0 Wheel 16 x 75 Motorcycle Solid
0 Name: 46334.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Part UPDATE 2024-08
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS Fat Boy, Harley Davidson, Set 10269

0 !HISTORY 2024-09-30 [OrionP] Official Update 2024-08

Show contents

1 16 0 0 -10 0 0 1 1 0 0 0 20 0 axl3hole.dat

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\46334s01.dat
1 16 0 0 0 .5 -.86603 0 .86603 .5 0 0 0 1 s\46334s01.dat
1 16 0 0 0 -.5 -.86603 0 .86603 -.5 0 0 0 1 s\46334s01.dat
1 16 0 0 0 -1 0 0 0 -1 0 0 0 1 s\46334s01.dat
1 16 0 0 0 -.5 .86603 0 -.86603 -.5 0 0 0 1 s\46334s01.dat
1 16 0 0 0 .5 .86603 0 -.86603 .5 0 0 0 1 s\46334s01.dat

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\46334s04.dat
1 16 0 0 0 -1 0 0 0 -1 0 0 0 1 s\46334s04.dat

0 // CEntre Axelhole Back Side
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\46334s05.dat
1 16 0 0 0 -1 0 0 0 -1 0 0 0 1 s\46334s05.dat
1 16 0 0 0 -.5 .86603 0 -.86603 -.5 0 0 0 1 s\46334s05.dat
1 16 0 0 0 .5 .86603 0 -.86603 .5 0 0 0 1 s\46334s05.dat

1 16 -17.3206 10 8 3 0 -5.19618 5.19618 0 3 0 -1 0 4-4edge.dat
1 16 -17.3206 10 8 1 0 -1.73206 1.73206 0 1 0 -1 0 2-4ring3.dat
1 16 -17.3206 10 8 1 0 1.73206 1.73206 0 -1 0 -1 0 5-16rin3.dat
1 16 -17.3206 10 8 -3 0 5.19618 -5.19618 0 -3 0 -1 0 3-16tndis.dat

0 BFC INVERTNEXT
1 16 -17.3206 10 10 4 0 -6.92824 6.92824 0 4 0 -2 0 2-4cylo.dat
0 BFC INVERTNEXT
1 16 -17.3206 10 10 4 0 6.92824 6.92824 0 -4 0 -2 0 5-16cylo.dat
1 16 -17.3206 10 10 4 0 6.92824 6.92824 0 -4 0 -1 0 1-8tndis.dat
1 16 -17.3206 10 10 6.92824 0 -4 -4 0 -6.92824 0 -1 0 1-16tndis.dat
1 16 -17.3206 10 10 6.92824 0 4 -4 0 6.92824 0 -1 0 1-8tndis.dat
3 16 -7.56396 10.898958504 10 -8.421641496 14.09984 10 -9.593241496 12.070558504 10
3 16 -12.450399064 3.652962552 8 -13.667949298 5.239721914 8 -15.519849298 2.03212 8
3 16 -15.519849298 2.03212 8 -20.3206 4.80382 8 -21.3206 3.07176 8

0 // Peghole and Padding
1 16 -17.3206 -10 8 3 0 -5.19618 -5.19618 0 -3 0 -1 0 4-4edge.dat
1 16 -17.3206 -10 8 1 0 -1.73206 -1.73206 0 -1 0 -1 0 2-4ring3.dat
1 16 -17.3206 -10 8 1 0 1.73206 -1.73206 0 1 0 -1 0 5-16rin3.dat
1 16 -17.3206 -10 8 -3 0 5.19618 5.19618 0 3 0 -1 0 3-16tndis.dat

