File Detail parts/s/44570s01.dat

Official File parts/s/44570s01.dat

~Hinge Plate 3 x 4 Locking Dual - Without Finger

File Header:

0 ~Hinge Plate  3 x  4 Locking Dual - Without Finger
0 Name: s\44570s01.dat
0 Author: Marc Giraudet [Mad_Marc]
0 !LDRAW_ORG Subpart UPDATE 2024-08
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2024-09-30 [OrionP] Official Update 2024-08

Show contents

1 16 -10 0 -10 0 0 1 0 1 0 -1 0 0 stug-3x3.dat
1 16 30 0 -10 0 0 1 0 1 0 -1 0 0 stug-1x3.dat
1 16 0 8 -10 40 0 0 0 -8 0 0 0 -30 box4-4a.dat
0 BFC INVERTNEXT
1 16 0 6 16 0 0 -36 2 0 0 0 -52 0 box3u2p.dat
1 16 28.5 6 16 -7.5 0 0 0 0 2 0 1 0 rect2p.dat
1 16 -28.5 6 16 -7.5 0 0 0 0 2 0 1 0 rect2p.dat
4 16 -40 8 -40 -40 8 20 -36 8 16 -36 8 -36
4 16 40 8 -40 -40 8 -40 -36 8 -36 36 8 -36
4 16 40 8 20 40 8 -40 36 8 -36 36 8 16
4 16 -21 4 16 -21 4 -19 -36 4 -36 -36 4 16
4 16 36 4 16 36 4 -36 21 4 -19 21 4 16
4 16 21 4 -19 36 4 -36 -36 4 -36 -21 4 -19
1 16 0 4 2 21 0 0 0 -1 0 0 0 -21 2-4ndis.dat
1 16 0 3 2 21 0 0 0 -1 0 0 0 -21 2-4disc.dat
0 BFC INVERTNEXT
1 16 0 3 2 -21 0 0 0 1 0 0 0 -21 2-4cylo.dat
0 BFC INVERTNEXT
1 16 0 4 9 0 0 -21 0 -1 0 -7 0 0 box3u5p.dat
1 16 20 4 -20 1 0 0 0 -1 0 0 0 1 stud4.dat
1 16 -20 4 -20 1 0 0 0 -1 0 0 0 1 stud4.dat
1 16 0 4 -20 0.70711 0 -0.70711 0 -1 0 -0.70711 0 -0.70711 1-4stud4.dat
1 16 4.95 8 -24.95 0.70711 0 0.70711 0 -4 0 -0.70711 0 0.70711 2-4cylc.dat
1 16 -4.95 8 -24.95 0.70711 0 -0.70711 0 -4 0 0.70711 0 0.70711 2-4cylc.dat
1 16 -7 2 30 0 14 0 -6 0 0 0 0 6 2-4cylo.dat
1 16 -40 2 30 0 8 0 -6 0 0 0 0 6 2-4cylo.dat
1 16 32 2 30 0 8 0 -6 0 0 0 0 6 2-4cylo.dat
1 16 40 2 30 0 -1 0 -6 0 0 0 0 6 2-4disc.dat
1 16 32 2 30 0 1 0 -6 0 0 0 0 6 2-4disc.dat
1 16 7 2 30 0 -1 0 -6 0 0 0 0 6 2-4disc.dat
1 16 -7 2 30 0 1 0 -6 0 0 0 0 6 2-4disc.dat
1 16 -32 2 30 0 -1 0 -6 0 0 0 0 6 2-4disc.dat
1 16 -40 2 30 0 1 0 -6 0 0 0 0 6 2-4disc.dat
1 16 13.75 -2 22 2.25 0 0 0 1 -2 0 0 2 rect.dat
1 16 26.25 -2 22 2.25 0 0 0 1 -2 0 0 2 rect.dat
1 16 -26.25 -2 22 2.25 0 0 0 1 -2 0 0 2 rect.dat
1 16 -13.75 -2 22 2.25 0 0 0 1 -2 0 0 2 rect.dat
1 16 -36 -2 22 4 0 0 0 1 -2 0 0 2 rect.dat
1 16 36 -2 22 4 0 0 0 1 -2 0 0 2 rect.dat
