File Detail parts/4352.dat

Download Download zip file View patterns/composites/shortcuts

Official File parts/4352.dat

Part Attributes:

~Electric 4.5V 3 C-Cell Battery Box Polarity Switch 2 x 4 Front

File Header:

0 ~Electric 4.5V 3 C-Cell Battery Box Polarity Switch 2 x 4 Front
0 Name: 4352.dat
0 Author: Rene Rechthaler [Blechtaler]
0 !LDRAW_ORG Part UPDATE 2024-10
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2024-12-01 [OrionP] Official Update 2024-10

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\4352s02.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\4352s02.dat

0 // Outside
1 16 0 -4 0 1 0 0 0 -1 0 0 0 1 stud4.dat
0 BFC INVERTNEXT
1 16 0 0 0 16 0 0 0 -4 0 0 0 16 box5.dat
1 16 0 -4 20 0 0 20 4 0 0 0 -40 0 box3u4p.dat
2 24 20 0 20 -20 0 20
2 24 -20 0 -20 20 0 -20
4 16 16 0 16 -16 0 16 -20 0 20 20 0 20
4 16 16 0 -16 16 0 16 20 0 20 20 0 -20
4 16 -16 0 -16 16 0 -16 20 0 -20 -20 0 -20
4 16 -16 0 16 -16 0 -16 -20 0 -20 -20 0 20
4 16 20 0 20 -20 0 20 -9.3168 -5.2276 20 9.3168 -5.2276 20
3 16 -20 -8 -20 20 -8 -20 0 -24.5 -20

0 // Holes
0 BFC INVERTNEXT
1 16 0 -38 -20 0 0 3.5 3.5 0 0 0 4 0 4-4cyli.dat
0 BFC INVERTNEXT
1 16 0 -48 -20 0 0 3.5 3.5 0 0 0 4 0 4-4cylo.dat
0 BFC INVERTNEXT
1 16 0 -28 -20 0 0 3.5 3.5 0 0 0 4 0 4-4cylo.dat
1 16 0 -38 -20 0 0 3.5 3.5 0 0 0 1 0 4-4edge.dat
1 16 0 -28 -20 0 0 3.5 3.5 0 0 0 1 0 4-4ndis.dat
1 16 0 -38 -20 0 0 3.5 3.5 0 0 0 1 0 4-4ndis.dat
1 16 0 -48 -20 0 0 3.5 3.5 0 0 0 1 0 4-4ndis.dat

0 // Inside
1 16 0 -5.2276 18 0 0 -9.3168 0 1 0 -2 0 0 rect.dat
4 16 -13.7772 -6.7396 16 -18 -8.824 16 18 -8.824 16 13.7772 -6.7396 16
4 16 -9.3168 -5.2276 16 -13.7772 -6.7396 16 13.7772 -6.7396 16 9.3168 -5.2276 16
1 16 0 -28 -16 0 0 3.5 3.5 0 0 0 -1 0 4-4ndis.dat
1 16 0 -48 -16 0 0 3.5 3.5 0 0 0 -1 0 4-4ndis.dat
1 16 0 -38 -12 0 0 24 1.3395 0 0 0 8 0 box5-4a.dat
2 24 3.2337 -36.6606 -12 -3.2337 -36.6606 -12
2 24 3.2337 -39.3395 -12 -3.2337 -39.3395 -12
3 16 3.2337 -39.3395 -12 -3.2337 -39.3395 -12 0 -38 -12
3 16 0 -38 -12 -3.2337 -36.6606 -12 3.2337 -36.6606 -12
3 16 17 -69.444 -16 -17 -69.444 -16 0 -74 -16
4 16 19 -68 -16 -19 -68 -16 -17 -69.444 -16 17 -69.444 -16
4 16 28 -57 -16 -28 -57 -16 -19 -68 -16 19 -68 -16
2 24 28 -57 -16 -28 -57 -16
4 16 14 -57 -4 -14 -57 -4 -28 -57 -16 28 -57 -16
0 BFC INVERTNEXT
1 16 0 -55 4 0 0 14 2 0 0 0 -8 0 box3u2p.dat
0 BFC INVERTNEXT
1 16 0 -21 4 0 0 14 2 0 0 0 -8 0 box3u2p.dat
4 16 20 -53 -12 -20 -53 -12 -14 -53 -4 14 -53 -4
1 16 0 -53 -14 0 0 -20 0 -1 0 -2 0 0 rect1.dat
1 16 0 -23 -14 0 0 -20 0 1 0 -2 0 0 rect1.dat
4 16 -14 -23 -4 -20 -23 -12 20 -23 -12 14 -23 -4
3 16 -20 -53 -16 20 -53 -16 0 -51.5 -16
3 16 20 -23 -16 -20 -23 -16 0 -24.5 -16
4 16 28 -19 -16 -28 -19 -16 -14 -19 -4 14 -19 -4
4 16 -18 -8.824 -16 -28 -17.4426 -16 28 -17.4426 -16 18 -8.824 -16
1 16 0 -18.2213 -16 0 0 28 -.7787 0 0 0 -1 0 rect1.dat
1 16 0 -8.824 0 0 0 -18 0 1 0 16 0 0 rect.dat
