Official File parts/74747.dat
Part Attributes:
File Header:
0 Train Track 9V Curved
0 Name: 74747.dat
0 Author: Willy Tschager [Holly-Wood]
0 !LDRAW_ORG Shortcut UPDATE 2025-02
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !KEYWORDS BrickLink 2867c01
0 !HISTORY 2004-08-07 [ludo] Rotated inner sleepers for logo alignment.
0 !HISTORY 2004-11-06 [PTadmin] Official Update 2004-04
0 !HISTORY 2007-05-20 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2012-09-09 [technog] changed rail colour from chrome (383) to contact alloy (494)
0 !HISTORY 2012-09-11 [PTadmin] Renamed from 2867
0 !HISTORY 2017-11-21 [MagFors] Modified with WINDZ for BFC compliance
0 !HISTORY 2023-12-12 [Holly-Wood] Rewrote from scratch, original by ludo
0 !HISTORY 2025-02-27 [OrionP] Official Update 2025-02
Show contents
0 // Train Track 9V Curved - Plastic Part
1 16 0 0 0 1 0 0 0 1 0 0 0 1 2867a.dat
0 // Train Track 9V Curved - Metal Rails
1 494 0 0 0 1 0 0 0 1 0 0 0 1 u9610.dat
1 494 0 0 0 1 0 0 0 1 0 0 0 1 u9621.dat
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
2012-09-10 09:35:19
[PTadmin]
edited the part header.
2012-09-10 09:35:19
[PTadmin]
renamed the part.
2012-09-11 19:45:05
"parts/2867.dat" to "parts/2867c00.dat."
[PTadmin]
edited the part header.
2012-09-11 19:50:04
I think for analogy with the 4.5 and 12V train tracks,
this should be renumbered from c00 to c01.
this should be renumbered from c00 to c01.
an alternative could be to simply renumber this file to 74747.dat.
I think that having the quite artificial 2867c00 number is just clutter.
I think that having the quite artificial 2867c00 number is just clutter.
2012-09-11 20:40:05
Yes this could be 2867c01 and bump up the other four.
[PTadmin]
renamed the part.
2012-09-11 21:24:48
"parts/2867c00.dat" to "parts/74747.dat."
2012-09-14 21:30:09
good! removing hold.
will come back for cert.
will come back for cert.
2012-09-16 09:15:21
I'm sorry to come up with this this late, but I just discovered
that this file has a different vertical origin than the
currently official 4.5V and 12V files.
(Both the origin choice there and here of course make sense in their way.)
However, I would like to achieve that this file, and its 4.5V and 12V
counterparts can be freely interchanged, without having to each time
correct the vertical positioning.
We have a chance here to do that now, because this file can have
that origin, and the MOVED-TO pointing here can compensate for that
to achieve downwards-compatibility.
I think we should apply that change. Do you as well? Chris?
that this file has a different vertical origin than the
currently official 4.5V and 12V files.
(Both the origin choice there and here of course make sense in their way.)
However, I would like to achieve that this file, and its 4.5V and 12V
counterparts can be freely interchanged, without having to each time
correct the vertical positioning.
We have a chance here to do that now, because this file can have
that origin, and the MOVED-TO pointing here can compensate for that
to achieve downwards-compatibility.
I think we should apply that change. Do you as well? Chris?
2012-09-16 10:30:03
(that vertical origin change of course should also be applied to the left and right point parts.)
cleaned up comments: most of them started with
0 Comment:
, resulting from mistaking our spec, there the word "Comment" had been used as a placeholder, not as a syntactical required element :-D
Existing certification-votes were deleted.
0 Comment:
, resulting from mistaking our spec, there the word "Comment" had been used as a placeholder, not as a syntactical required element :-D
Existing certification-votes were deleted.
2012-10-03 11:55:04
unfortunatley, my vertical origin change suggested above is impossible.
I suggested it to make the 9v train track have the same origins
everywhere as the 12v and 4.5v tracks.
This would allow, e.g. in train track layout software, to simply
swap between these.
this would be possible now, I thought, because currently all 9v
parts are on the PT, and an origin change is possible for all of them.
BUT 1 part is not: the crossing 32087.dat
I am pondering this through an through currently,
and sometimes I think we should 32087.dat MOVE-TO 32087a.dat
and give it the vertical origin change there.
Would we do that, then we could adjust also the other 9v train
parts currently on the PT, and finally would achieve
that train track layout software could freely interchange
4.5v, 12v and 9v train track parts without taking care
of each time compensating the different vertical origin.
I suggested it to make the 9v train track have the same origins
everywhere as the 12v and 4.5v tracks.
This would allow, e.g. in train track layout software, to simply
swap between these.
this would be possible now, I thought, because currently all 9v
parts are on the PT, and an origin change is possible for all of them.
