Official File parts/6148328r.dat
Part Attributes:
File Header:
0 Sticker 1.8 x 3.8 with Black Halftone Stripes on White Background (Needs Work)
0 Name: 6148328r.dat
0 Author: Massimo Maso [Sirio]
0 !LDRAW_ORG Part UPDATE 2024-05
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 !HELP Needs work: halftone stripes are approximate because no high-resolution images are available
0 BFC CERTIFY CCW
0 !KEYWORDS 917K, 919, Bricklink 75876stk01, Brickowl 852010, Hybrid, Pit Lane
0 !KEYWORDS Rebrickable 26357, set 75876, Speed Champions
0 !HISTORY 2024-06-30 [OrionP] Official Update 2024-05
Show contents
0 // Textures
0 !TEXMAP START PLANAR -38 0 6.8 38 0 6.8 -38 0 2.8 6148328r.png
0 !: 4 15 -38 -.25 6.8 -38 -.25 2.8 38 -.25 2.8 38 -.25 6.8
0 !TEXMAP FALLBACK
4 72 -38 -.25 6.8 -38 -.25 2.8 38 -.25 2.8 38 -.25 6.8
0 !TEXMAP END
0 !TEXMAP START PLANAR -38 0 2 38 0 2 -38 0 -2 6148328r.png
0 !: 4 15 -38 -.25 2 -38 -.25 -2 38 -.25 -2 38 -.25 2
0 !TEXMAP FALLBACK
4 72 -38 -.25 2 -38 -.25 -2 38 -.25 -2 38 -.25 2
0 !TEXMAP END
0 !TEXMAP START PLANAR -38 0 -2.8 38 0 -2.8 -38 0 -6.8 6148328r.png
0 !: 4 15 -38 -.25 -2.8 -38 -.25 -6.8 38 -.25 -6.8 38 -.25 -2.8
0 !TEXMAP FALLBACK
4 72 -38 -.25 -2.8 -38 -.25 -6.8 38 -.25 -6.8 38 -.25 -2.8
0 !TEXMAP END
0 // Primitives
1 16 -36.5 0 16.5 -1.5 0 0 0 -1 0 0 0 1.5 1-4chrd.dat
1 16 36.5 0 16.5 1.5 0 0 0 -1 0 0 0 1.5 1-4chrd.dat
1 16 0 -.25 0 36.5 0 0 0 .25 0 0 0 18 box3u12.dat
1 16 -36.5 0 -16.5 -1.5 0 0 0 -1 0 0 0 -1.5 1-4chrd.dat
1 16 36.5 0 -16.5 1.5 0 0 0 -1 0 0 0 -1.5 1-4chrd.dat
1 16 -36.5 0 16.5 -1.5 0 0 0 -.25 0 0 0 1.5 1-4cyli.dat
1 16 36.5 0 16.5 1.5 0 0 0 -.25 0 0 0 1.5 1-4cyli.dat
1 16 -36.5 0 -16.5 -1.5 0 0 0 -.25 0 0 0 -1.5 1-4cyli.dat
1 16 36.5 0 -16.5 1.5 0 0 0 -.25 0 0 0 -1.5 1-4cyli.dat
1 15 -36.5 -.25 16.5 -1.5 0 0 0 1 0 0 0 1.5 1-4chrd.dat
1 15 36.5 -.25 16.5 1.5 0 0 0 1 0 0 0 1.5 1-4chrd.dat
1 15 -36.5 -.25 -16.5 -1.5 0 0 0 1 0 0 0 -1.5 1-4chrd.dat
1 15 36.5 -.25 -16.5 1.5 0 0 0 1 0 0 0 -1.5 1-4chrd.dat
0 // Bottom faces
4 16 -36.5 0 18 -36.5 0 -18 -38 0 -16.5 -38 0 16.5
4 16 36.5 0 18 38 0 16.5 38 0 -16.5 36.5 0 -18
0 // Lateral faces
3 16 -38 0 16.5 -38 -.25 6.8 -38 -.25 16.5
3 16 -38 0 16.5 -38 -.25 2.8 -38 -.25 6.8
3 16 -38 0 16.5 -38 -.25 2 -38 -.25 2.8
4 16 -38 0 16.5 -38 0 -16.5 -38 -.25 -2 -38 -.25 2
3 16 -38 0 -16.5 -38 -.25 -2.8 -38 -.25 -2
3 16 -38 0 -16.5 -38 -.25 -6.8 -38 -.25 -2.8
3 16 -38 0 -16.5 -38 -.25 -16.5 -38 -.25 -6.8
3 16 38 0 16.5 38 -.25 16.5 38 -.25 6.8
3 16 38 0 16.5 38 -.25 6.8 38 -.25 2.8
3 16 38 0 16.5 38 -.25 2.8 38 -.25 2
4 16 38 0 16.5 38 -.25 2 38 -.25 -2 38 0 -16.5
3 16 38 0 -16.5 38 -.25 -2 38 -.25 -2.8
3 16 38 0 -16.5 38 -.25 -2.8 38 -.25 -6.8
3 16 38 0 -16.5 38 -.25 -6.8 38 -.25 -16.5
0 // Top faces
4 15 -38 -.25 16.5 38 -.25 16.5 36.5 -.25 18 -36.5 -.25 18
4 15 -38 -.25 16.5 -38 -.25 6.8 38 -.25 6.8 38 -.25 16.5
4 15 -38 -.25 2.8 -38 -.25 2 38 -.25 2 38 -.25 2.8
4 15 -38 -.25 -2 -38 -.25 -2.8 38 -.25 -2.8 38 -.25 -2
4 15 -38 -.25 -16.5 38 -.25 -16.5 38 -.25 -6.8 -38 -.25 -6.8
4 15 -38 -.25 -16.5 -36.5 -.25 -18 36.5 -.25 -18 38 -.25 -16.5
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
2022-09-29 22:25:01
[PTadmin]
edited the part header.
2023-01-04 16:00:01
2023-01-04 16:05:01
2024-06-19 14:06:19
2024-06-19 20:46:03
2024-06-30 00:13:24
Release 2024-05
