File Detail parts/4354.dat

Official File parts/4354.dat

Part Attributes:

~Electric 4.5V 3 C-Cell Battery Box Polarity Switch 2 x 4 Lever

File Header:

0 ~Electric  4.5V  3 C-Cell Battery Box Polarity Switch  2 x  4 Lever
0 Name: 4354.dat
0 Author: Rene Rechthaler [Blechtaler]
0 !LDRAW_ORG Part UPDATE 2024-10
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2024-12-01 [OrionP] Official Update 2024-10

Show contents

1 16 0 -42 0 20 0 0 0 2 0 0 0 20 box4.dat
1 16 0 -42 0 6 0 0 0 1 0 0 0 6 4-4ndis.dat
4 16 -6 -42 6 6 -42 6 20 -42 20 -20 -42 20
4 16 -6 -42 -6 -6 -42 6 -20 -42 20 -20 -42 -20
4 16 6 -42 -6 -6 -42 -6 -20 -42 -20 20 -42 -20
4 16 6 -42 6 6 -42 -6 20 -42 -20 20 -42 20
1 16 0 -42 0 0 0 1 0 1 0 -1 0 0 stug2-2x2.dat
1 16 0 -42 0 1 0 0 0 1 0 0 0 1 axl5ho10.dat
1 16 0 -42 0 1 0 0 0 16 0 0 0 1 axl5hol8.dat
1 16 0 -42 0 1 0 0 0 1 0 0 0 1 axl5hol9.dat
1 16 0 -42 0 1 0 0 0 1 0 0 0 1 axlehol2.dat
1 16 0 -26 0 1 0 0 0 1 0 0 0 1 axl5hol9.dat
1 16 0 -26 0 1 0 0 0 1 0 0 0 1 axlehol2.dat
1 16 0 -26 0 1 0 0 0 1 0 0 0 1 axl5end.dat
1 16 0 -40 0 8 0 0 0 -1 0 0 0 8 4-4ndis.dat
4 16 20 -40 20 8 -40 8 -8 -40 8 -20 -40 20
4 16 -20 -40 20 -8 -40 8 -8 -40 -8 -20 -40 -20
4 16 -20 -40 -20 -8 -40 -8 8 -40 -8 20 -40 -20
4 16 20 -40 -20 8 -40 -8 8 -40 8 20 -40 20
1 16 0 -24 0 8 0 0 0 -16 0 0 0 8 4-4cylc.dat
1 16 0 -24 0 7.3912 0 0 0 40 0 0 0 3.0616 box5.dat

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Rene Rechthaler [Blechtaler]

initially submitted the part.

2022-12-31 20:20:01

didnt want to open the part, so some internals are guessed.

Orion Pobursky [OrionP]

renamed the part.

2023-03-22 00:29:26

"s\4352s03.dat" to "4354.dat"

Magnus Forsberg [MagFors]

posted a vote of Certify.

2023-03-25 13:18:12

Maybe add a hole around the rotation centre? Or a pin?

Rene Rechthaler [Blechtaler]

made the following comment.

2023-03-25 20:45:55

I didnt want to open my glued part, so some internals are guessed.

Max Martin Richter [MMR1988]

edited the part header.

2023-05-23 18:18:31

Added missing whitespaces

Takeshi Takahashi [RainbowDolphin]

posted a vote of Certify.

2024-03-30 15:25:26

Orion Pobursky [OrionP]

posted a vote of Admin Review.

2024-11-27 20:20:47

Orion Pobursky [OrionP]

2024-12-01 00:36:19

Release 2024-10
