| Brickstuff Single-Function Lighting Effect Controller
File Header:
0 | Brickstuff Single-Function Lighting Effect Controller 0 Name: t1021.dat 0 Author: Philippe Hurbain [Philo] 0 !LDRAW_ORG Part UPDATE 2024-03 0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt 0 BFC CERTIFY CCW 0 !CATEGORY Electric 0 !KEYWORDS LEC, TRUNK01 0 !HISTORY 2024-04-28 [OrionP] Official Update 2024-03
Show contents
1 16 0 0 0 -52 0 0 0 -4 0 0 0 -18 box4.dat 0 BFC INVERTNEXT 1 16 -30 0 -10 -6 0 0 0 -4 0 0 0 -6 4-4cylo.dat 1 16 -30 0 -10 -6 0 0 0 -1 0 0 0 -6 4-4ndis.dat 1 16 -30 -4 -10 -6 0 0 0 1 0 0 0 -6 4-4ndis.dat 0 BFC INVERTNEXT 1 16 -30 0 10 -6 0 0 0 -4 0 0 0 -6 4-4cylo.dat 1 16 -30 0 10 -6 0 0 0 -1 0 0 0 -6 4-4ndis.dat 1 16 -30 -4 10 -6 0 0 0 1 0 0 0 -6 4-4ndis.dat 4 16 -24 -4 4 -36 -4 4 -36 -4 -4 -24 -4 -4 4 16 -24 0 -4 -36 0 -4 -36 0 4 -24 0 4 4 16 -36 -4 -16 -36 -4 16 -52 -4 18 -52 -4 -18 4 16 -36 0 16 -36 0 -16 -52 0 -18 -52 0 18 0 BFC INVERTNEXT 1 16 30 0 -10 6 0 0 0 -4 0 0 0 -6 4-4cylo.dat 1 16 30 0 -10 6 0 0 0 -1 0 0 0 -6 4-4ndis.dat 1 16 30 -4 -10 6 0 0 0 1 0 0 0 -6 4-4ndis.dat 0 BFC INVERTNEXT 1 16 30 0 10 6 0 0 0 -4 0 0 0 -6 4-4cylo.dat 1 16 30 0 10 6 0 0 0 -1 0 0 0 -6 4-4ndis.dat 1 16 30 -4 10 6 0 0 0 1 0 0 0 -6 4-4ndis.dat 4 16 36 -4 -4 36 -4 4 24 -4 4 24 -4 -4 4 16 36 0 4 36 0 -4 24 0 -4 24 0 4 4 16 52 -4 18 36 -4 16 36 -4 -16 52 -4 -18 4 16 52 0 -18 36 0 -16 36 0 16 52 0 18 4 16 36 -4 -16 -36 -4 -16 -52 -4 -18 52 -4 -18 1 78 51 -8 -10 0 0 -1 0 1 0 1 0 0 t1011.dat 1 78 51 -8 10 0 0 -1 0 1 0 1 0 0 t1011.dat 1 78 -51 -8 -10 0 0 1 0 1 0 -1 0 0 t1011.dat 1 0 -24 -4 -7 1 0 0 0 1 0 0 0 1 t1020.dat 1 0 5 -4 -11.5 6 0 0 0 -4 0 0 0 6 box5.dat 1 0 11 -4 7.5 11 0 0 0 -7 0 0 0 5 box5.dat 1 494 11 -11 7.5 11 0 0 0 -1 0 0 0 5 box4.dat 0 BFC INVERTNEXT 1 494 11 -11 7.5 4 0 0 0 -1 0 0 0 2 box4.dat 1 0 13 -11 7.5 1.8 0 0 0 -5 0 0 0 1.8 box5.dat 1 494 -10 -4 11 6 0 0 0 -3 0 0 0 4 box5.dat 1 15 -10 -7 11 3 0 0 0 -2 0 0 0 2 box5.dat 4 494 7 -12 5.5 7 -12 9.5 0 -12 12.5 0 -12 2.5 4 494 15 -12 5.5 7 -12 5.5 0 -12 2.5 22 -12 2.5 4 494 15 -12 5.5 22 -12 2.5 22 -12 12.5 15 -12 9.5 4 494 15 -12 9.5 22 -12 12.5 0 -12 12.5 7 -12 9.5 1 16 0 0 6.5 -1.5 0 0 0 -1 0 0 0 1.5 s\t1012s01.dat 4 16 -10.5 0 17 -10.5 0 -2.5 -24 0 -16 -24 0 16 4 16 -24 0 16 -36 0 16 -52 0 18 -10.5 0 17 4 16 10.5 0 17 -10.5 0 17 -52 0 18 52 0 18 4 16 10.5 0 17 52 0 18 36 0 16 24 0 16 4 16 10.5 0 -2.5 10.5 0 17 24 0 16 24 0 -16 4 16 -10.5 0 -2.5 10.5 0 -2.5 24 0 -16 -24 0 -16 4 16 -52 0 -18 -36 0 -16 36 0 -16 52 0 -18 1 15 48 -4 0 1.5 0 0 0 -0.5 0 0 0 1 box5.dat 1 79 48 -4.5 0 1.5 0 0 0 -.5 0 0 0 1 box5.dat 4 15 24 -4 18 21 -4 18 21 -4 -1.5 24 -4 -1.5 4 16 24 -4 18 24 -4 16 36 -4 16 52 -4 18 4 16 24 -4 -16 24 -4 -1.5 21 -4 -1.5 -24 -4 -16 4 16 -24 -4 16 -24 -4 -16 21 -4 -1.5 21 -4 18 4 16 -36 -4 16 -24 -4 16 21 -4 18 -52 -4 18
Status:
Official Official
Unofficial parents
Part Events:
Archived Part Events:
Philippe Hurbain [Philo]
Senior Part Reviewer
initially submitted the part.
2017-12-15 14:05:00
Philippe Hurbain [Philo]
Senior Part Reviewer
submitted a new version of the part.
2017-12-19 15:50:00
Added white mark below switch
Steffen [Steffen]
Senior Part Reviewer
made the following comment.
2017-12-22 12:35:00
for consistency with our existing parts titling
(we use "English Heading Titling"), the word "Party" in the title should get a capital "P" IMHO
[PTadmin]
Part Author
renamed the part.
2018-01-16 21:58:12
"parts/u9398.dat" to "parts/t1021.dat."
Max Martin Richter [MMR1988]
Senior Part Reviewer
posted a vote of Hold.
2021-09-17 19:50:01
One connector (with 3 pins?) is missing.
Philippe Hurbain [Philo]
Senior Part Reviewer
submitted a new version of the part.
2021-09-18 07:20:02
Mine has was unpopulated there. Maybe several versions? Added connector nonetheless...

Existing certification-votes were deleted.
Max Martin Richter [MMR1988]
Senior Part Reviewer
posted a vote of Hold.
2021-09-18 19:30:01
You added a two pin connector. The picture I found has a three pin connector. ;-)

Yes, I think it's a newer version of this part which contains the 4th connector.
Philippe Hurbain [Philo]
Senior Part Reviewer
submitted a new version of the part.
2021-11-09 08:45:02
Reverted to 3 connectors. I discussed with Brickstuff, the fourth one was an option never implemented (but appearing on some early photos of prototypes)

Existing certification-votes were deleted.
Max Martin Richter [MMR1988]
Senior Part Reviewer
posted a vote of Certify.
2021-11-13 21:40:01
OK :-)
Takeshi Takahashi [RainbowDolphin]
Senior Part Reviewer
posted a vote of Certify.
2023-09-08 13:23:36
Orion Pobursky [OrionP]
Part Library Admin
posted a vote of Admin Review.
2024-04-23 03:06:11
Orion Pobursky [OrionP]
Part Library Admin
2024-04-28 11:50:18
Release 2024-03