0 BFC INVERTNEXT
1 16 -17.3206 -10 10 4 0 -6.92824 -6.92824 0 -4 0 -2 0 2-4cylo.dat
0 BFC INVERTNEXT
1 16 -17.3206 -10 10 4 0 6.92824 -6.92824 0 4 0 -2 0 5-16cylo.dat
1 16 -17.3206 -10 10 4 0 6.92824 -6.92824 0 4 0 -1 0 1-8tndis.dat
1 16 -17.3206 -10 10 6.92824 0 -4 4 0 6.92824 0 -1 0 1-16tndis.dat
1 16 -17.3206 -10 10 6.92824 0 4 4 0 -6.92824 0 -1 0 1-8tndis.dat
3 16 -8.421641496 -14.09984 10 -7.56396 -10.898958504 10 -9.593241496 -12.070558504 10
3 16 -13.667949298 -5.239721914 8 -12.450399064 -3.652962552 8 -15.519849298 -2.03212 8
3 16 -20.3206 -4.80382 8 -15.519849298 -2.03212 8 -21.3206 -3.07176 8

4 16 -21.3206 -3.07176 10 -21.3206 -3.0718 8 -21.3206 3.0718 8 -21.3206 3.0718 10
4 16 -22.4881 1.1458 10 -22.4881 -1.1458 10 -21.3206 -3.07176 10 -21.3206 3.0718 10
3 16 -23.6339 -.0001 10 -22.4881 -1.1458 10 -22.4881 1.1458 10

2 24 -13.3206 -3.2239 10 -13.3206 3.2239 10
2 24 -13.3206 -3.2239 8 -13.3206 3.2239 8

4 16 -13.3206 3.2239 8 -13.3206 -3.2239 8 -13.3206 -3.2239 10 -13.3206 3.2239 10
4 16 -13.3206 -3.2239 10 -12.4504 -3.653 10 -12.4504 3.653 10 -13.3206 3.2239 10
4 16 -12.4504 3.653 10 -12.4504 -3.653 10 -11.9232 -3.3486 10 -11.9232 3.3486 10
4 16 -12.4504 3.653 8 -13.3206 3.2239 8 -13.3206 3.2239 10 -12.4504 3.653 10
4 16 -13.3206 -3.2239 10 -13.3206 -3.2239 8 -12.4504 -3.653 8 -12.4504 -3.653 10
4 16 -15.5198 2.0321 8 -15.5198 -2.0321 8 -13.3206 -3.2239 8 -13.3206 3.2239 8
4 16 -15.5198 2.0321 8 -21.3206 3.0718 8 -21.3206 -3.0718 8 -15.5198 -2.0321 8
3 16 -11.9232 3.3486 10 -11.9232 -3.3486 10 -6 0 10
3 16 -6 0 10 -11.9232 -3.3486 10 -10.3924 -6 10
3 16 -10.3924 6 10 -11.9232 3.3486 10 -6 0 10
2 24 -13.3206 3.2239 10 -12.4504 3.653 10
2 24 -13.3206 3.2239 10 -13.3206 3.2239 8
2 24 -13.3206 3.2239 8 -12.4504 3.653 8
2 24 -13.3206 -3.2239 8 -13.3206 -3.2239 10
2 24 -13.3206 -3.2239 8 -12.4504 -3.653 8
2 24 -13.3206 -3.2239 10 -12.4504 -3.653 10
2 24 -21.3206 3.0718 8 -21.3206 3.0718 10
2 24 -21.3206 3.0718 8 -21.3206 -3.0718 8
2 24 -21.3206 3.0718 10 -21.3206 -3.0718 10
2 24 -21.3206 -3.0718 8 -21.3206 -3.0718 10
3 16 6 0 10 10.3924 -6 10 10.3924 6 10
4 16 13.2208 -1.101 10 13.2208 1.101 10 10.3924 6 10 10.3924 -6 10
3 16 -11.817 20.4676 10 -12.2364 18.9023 10 -8.4216 14.0998 10
3 16 -8.4216 14.0998 10 -12.2364 18.9023 10 -13.3206 16.9282 10
3 16 -13.3206 -16.9282 10 -12.2364 -18.9023 10 -8.4216 -14.0998 10
3 16 -8.4216 -14.0998 10 -12.2364 -18.9023 10 -8 -14.3432 10
3 16 -8 -14.3432 10 -12.2364 -18.9023 10 -11.817 -20.4676 10
4 16 -7.564 -10.899 10 -8.4216 -14.0998 10 -8 -14.3432 10 -5.6568 -12 10
