Plate 1 x 1 x 0.667 Half Round with Open Side Stud

File Header:

0 Plate  1 x  1 x  0.667 Half Round with Open Side Stud
0 Name: 3386.dat
0 Author: Magnus Forsberg [MagFors]
0 !LDRAW_ORG Part UPDATE 2024-02
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2024-03-24 [OrionP] Official Update 2024-02

Show contents

1 16 0 16 0 6 0 0 0 -1 0 0 0 6 2-4ndis.dat
1 16 0 16 0 10 0 0 0 -1 0 0 0 10 1-8chrd.dat
1 16 0 16 0 0 0 10 0 -1 0 10 0 0 1-8chrd.dat
1 16 0 16 0 -10 0 0 0 -1 0 0 0 10 1-8chrd.dat
1 16 0 16 0 0 0 -10 0 -1 0 10 0 0 1-8chrd.dat
4 16 10 16 0 6 16 0 6 16 6 7.071 16 7.071
4 16 0 16 10 7.071 16 7.071 6 16 6 0 16 6
4 16 0 16 10 0 16 6 -6 16 6 -7.071 16 7.071
4 16 -7.071 16 7.071 -6 16 6 -6 16 0 -10 16 0
2 24 10 16 -10 -10 16 -10

4 16 -10 16 -10 -10 16 0 -6 16 0 -6 16 -6
4 16 10 16 -10 -10 16 -10 -6 16 -6 6 16 -6
4 16 10 16 0 10 16 -10 6 16 -6 6 16 0
0 BFC INVERTNEXT
1 16 0 16 -3 0 0 6 0 -14 0 3 0 0 box3u5p.dat
0 BFC INVERTNEXT
1 16 0 2 0 6 0 0 0 14 0 0 0 6 2-4cylc.dat
1 16 0 6 -6 0 0 4 4 0 0 0 -1 0 4-4ndis.dat
4 16 4 10 -6 4 2 -6 6 2 -6 6 16 -6
4 16 -4 10 -6 4 10 -6 6 16 -6 -6 16 -6
4 16 -4 10 -6 -6 16 -6 -6 2 -6 -4 2 -6
2 24 6 16 -6 -6 16 -6

0 BFC INVERTNEXT
1 16 0 6 -6 0 0 4 4 0 0 0 -4 0 4-4cyli.dat
1 16 0 6 -10 0 0 6 6 0 0 0 1 0 4-4edge.dat
1 16 0 6 -6 0 0 4 4 0 0 0 1 0 4-4edge.dat
1 16 0 6 -10 0 0 6 6 0 0 0 1 0 4-4ndis.dat
1 16 0 6 -10 0 0 1 1 0 0 0 1 0 stud2a.dat
4 16 10 0 -10 6 0 -10 6 12 -10 10 16 -10
4 16 -10 16 -10 10 16 -10 6 12 -10 -6 12 -10
4 16 -10 16 -10 -6 12 -10 -6 0 -10 -10 0 -10

1 16 0 0 0 10 0 0 0 16 0 0 0 10 2-4cylc.dat
1 16 0 16 -5 0 0 10 0 -16 0 5 0 0 box3u5p.dat
1 16 0 0 0 0 0 1 0 1 0 -1 0 0 stud.dat

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Magnus Forsberg [MagFors]

initially submitted the part.

2023-01-01 10:00:02

New part in upcomming 2023 Speed Champions sets.

Philippe Hurbain [Philo]

made the following comment.

2023-01-01 13:25:01

Magnus shot first (was building it ;) )
From the description I think that side stud is fully open to receive a bar.
Here is my code...
1 16 0 0 0 10 0 0 0 16 0 0 0 10 2-4cylo.dat
0 BFC INVERTNEXT
1 16 0 2 0 6 0 0 0 14 0 0 0 6 2-4cylo.dat
0 BFC INVERTNEXT
1 16 0 16 -3 0 0 6 0 -14 0 3 0 0 box3u5p.dat
1 16 0 0 0 0 0 1 0 1 0 -1 0 0 stud.dat
1 16 0 6 -10 0 0 1 1 0 0 0 1 0 stud2a.dat

1 16 0 16 -5 0 0 10 0 -16 0 5 0 0 box3u5p.dat
1 16 0 6 -10 0 0 6 6 0 0 0 1 0 4-4edge.dat
1 16 0 6 -10 0 0 6 6 0 0 0 1 0 4-4ndis.dat
1 16 0 6 -6 0 0 4 4 0 0 0 1 0 4-4edge.dat
1 16 0 6 -6 0 0 4 4 0 0 0 -1 0 4-4ndis.dat
4 16 6 16 -6 4 10 -6 4 2 -6 6 2 -6
4 16 -6 16 -6 -6 2 -6 -4 2 -6 -4 10 -6
4 16 6 16 -6 -6 16 -6 -4 10 -6 4 10 -6
2 24 -6 16 -6 6 16 -6
0 BFC INVERTNEXT
1 16 0 6 -6 0 0 4 4 0 0 0 -4 0 4-4cyli.dat
4 16 10 0 -10 6 0 -10 6 12 -10 10 16 -10
4 16 -10 16 -10 10 16 -10 6 12 -10 -6 12 -10
4 16 -10 0 -10 -10 16 -10 -6 12 -10 -6 0 -10
2 24 -10 16 -10 10 16 -10
4 16 10 16 -10 6 16 -6 6 16 0 10 16 0
4 16 6 16 -6 10 16 -10 -10 16 -10 -6 16 -6
4 16 -6 16 -6 -10 16 -10 -10 16 0 -6 16 0
1 16 0 16 0 10 0 0 0 -1 0 0 0 10 1-8chrd.dat
1 16 0 16 0 0 0 10 0 -1 0 10 0 0 1-8chrd.dat
1 16 0 16 0 -10 0 0 0 -1 0 0 0 10 1-8chrd.dat
1 16 0 16 0 0 0 -10 0 -1 0 10 0 0 1-8chrd.dat
1 16 0 16 0 6 0 0 0 -1 0 0 0 6 2-4ndis.dat
4 16 -6 16 0 -10 16 0 -7.071 16 7.071 -6 16 6
4 16 0 16 6 -6 16 6 -7.071 16 7.071 0 16 10
4 16 6 16 6 0 16 6 0 16 10 7.071 16 7.071
4 16 6 16 0 6 16 6 7.071 16 7.071 10 16 0
1 16 0 0 0 10 0 0 0 1 0 0 0 10 2-4chrd.dat
1 16 0 2 0 6 0 0 0 -1 0 0 0 6 2-4chrd.dat

Note that bottom is much more triangle efficient compared to two rings!

Magnus Forsberg [MagFors]

made the following comment.

2023-01-01 14:15:01

I'll use your bottom surface, when we know if the hole is open...

Gerald Lasser [GeraldLasser]

made the following comment.

2023-01-09 16:30:02

according to the reviews and Designer interviews (Racingbrick) the hole is open

Magnus Forsberg [MagFors]

submitted a new version of the part.

2023-01-09 17:10:01

Still not fully convinced, but they keep saying we can put bars in the hole...

Existing certification-votes were deleted.
