Slope 10 x 2 x 2 Curved with Rounded Corner - Left

File Header:

0 Slope 10 x  2 x  2 Curved with Rounded Corner - Left
0 Name: 77180.dat
0 Author: Ulrich Röder [UR]
0 !LDRAW_ORG Part UPDATE 2023-05
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS Car, Porsche, Set 10295

0 !HISTORY 2023-10-31 [OrionP] Official Update 2023-05

Show contents

1 16 0 0 0 0 0 1 0 1 0 -1 0 0 stud.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\77182s02.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\77182s01.dat

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Ulrich Röder [UR]

initially submitted the part.

2021-03-22 22:40:02

Ulrich Röder [UR]

submitted a new version of the part.

2021-03-23 17:30:02

unknown [unknown]

made the following comment.

2021-09-16 08:20:02

Excuse me ,when I import ,why tell me parts not found?

unknown [unknown]

made the following comment.

2021-11-22 21:05:01

it will be nice to also have the other required parts mirrored to the left. The parts I need are:
Slope 10 x 2 x 2 Curved with Rounded Corner - without Surface - Left
Slope 10 x 2 x 2 Curved with Rounded Corner - Outer Surface - Left
Thanks for the work!

Magnus Forsberg [MagFors]

made the following comment.

2021-11-22 22:35:01

There is no need for left side subfiles. The subfiles are used mirrored in part 77180 and unmirrored in 77182.
That's one of the main ideas in ldraw. We don't make both a left and a right version. Instead a subfile is made and reused in a mirrored position.

unknown [unknown]

made the following comment.

2021-11-23 10:25:02

ok MagFors but when I import the 77180.dat file in PartDesigner it tell me missing parts so I need the subfiles in order to creake the complete part. If yuo know how to import the .dat file correctly let me know how

Max Martin Richter [MMR1988]

made the following comment.

2021-11-23 12:25:02

Could we please move the discussion to the forum, thanks!

Back to the review: As this part is used in the Titanic as well, I would not set the keywords that specific.

unknown [unknown]

made the following comment.

2021-12-09 04:10:01

I'm new here, why are the files for this piece and for 77182 the same? I'm trying to build the Titanic on stud.io and I have been able to create brick 77182 on partbuilder but when I try to make this brick the parts are the same as the one I already built. Am i missing something that would allow me to mirror part 77182.

Philippe Hurbain [Philo]

made the following comment.

2021-12-09 07:30:01

The subfiles are the same but they are mirrored in this file, not mirrored in 77182. Have a look at the preview image!

unknown [unknown]

made the following comment.

2021-12-18 03:35:01

Philo, I can see that the preview shows the mirrored version, but the files under "Required (unofficial) subfiles" are still the same for both pieces. Does this mean that I am not able to create this piece in Partbuilder? Do I need to manually mirror the piece on Partbuilder or am I missing something? I thought that I just needed to download the files under the part and then I could build it in Partbuilder.

Max Martin Richter [MMR1988]

made the following comment.

2021-12-22 16:55:01

If you look into the files 77180 and 77182 you can see, that the subparts are mirrored on x-axis in 77180. Please have a look into the code:
77182:
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\77182s02.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\77182s01.dat
77180:
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\77182s02.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\77182s01.dat

So the same subparts are used, but mirrored in one of both parts to create the left and right file.

Please move further discussion, that do not include review comments, to the forum! Thanks!

Philippe Hurbain [Philo]

posted a vote of Certify.

2022-04-07 11:50:01

Max Martin Richter [MMR1988]

posted a vote of Certify.

2022-04-17 20:35:01

Orion Pobursky [OrionP]

posted a vote of Admin Review.

2023-10-30 14:40:06

Orion Pobursky [OrionP]

2023-10-31 03:34:36

Release 2023-05
