0 Brick 1 x 1 with Blue "0" (Numeric) Pattern
0 Name: 3005pt0.dat
0 Author: Tore Eriksson [Tore_Eriksson]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !KEYWORDS Rebrickable 3005pr9992, Set 237
0 !HISTORY 2003-06-08 [jriley] BFC compliant
0 !HISTORY 2004-03-16 [westrate] added ring primitives
0 !HISTORY 2004-09-15 [PTadmin] Official Update 2004-03
0 !HISTORY 2007-05-11 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2020-06-04 [Sirio] Updated the use of primitives: removed ringr.dat or ringrr.dat, removed overlapping
