Unofficial File parts/41749.dat
Part Attributes:
File Header:
0 Slope Brick Round 3 x 8 x 2 Right
0 Name: 41749.dat
0 Author: Brent Jackson [bjackson]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 2.0 and CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !KEYWORDS curved, Open, wedge
0 !HISTORY 2004-09-15 [PTadmin] Official Update 2004-03
0 !HISTORY 2007-07-04 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2020-09-02 [ejboer] Subparted from 41749 for patterns, changed keywords
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\41749s01.dat
1 16 0 0 0 0 0 1 0 1 0 -1 0 0 stug-1x2.dat
4 16 -50 20 -20 -10 0 -20 -10 0 20 -50 20 20
3 16 -10 0 -20 -50 20 -20 -10 2 -40
3 16 -10 2 -40 -50 20 -20 -50 21.5403 -40
3 16 -10 2 -40 -50 21.5403 -40 -10 6 -60
3 16 -10 6 -60 -50 21.5403 -40 -50 26.1075 -60
3 16 -10 6 -60 -50 26.1075 -60 -10 12 -80
3 16 -10 12 -80 -50 26.1075 -60 -50 33.6299 -80
3 16 -10 12 -80 -50 33.6299 -80 -10 20 -100
3 16 -10 20 -100 -50 33.6299 -80 -50 44 -100
3 16 -10 20 -100 -50 44 -100 -10 32 -120
3 16 -10 32 -120 -50 44 -100 -10 44 -140
Status:
Needs More Votes (F)
This part has the following automated holds from the Parts Tracker
-
Has uncertified subfiles
This part has the following errors
- All parts are required to be CC BY 4.0
Current Votes:
None
Official parents and subparts
Part Events:
Archived Part Events:
None
Added stud group
Updated for changed subpart
Quick adjustment for new subfile, will propably need some work
2021-02-19 15:45:01
2022-09-20 15:35:01
2024-01-14 13:26:18
I think this quad:
4 16 -50 20 -20 -50 21.5403 -40.88 -10 1.2919 -42.1468 -10 0 -20
should be splitted into two triangles as well:
3 16 -50 20 -20 -50 21.5403 -40.88 -10 1.2919 -42.1468
3 16 -10 1.2919 -42.1468 -10 0 -20 -50 20 -20
Same for 41750 and s01 need an extra cond then:
5 24 -50 20 -20 -10 1.2919 -42.1468 -50 21.5403 -40.88 -10 0 -20
4 16 -50 20 -20 -50 21.5403 -40.88 -10 1.2919 -42.1468 -10 0 -20
should be splitted into two triangles as well:
3 16 -50 20 -20 -50 21.5403 -40.88 -10 1.2919 -42.1468
3 16 -10 1.2919 -42.1468 -10 0 -20 -50 20 -20
Same for 41750 and s01 need an extra cond then:
5 24 -50 20 -20 -10 1.2919 -42.1468 -50 21.5403 -40.88 -10 0 -20
2024-09-12 07:18:16
the quad mentionned by Max is below specs threshold, but indeed the condline is not shown under some viewing angles, so the suggested split would be nice
The LDD version follows a different curve. This need to be rewritten.
The LDD version is not THAT different, but top curve should match 46413, and bottom curve should match 42022, and they don't. Not sure which part(s) is correct and which is not... this can be a can of worms!
2024-09-12 15:41:34
2024-09-12 15:52:36
Ouch. Even worse than expected. Do we have a full list of parts that_should_match_but_don't (top and bottom curvatures)?
2024-09-12 15:58:18
I don't even want to think about it... patterns, stickers etc...
2024-09-12 16:30:04
Yeah, few patterns/stickers for this one, but awful for slopes with curved tops :(
2024-11-25 14:57:22
yeah i think
speaking of slopes i need to do something about 6192
speaking of slopes i need to do something about 6192
Changed the curves to match 46413 and 42022. I know this breaks the patterned/stickered parts, will fix them as well.
If curves need to change again, happy to do so.
If curves need to change again, happy to do so.
2025-06-08 10:50:42
needs rewrite
