0 Tyre 28/ 57 x 43 Off Road
0 Name: 69909.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Part UPDATE 2024-02
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS 75.1 x 28, Buggy, Knob, Set 42124

0 !HISTORY 2023-10-31 [OrionP] Official Update 2023-05
0 !HISTORY 2024-03-23 [OrionP] Updated ring primitives
0 !HISTORY 2024-03-24 [OrionP] Official Update 2024-02
