Official File parts/s/16965s03.dat
File Header:
0 ~Ripcord Flexible with Handle Thick for Ninjago Airjitzu Flyers (70 Teeth) - Single Tooth
0 Name: s\16965s03.dat
0 Author: Massimo Maso [Sirio]
0 !LDRAW_ORG Subpart UPDATE 2023-02
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2023-04-17 [OrionP] Official Update 2023-02
Show contents
0 // Primitives
1 16 0 1 1.875 .535 0 0 0 1 0 0 0 4.225 rect.dat
1 16 0 6.45 2.5 1.125 0 0 0 -1 0 0 0 7.5 rect.dat
1 16 0 -1.75 1.875 1.535 0 0 0 1 0 0 0 4.225 recte4.dat
1 16 0 1.75 2.5 -2.915 0 0 0 1 0 0 0 -7.5 recte3.dat
0 // Bottom faces
4 16 -1.535 -1.75 6.1 -1.535 -1.75 -2.35 -.535 1 -2.35 -.535 1 6.1
4 16 1.535 -1.75 -2.35 1.535 -1.75 6.1 .535 1 6.1 .535 1 -2.35
4 16 .535 1 6.1 1.535 -1.75 6.1 -1.535 -1.75 6.1 -.535 1 6.1
4 16 -.535 1 -2.35 -1.535 -1.75 -2.35 1.535 -1.75 -2.35 .535 1 -2.35
0 // Top faces
4 16 2.915 1.75 10 2.915 1.75 -5 1.125 6.45 -5 1.125 6.45 10
4 16 -1.125 6.45 10 -1.125 6.45 -5 -2.915 1.75 -5 -2.915 1.75 10
4 16 2.915 1.75 10 1.125 6.45 10 -1.125 6.45 10 -2.915 1.75 10
4 16 -2.915 1.75 -5 -1.125 6.45 -5 1.125 6.45 -5 2.915 1.75 -5
0 // Edges
2 24 -1.125 6.45 10 -2.915 1.75 10
2 24 1.125 6.45 10 2.915 1.75 10
2 24 -.535 1 6.1 -1.535 -1.75 6.1
2 24 .535 1 6.1 1.535 -1.75 6.1
2 24 1.125 6.45 -5 2.915 1.75 -5
2 24 -1.125 6.45 -5 -2.915 1.75 -5
2 24 .535 1 -2.35 1.535 -1.75 -2.35
2 24 -.535 1 -2.35 -1.535 -1.75 -2.35
2 24 -1.535 -1.75 6.1 -1.535 -1.75 -2.35
2 24 1.535 -1.75 6.1 1.535 -1.75 -2.35
2 24 -2.915 1.75 10 -2.915 1.75 -5
2 24 2.915 1.75 10 2.915 1.75 -5
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
Creative Commons Attribution License information
This part is copyright © Massimo Maso
Licensed under CC BY 4.0
