Official File parts/u9431.dat
Part Attributes:
File Header:
0 ~Electric Constraction Eyes 4.5 x 2 x 1.5 Light-Up Sponge for LED Anode
0 Name: u9431.dat
0 Author: Santeri Piippo [arezey]
0 !LDRAW_ORG Part UPDATE 2024-05
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 !HELP Keeps the LED's anode away from the battery while the button is not pressed.
0 BFC CERTIFY CCW
0 !HISTORY 2023-05-30 [SwampKryakwa] Changed triangulation to avoid convex faces, changed condlines to appear properly, use of rect and box primitives.
0 !HISTORY 2024-06-30 [OrionP] Official Update 2024-05
Show contents
1 16 0 -2.25 0 0 0 6.25 0 3.75 0 3 0 0 box3u2p.dat
1 16 4.125 -2.25 0 2.125 0 0 0 1 0 0 0 3 rect2p.dat
1 16 -4.125 -2.25 0 2.125 0 0 0 1 0 0 0 3 rect2p.dat
1 16 0 0.360165 0 0.575 0 0 0 1 -0.665935 0 0 3 rect.dat
2 24 1.3286 -2.23445 3 2 -2.25 3
2 24 0.9188 -2.12557 3 1.3286 -2.23445 3
2 24 0.7022 -1.83005 3 0.9188 -2.12557 3
2 24 0.6104 -1.25455 3 0.7022 -1.83005 3
2 24 0.575 -0.30577 3 0.6104 -1.25455 3
2 24 -0.575 -0.30577 3 -0.6104 -1.25455 3
2 24 -0.6104 -1.25455 3 -0.7022 -1.83005 3
2 24 -0.7022 -1.83005 3 -0.9188 -2.12557 3
2 24 -0.9188 -2.12557 3 -1.3286 -2.23445 3
2 24 -1.3286 -2.23445 3 -2 -2.25 3
2 24 1.4246 -2.21179 -3 2 -2.25 -3
2 24 1.0268 -2.00433 -3 1.4246 -2.21179 -3
2 24 0.7742 -1.48836 -3 1.0268 -2.00433 -3
2 24 0.6344 -0.524637 -3 0.7742 -1.48836 -3
2 24 0.575 1.0261 -3 0.6344 -0.524637 -3
2 24 -0.575 1.0261 -3 -0.6344 -0.524637 -3
2 24 -0.6344 -0.524637 -3 -0.7742 -1.48836 -3
2 24 -0.7742 -1.48836 -3 -1.0268 -2.00433 -3
2 24 -1.0268 -2.00433 -3 -1.4246 -2.21179 -3
2 24 -1.4246 -2.21179 -3 -2 -2.25 -3
3 16 0.7022 -1.83005 3 1.0268 -2.00433 -3 0.9188 -2.12557 3
3 16 0.7742 -1.48836 -3 1.0268 -2.00433 -3 0.7022 -1.83005 3
4 16 0.6344 -0.524637 -3 0.7742 -1.48836 -3 0.7022 -1.83005 3 0.6104 -1.25455 3
4 16 0.575 1.0261 -3 0.6344 -0.524637 -3 0.6104 -1.25455 3 0.575 -0.305769 3
4 16 -0.6104 -1.25455 3 -0.6344 -0.524637 -3 -0.575 1.0261 -3 -0.575 -0.30577 3
4 16 -0.7022 -1.83005 3 -0.7742 -1.48836 -3 -0.6344 -0.524637 -3 -0.6104 -1.25455 3
3 16 -1.0268 -2.00433 -3 -0.7742 -1.48836 -3 -0.7022 -1.83005 3
3 16 -0.9188 -2.12557 3 -1.0268 -2.00433 -3 -0.7022 -1.83005 3
5 24 0.7022 -1.83005 3 1.0268 -2.00433 -3 0.9188 -2.12557 3 0.7742 -1.48836 -3
5 24 0.6344 -0.524637 -3 0.6104 -1.25455 3 0.7742 -1.48836 -3 0.575 -0.305769 3
4 16 -6.25 -2.25 -3 -6.25 1.5 -3 -0.7742 -1.48836 -3 -1.0268 -2.00433 -3
4 16 -6.25 -2.25 -3 -1.0268 -2.00433 -3 -1.4246 -2.21179 -3 -2 -2.25 -3
4 16 0.6344 -0.524637 -3 0.575 1.0261 -3 6.25 1.5 -3 0.7742 -1.48836 -3
4 16 2 -2.25 -3 1.4246 -2.21179 -3 1.0268 -2.00433 -3 6.25 -2.25 -3
