File Detail parts/u767c01.dat

Download Download zip file View patterns/composites/shortcuts

Unofficial File parts/u767c01.dat

Part Attributes: Base Part: u767.dat

Sail 12 x 10 Trapezoidal (Formed Shape 1)

File Header:

0 Sail 12 x 10 Trapezoidal (Formed Shape 1)
0 Name: u767c01.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 !HELP Placement on mast:
0 !HELP 1 25 0 148 0 1 0 0 0 1 0 0 0 1 4318.dat
0 !HELP 1 25 0 -10 0 1 0 0 0 1 0 0 0 1 4733.dat
0 !HELP 1 25 -98 0 0 0 -1 0 -1 0 0 0 0 -1 3957a.dat
0 !HELP 1 25 98 0 0 0 1 0 -1 0 0 0 0 1 3957a.dat
0 !HELP 1 25 0 -18 0 -1 0 0 0 1 0 0 0 -1 3957a.dat

0 BFC CERTIFY CCW

0 !CATEGORY Sheet Fabric
0 !KEYWORDS Set 6057
