Official File parts/76796.dat
Part Attributes:
File Header:
0 Windscreen 4 x 6 x 1.333 Curved Open
0 Name: 76796.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Part UPDATE 2024-11
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2024-12-30 [OrionP] Official Update 2024-11
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\76796s01.dat
4 16 60 32 10 60 0 10 60 28 -10 60 32 -10
4 16 -60 28 -10 -60 0 10 -60 32 10 -60 32 -10
1 16 0 0 10 60 0 0 0 28 0 0 -20 -60 48\2-4cyli.dat
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
Orion, can you check the dimensions and fit?
2021-04-18 14:05:02
Fit looks good. There might be some small stud overlaps at the bottom (I have to look into it more) but, if so, it'll be a minor adjustment and won't affect the overall shape
https://www.ldraw.org/files/78840-test.png
Note that Rebrickable and Brickset disagree about the number (76796 vs. 78840) and BL doesn't have the set inventory yet.
https://www.ldraw.org/files/78840-test.png
Note that Rebrickable and Brickset disagree about the number (76796 vs. 78840) and BL doesn't have the set inventory yet.
2021-04-18 15:25:01
78840 number listed at Rebrickable is for the patterned version. So real part number for blank part is most probably 76796 as reported by Rebrickable (I guess Orion can read the fine prints engraved? ;) )
2021-04-18 16:25:02
It's actually readable on the images from Orion in the forum, 76796
2021-04-18 17:30:01
Gotta love that new iPhone camera. I would have checked but Gerald submitted after I went to bed. I guess a renumber is in order.
[PTadmin]
renamed the part.
2021-04-23 06:58:09
"parts/78840.dat" to "parts/76796.dat."
adapted to new subfile
2023-12-27 16:05:49
2024-11-29 11:18:49
2024-12-27 23:56:40
2024-12-30 06:25:50
Release 2024-11
Creative Commons Attribution License information
This part is copyright © Gerald Lasser
Licensed under CC BY 4.0
