0 Technic Panel Curved  3 x  2 x  1
0 Name: 71682.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Part UPDATE 2023-05
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2022-07-24 [jb70] Using subfile s\71682s01.dat
0 !HISTORY 2023-10-31 [OrionP] Official Update 2023-05

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\71682s01.dat
4 16 9 0 -30 9 0 30 8.336 -8.558 30 8.336 -8.558 -30
4 16 8.336 -8.558 -30 8.336 -8.558 30 6.365 -16.971 30 6.365 -16.971 -30
4 16 6.365 -16.971 -30 6.365 -16.971 30 3.121 -25.096 30 3.121 -25.096 -30
4 16 3.121 -25.096 -30 3.121 -25.096 30 1.228 -28.351 30 1.228 -28.351 -30
