edited the part header.

2025-08-24 21:37:36

Header Edits

history:
0 !HISTORY 2025-08-23 [MagFors] corrected position of lever
to
0 !HISTORY 2025-08-23 [MagFors] corrected position of lever 0 !HISTORY 2025-08-24 [MagFors] renumbered from 2861c03
description:
Train Track 9V Point Left Straight (Complete)
to
Train Track 9V Point Left Straight with Yellow Lever

Orion Pobursky [OrionP]

2025-08-31 02:18:23

Release 2025-08

Creative Commons Attribution License information

This part is copyright © Steffen
Licensed under CC BY 4.0

Edits:
LDraw.org Parts Tracker, Magnus Forsberg, Orion Pobursky,