4 16 1.0268 -2.00433 -3 0.7742 -1.48836 -3 6.25 1.5 -3 6.25 -2.25 -3
4 16 -0.7742 -1.48836 -3 -6.25 1.5 -3 -0.575 1.0261 -3 -0.6344 -0.524637 -3
4 16 -0.575 1.0261 -3 -6.25 1.5 -3 6.25 1.5 -3 0.575 1.0261 -3
4 16 -6.25 -2.25 3 -2 -2.25 3 -1.3286 -2.23445 3 -0.9188 -2.12557 3
4 16 -6.25 -2.25 3 -0.9188 -2.12557 3 -0.7022 -1.83005 3 -0.6104 -1.25455 3
4 16 -6.25 -2.25 3 -0.6104 -1.25455 3 -0.575 -0.30577 3 -6.25 1.5 3
4 16 6.25 1.5 3 0.575 -0.30577 3 0.6104 -1.25455 3 6.25 -2.25 3
4 16 0.6104 -1.25455 3 0.7022 -1.83005 3 0.9188 -2.12557 3 6.25 -2.25 3
4 16 0.9188 -2.12557 3 1.3286 -2.23445 3 2 -2.25 3 6.25 -2.25 3
4 16 0.575 -0.305769 3 6.25 1.5 3 -6.25 1.5 3 -0.575 -0.30577 3
3 16 -1.3286 -2.23445 3 -1.4246 -2.21179 -3 -.9188 -2.12557 3
3 16 -.9188 -2.12557 3 -1.4246 -2.21179 -3 -1.0268 -2.00433 -3
3 16 1.3286 -2.23445 3 .9188 -2.12557 3 1.4246 -2.21179 -3
3 16 1.4246 -2.21179 -3 .9188 -2.12557 3 1.0268 -2.00433 -3
5 24 1.4246 -2.21179 -3 .9188 -2.12557 3 1.3286 -2.23445 3 1.0268 -2.00433 -3
5 24 .9188 -2.12557 3 1.0268 -2.00433 -3 .7742 -1.48836 -3 1.4246 -2.21179 -3
3 16 2 -2.25 3 1.3286 -2.23445 3 2 -2.25 -3
3 16 2 -2.25 -3 1.3286 -2.23445 3 1.4246 -2.21179 -3
3 16 -2 -2.25 -3 -1.4246 -2.21179 -3 -1.3286 -2.23445 3
3 16 -2 -2.25 -3 -1.3286 -2.23445 3 -2 -2.25 3
5 24 2 -2.25 -3 1.3286 -2.23445 3 1.4246 -2.21179 -3 2 -2.25 3
5 24 .7022 -1.83005 3 .7742 -1.48836 -3 .6344 -.524637 -3 1.0268 -2.00433 -3
5 24 2 -2.25 -3 2 -2.25 3 1.3286 -2.23445 3 6.25 -2.25 3
5 24 1.3286 -2.23445 3 1.4246 -2.21179 -3 2 -2.25 -3 .9188 -2.12557 3
5 24 -.7022 -1.83005 3 -1.0268 -2.00433 -3 -.9188 -2.12557 3 -.7742 -1.48836 -3
5 24 -.6344 -.524637 -3 -.6104 -1.25455 3 -.7742 -1.48836 -3 -.575 -.305769 3
5 24 -1.4246 -2.21179 -3 -.9188 -2.12557 3 -1.3286 -2.23445 3 -1.0268 -2.00433 -3
5 24 -.9188 -2.12557 3 -1.0268 -2.00433 -3 -.7742 -1.48836 -3 -1.4246 -2.21179 -3
5 24 -2 -2.25 -3 -1.3286 -2.23445 3 -1.4246 -2.21179 -3 -2 -2.25 3
5 24 -.7022 -1.83005 3 -.7742 -1.48836 -3 -.6344 -.524637 -3 -1.0268 -2.00433 -3
5 24 -2 -2.25 -3 -2 -2.25 3 -1.3286 -2.23445 3 -6.25 -2.25 3
5 24 -1.3286 -2.23445 3 -1.4246 -2.21179 -3 -2 -2.25 -3 -.9188 -2.12557 3
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
2018-04-06 09:20:01
2021-09-23 20:20:01
I would like to see the triangulation in the round area switched to get a smoother rendering result.
Way it's shaded on render looks good enough to me
2023-05-29 10:53:13
Switching them would avoid convex areas.
Changed triangulation, fixed condlines to appear properly, replaced some geometry with rect and box primitives
* Rounding
* Ugly triangulation
* Ugly triangulation
2023-09-08 15:27:52
2024-06-04 19:42:41
2024-06-30 00:13:33
Release 2024-05
