0 Technic Cross Block 2 x 4 Split (Pin/Axle/Axle/Pin)
0 Name: 80910.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Part UPDATE 2025-03
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2025-03-30 [OrionP] Official Update 2025-03
Show contents
1 16 0 0 30 0 0 1 0 1 0 -1 0 0 6536.dat
1 16 0 0 -30 0 0 1 0 1 0 -1 0 0 6536.dat
1 16 0 0 20 8.7 0 0 0 0 -8.7 0 -40 0 1-16cylo.dat
1 16 0 0 20 8.7 0 0 0 0 8.7 0 -40 0 1-16cylo.dat
0 BFC INVERTNEXT
1 16 8.2412 -8.2412 20 -4.9118 0 1.81453 0.20326 0 5.2323 0 -40 0 3-16cylo.dat
2 24 8.0379 -3.3295 20 8.0379 -3.3293 -20
2 24 3.3294 -8.038 20 3.3294 -8.038 -20
1 16 0 0 20 0 0 8.7 8.7 0 0 0 -40 0 1-16cylo.dat
1 16 0 0 20 0 0 -8.7 8.7 0 0 0 -40 0 1-16cylo.dat
0 BFC INVERTNEXT
1 16 8.2412 8.2412 20 -0.20326 0 -5.2323 -4.9118 0 1.81453 0 -40 0 3-16cylo.dat
2 24 3.3295 8.0379 20 3.3293 8.0379 -20
2 24 8.038 3.3294 20 8.038 3.3294 -20
1 16 0 0 20 -8.7 0 0 0 0 8.7 0 -40 0 1-16cylo.dat
1 16 0 0 20 -8.7 0 0 0 0 -8.7 0 -40 0 1-16cylo.dat
0 BFC INVERTNEXT
1 16 -8.2412 8.2412 20 4.9118 0 -1.81453 -0.20326 0 -5.2323 0 -40 0 3-16cylo.dat
2 24 -8.0379 3.3295 20 -8.0379 3.3293 -20
2 24 -3.3294 8.038 20 -3.3294 8.038 -20
1 16 0 0 20 0 0 -8.7 -8.7 0 0 0 -40 0 1-16cylo.dat
1 16 0 0 20 0 0 8.7 -8.7 0 0 0 -40 0 1-16cylo.dat
0 BFC INVERTNEXT
1 16 -8.2412 -8.2412 20 0.20326 0 5.2323 4.9118 0 -1.81453 0 -40 0 3-16cylo.dat
2 24 -3.3295 -8.0379 20 -3.3293 -8.0379 -20
2 24 -8.038 -3.3294 20 -8.038 -3.3294 -20
0 BFC INVERTNEXT
1 16 0 0 20 0 0 4 4 0 0 0 -40 0 4-4cylo.dat
1 16 0 0 20 0 0 2 2 0 0 0 -1 0 4-4ring2.dat
1 16 0 0 -20 0 0 2 2 0 0 0 1 0 4-4ring2.dat
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
2021-12-06 08:30:02
Changed orientation to match 6536
Axlehole is missing in the centre piece
2021-12-06 09:55:01
I understood there was only a bar hole there.
https://www.eurobricks.com/forum/index.php?/forums/topic/101081-general-part-discussion/&;do=findComment&comment=3474993
https://www.eurobricks.com/forum/index.php?/forums/topic/101081-general-part-discussion/&;do=findComment&comment=3474993
I think he means that the inside structure is missing. The middle tube is empty.
Groumph... looks like my latest edits were not saved :(
Existing certification-votes were deleted.
Existing certification-votes were deleted.
Updated description
2021-12-11 22:00:01
Does it contain two flat side as the ordinary smooth axle joiner or not? Can't see it an the pictures.
2021-12-12 06:55:02
From all I can say all sides are rounded. But don't have the part either...
2024-12-31 19:37:03
It looks and feels the same as the normal smooth axle holder, two rounded sides and two flat sides. The top and bottom sides are rounded, the sides are flat (with the current orientation of the part)
2025-01-01 15:37:23
I just looked at BIs part, all sides are rounded there. But it wouldn't be the first time that a BIs mesh is inaccurate...
* The inside of the joint is not correct. It's not just a cylinder:
https://i.ebayimg.com/images/g/T5sAAOSwcPNkR3wY/s-l1600.jpg
https://i.ebayimg.com/images/g/T5sAAOSwcPNkR3wY/s-l1600.jpg
2025-03-15 19:29:55
Let's keep things simple please! It's functionally OK. Quote of Eurobricks: "Notice that one can only insert an axle by 1L (but a bar can go all the way through)"
2025-03-15 22:01:07
IMHO , the blocker serves it's purpose inb the current shapeso IMO it is good that way
Axle needs to be stopped -> check
Bar needs to go through -> check
We really need to consider the tapered and shortened Axle ends now... to keep them from collinding in parts like this.
Axle needs to be stopped -> check
Bar needs to go through -> check
We really need to consider the tapered and shortened Axle ends now... to keep them from collinding in parts like this.
2025-03-15 22:28:03
2025-03-16 10:45:24
2025-03-16 14:52:59
2025-03-17 08:00:02
2025-03-30 05:48:50
Release 2025-03
Creative Commons Attribution License information
This part is copyright © Philippe Hurbain
Licensed under CC BY 4.0