BUT 1 part is not: the crossing 32087.dat
I am pondering this through an through currently,
and sometimes I think we should 32087.dat MOVE-TO 32087a.dat
and give it the vertical origin change there.
Would we do that, then we could adjust also the other 9v train
parts currently on the PT, and finally would achieve
that train track layout software could freely interchange
4.5v, 12v and 9v train track parts without taking care
of each time compensating the different vertical origin.
2013-03-14 22:35:02
I agree with what steffen is suggesting that we should keep similar parts consistent with one another.
However, I disagree with steffen and the desire to shift the 9v track system to do this.
The 9v track system has the origin logically placed on the top of the plate as all other parts.
Whereas the 12v and 4.5v have track systems have their origin at the top of the rail which feels wrong to me.
However, I disagree with steffen and the desire to shift the 9v track system to do this.
The 9v track system has the origin logically placed on the top of the plate as all other parts.
Whereas the 12v and 4.5v have track systems have their origin at the top of the rail which feels wrong to me.
2013-03-14 22:45:05
beside this discussion: there is a typo in the 2012-09-09 history line: cotact -> contact
[PTadmin]
edited the part header.
2013-03-15 07:55:02
2013-03-15 07:55:02
Corrected contact typo
2013-12-31 06:00:06
the origin at the 4.5V and 12V rail assemblies is at the rail top
because the origin from the rail parts existing first has been
carried over to the rail assemblies.
in the meantime, with the 2013-02 update 2 other rail systems
have been released with their origin at plate level,
so the discussion here is obsolete now.
I retract my suggestion and am fine with origin at plate level.
because the origin from the rail parts existing first has been
carried over to the rail assemblies.
in the meantime, with the 2013-02 update 2 other rail systems
have been released with their origin at plate level,
so the discussion here is obsolete now.
I retract my suggestion and am fine with origin at plate level.
2015-07-12 15:30:00
Another typo in the history:
0 !HISTORY 2012-09-11 [PTadmin] Renumbered from 2865
should be 2867.
0 !HISTORY 2012-09-11 [PTadmin] Renumbered from 2865
should be 2867.
[PTadmin]
edited the part header.
2015-07-12 20:10:00
Made bfc. Still has issues.
Existing certification-votes were deleted.
Existing certification-votes were deleted.
contains editing relicts like
0 // //Inlined: 1 16 0 0 0 1 0 0 0 1 0 0 0 1 movebinnenSh_1.dat
0 // //Inlined: 1 16 0 0 800 1 0 0 0 1 0 0 0 1 Z_binnen_Sh_1.dat
0 // //Inlined: 1 16 0 0 0 1 0 0 0 1 0 0 0 1 movebinnenSh_1.dat
0 // //Inlined: 1 16 0 0 800 1 0 0 0 1 0 0 0 1 Z_binnen_Sh_1.dat
I removed all of the "Inlined" relic comments.
Existing certification-votes were deleted.
Existing certification-votes were deleted.
2021-10-24 16:50:02
The end sleepers are not properly connected to the rails which results in gaps.
2022-12-21 00:19:41
All I did for this part was to remove the unneeded comments (from the inlined code).
If someone else wants to take this file and continue working it, please go ahead. ;-)
If someone else wants to take this file and continue working it, please go ahead. ;-)
Updated subparts sent to admin for proxy.
Complete overhaul.
Complete overhaul.
2023-12-12 21:00:03
IMHO we should split this into it's components, one plastic and one metal, (or two?).
Moved edges to subfile
Not needed, present in metal subfile:
2 5 -153.673 -16 -65.874 -149.75 -8.5 -65.095
2 5 -140.432 -8.5 -63.241 -136.509 -16 -62.46
Still think it should be split into plastic and metal parts.
The loose edge lines on top of the metal rails, added in this file, will get the same colour as the plastic part,
when this part is used coloured grey, or any other colour chosen of a model builder.
2 5 -153.673 -16 -65.874 -149.75 -8.5 -65.095
2 5 -140.432 -8.5 -63.241 -136.509 -16 -62.46
Still think it should be split into plastic and metal parts.
The loose edge lines on top of the metal rails, added in this file, will get the same colour as the plastic part,
when this part is used coloured grey, or any other colour chosen of a model builder.
Deleted edges, moved edge to subfile
2023-12-14 18:11:15
Ok, the design issues are now gone. Only structural issues remain.
Please split this into its separate parts. And each part should have its own set of complete edge lines.
Please split this into its separate parts. And each part should have its own set of complete edge lines.
2023-12-14 18:27:07
Please provide part numbers.
And spect link.
And spect link.
2023-12-14 18:27:10
Please provide part numbers.
And spect link.
And spect link.
Separated plastic from metal - what a vast of time.
2024-02-14 12:19:27
Wasted my time by splitting the metal rails in half
Thank you for finally fixing this, Willy!
2024-03-11 16:56:54
2024-03-14 17:42:43
2025-02-27 19:16:35
Release 2025-02
