Official File parts/66956.dat
Part Attributes:
File Header:
0 Slope Brick Curved 2 x 2 with Double Cutout
0 Name: 66956.dat
0 Author: Massimo Maso [Sirio]
0 !LDRAW_ORG Part UPDATE 2023-04
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2020-08-03 [Sirio] File preparation for LDraw
0 !HISTORY 2023-08-25 [OrionP] Official Update 2023-04
Show contents
0 // Subpart
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\66956s01.dat
0 // Patternable faces
4 16 20 -16 20 -20 -16 20 -20 -15.6524 12.616 20 -15.6524 12.616
4 16 20 -15.6524 12.616 -20 -15.6524 12.616 -20 -14.6036 5.36 20 -14.6036 5.36
3 16 -20 -14.6036 5.36 -20 -13.2852 0 -18.352 -12.8827 -1.648
4 16 20 -14.6036 5.36 -20 -14.6036 5.36 -18.352 -12.8827 -1.648 18.352 -12.8827 -1.648
3 16 20 -13.2852 0 20 -14.6036 5.36 18.352 -12.8827 -1.648
4 16 18.352 -12.8827 -1.648 -18.352 -12.8827 -1.648 -11.716 -10.5099 -8.284 11.716 -10.5099 -8.284
4 16 11.716 -10.5099 -8.284 -11.716 -10.5099 -8.284 -5.564 -7.5316 -14.436 5.564 -7.5316 -14.436
3 16 5.564 -7.5316 -14.436 -5.564 -7.5316 -14.436 0 -4 -20
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
2020-09-09 18:30:02
The image below clearly shows that the tip square doesn't touch the stud, it's size is just the same as plate side wall.
https://1.bp.blogspot.com/-b_MGBIppWU4/X_F-caRqTTI/AAAAAAAATEc/e7A8U4d-Vi4bwRJoZGOaqjiG9d9jHIHcgCLcBGAsYHQ/s1800/66956-lego-2x2-pointed-wedge-moc-trio-church-knight-star-wars-barc-pile.jpg
https://1.bp.blogspot.com/-b_MGBIppWU4/X_F-caRqTTI/AAAAAAAATEc/e7A8U4d-Vi4bwRJoZGOaqjiG9d9jHIHcgCLcBGAsYHQ/s1800/66956-lego-2x2-pointed-wedge-moc-trio-church-knight-star-wars-barc-pile.jpg
2021-01-09 14:50:02
2021-01-17 20:50:02
2022-02-01 20:45:02
2022-11-17 21:00:01
2023-08-20 02:54:55
2023-08-25 01:30:54
Release 2023-04
Creative Commons Attribution License information
This part is copyright © Massimo Maso
Licensed under CC BY 4.0
Edits:
LDraw.org Parts Tracker,
Orion Pobursky,
3D View
