Plate 14 x 18 x 1 Hexagonal with Three Pinholes at Centre

File Header:

0 Plate 14 x 18 x  1 Hexagonal with Three Pinholes at Centre
0 Name: 44666.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Part UPDATE 2025-03
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2024-09-30 [OrionP] Official Update 2024-08
0 !HISTORY 2025-03-26 [OrionP] Fix incorrect color usage
0 !HISTORY 2025-03-30 [OrionP] Official Update 2025-03
