File Detail parts/32074c02.dat

Download Download zip file View patterns/composites/shortcuts

Official File parts/32074c02.dat

Part Attributes: Base Part: 32074.dat

~Technic Competition Cannon with Round Bottom without Trigger

File Header:

0 ~Technic Competition Cannon with Round Bottom without Trigger
0 Name: 32074c02.dat
0 Author: Sylvain Sauvage [SLS]
0 !LDRAW_ORG Shortcut UPDATE 2024-08
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2024-09-13 [MagFors] Moved spring to assembly
0 !HISTORY 2024-09-30 [OrionP] Official Update 2024-08
