Official File parts/6578c01.dat
Part Attributes:
Base Part: 6578.dat
File Header:
0 Tyre 14/ 36 x 20 VR (Deformed to 10/ 67 x 24)
0 Name: 6578c01.dat
0 Author: Ulrich Röder [UR]
0 !LDRAW_ORG Part UPDATE 2023-06
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2023-11-19 [OrionP] Official Update 2023-06
Show contents
0 // Fitted on Wheel 2.8 x 34 with 8 Spokes 4489
0 // Technic Wedge Belt Wheel 4185 snap inside the Rim of the Tyre
0 // To de/-activate the Tire's 3D Type Label, write/delete >>0 // << of the first two Lines
1 16 0 0 0 -1 0 0 0 1 0 0 0 -1 s\6578c01s02.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\6578c01s02.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\6578c01s01.dat
1 16 0 0 0 0 -1 0 1 0 0 0 0 1 s\6578c01s01.dat
1 16 0 0 0 -1 0 0 0 -1 0 0 0 1 s\6578c01s01.dat
1 16 0 0 0 0 1 0 -1 0 0 0 0 1 s\6578c01s01.dat
1 16 0 0 0 1 0 0 0 -1 0 0 0 -1 s\6578c01s01.dat
1 16 0 0 0 0 -1 0 -1 0 0 0 0 -1 s\6578c01s01.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 -1 s\6578c01s01.dat
1 16 0 0 0 0 1 0 1 0 0 0 0 -1 s\6578c01s01.dat
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
2018-10-04 21:10:01
2018-10-13 17:15:01
2018-10-14 13:40:02
Is the c01 suffix the right choice here?
Isn't this more similar to the minifig suitcase, clamshell and book?
The same part, but in a different form/shape.
Isn't this more similar to the minifig suitcase, clamshell and book?
The same part, but in a different form/shape.
-f1?
...activated Label to connect the label dependencie
Existing certification-votes were deleted.
...activated Label to connect the label dependencie
Existing certification-votes were deleted.
2020-01-30 06:45:01
2020-01-30 06:55:02
2020-02-03 21:20:02
This description doesn't follow the suggestion from Chris.
"... with a description something like 'Tyre 14/ 36 x 20 VR (Deformed to XX/YYY x 20)', where XX and YYY are the new width (in mm) and new profile as a %age of the width."
But I think the rim diameter has to be changed too. It's also been stretched, and is bigger than 20mm.
My calculations give this description: Tyre 14/ 36 x 20 VR (Deformed to 10/ 67 x 24)
"... with a description something like 'Tyre 14/ 36 x 20 VR (Deformed to XX/YYY x 20)', where XX and YYY are the new width (in mm) and new profile as a %age of the width."
But I think the rim diameter has to be changed too. It's also been stretched, and is bigger than 20mm.
My calculations give this description: Tyre 14/ 36 x 20 VR (Deformed to 10/ 67 x 24)
all right - now I understand ...
just taken it over as suggested.
thanks Magnus
Existing certification-votes were deleted.
just taken it over as suggested.
thanks Magnus
Existing certification-votes were deleted.
2020-02-06 20:35:01
2020-10-07 06:30:02
2023-08-20 15:51:37
2023-08-20 15:52:12
I'd like to see the wheel assembly submitted as well
Actually, I think a !HELP statement on this part and the wheel assembly need to be done before this part is released.
2023-08-20 15:55:16
2023-08-20 15:56:19
I put this part on administrative hold instead of a "Hold" vote because it's otherwise good to release.
2023-11-19 03:08:44
Release 2023-06