1 16 0 -2 22 7 0 0 0 1 -2 0 0 2 rect.dat
1 16 0 -4 27 0 0 -7 0 1 0 3 0 0 rect2p.dat
1 16 -36 -4 27 0 0 -4 0 1 0 3 0 0 rect2p.dat
1 16 36 -4 27 0 0 -4 0 1 0 3 0 0 rect2p.dat
0 BFC INVERTNEXT
1 16 -36 8 25 0 0 -1.5 0 -4 0 5 0 0 box5.dat
0 BFC INVERTNEXT
1 16 36 8 25 0 0 -1.5 0 -4 0 5 0 0 box5.dat
0 BFC INVERTNEXT
1 16 0 8 27 4.5 0 0 0 -8 0 0 0 3 box4-7a.dat
2 24 4.5 8 30 -4.5 8 30
1 16 0 2 22 4.5 0 0 0 -1 2 0 0 -2 rect.dat
4 16 -4.5 8 24 -4.5 0 24 -4.5 4 20 -4.5 8 20
4 16 4.5 8 20 4.5 4 20 4.5 0 24 4.5 8 24
1 16 -38.75 8 25 -1.25 0 0 0 -1 0 0 0 -5 rect1.dat
1 16 -33.25 8 25 1.25 0 0 0 -1 0 0 0 5 rect1.dat
1 16 -5.75 8 25 0 0 1.25 0 -1 0 -5 0 0 rect2p.dat
1 16 5.75 8 25 0 0 -1.25 0 -1 0 5 0 0 rect2p.dat
1 16 33.25 8 25 -1.25 0 0 0 -1 0 0 0 -5 rect1.dat
1 16 38.75 8 25 1.25 0 0 0 -1 0 0 0 5 rect1.dat
1 16 26.25 8 23 0 0 -2.25 0 -1 0 3 0 0 rect2p.dat
1 16 13.75 8 23 0 0 -2.25 0 -1 0 3 0 0 rect2p.dat
1 16 -13.75 8 23 0 0 -2.25 0 -1 0 3 0 0 rect2p.dat
1 16 -26.25 8 23 0 0 -2.25 0 -1 0 3 0 0 rect2p.dat
1 16 26.25 -4 25 0 0 -2.25 0 1 0 1 0 0 rect2p.dat
1 16 13.75 -4 25 0 0 -2.25 0 1 0 1 0 0 rect2p.dat
1 16 -13.75 -4 25 0 0 -2.25 0 1 0 1 0 0 rect2p.dat
1 16 -26.25 -4 25 0 0 -2.25 0 1 0 1 0 0 rect2p.dat
3 16 40 -4 24 40 0 20 40 -4 30
3 16 32 -4 24 32 -4 30 32 0 20
3 16 7 -4 24 7 0 20 7 -4 30
3 16 -7 -4 24 -7 -4 30 -7 0 20
3 16 -32 -4 24 -32 0 20 -32 -4 30
3 16 -40 -4 24 -40 -4 30 -40 0 20
3 16 -28.5 -4 24 -28.5 -4 26 -28.5 0 20
3 16 -24 -4 24 -24 0 20 -24 -4 26
3 16 -16 -4 24 -16 -4 26 -16 0 20
3 16 -11.5 -4 24 -11.5 0 20 -11.5 -4 26
3 16 11.5 -4 24 11.5 -4 26 11.5 0 20
3 16 16 -4 24 16 0 20 16 -4 26
3 16 24 -4 24 24 -4 26 24 0 20
3 16 28.5 -4 24 28.5 0 20 28.5 -4 26
4 16 40 8 20 40 8 30 40 -4 30 40 0 20
4 16 32 8 20 32 0 20 32 -4 30 32 8 30
4 16 7 8 20 7 8 30 7 -4 30 7 0 20
4 16 -7 8 20 -7 0 20 -7 -4 30 -7 8 30
4 16 -32 8 20 -32 8 30 -32 -4 30 -32 0 20
4 16 -40 8 20 -40 0 20 -40 -4 30 -40 8 30
4 16 -28.5 8 20 -28.5 0 20 -28.5 -4 26 -28.5 8 26
4 16 -24 8 20 -24 8 26 -24 -4 26 -24 0 20
4 16 -16 8 20 -16 0 20 -16 -4 26 -16 8 26
4 16 -11.5 8 20 -11.5 8 26 -11.5 -4 26 -11.5 0 20
4 16 11.5 8 20 11.5 0 20 11.5 -4 26 11.5 8 26
4 16 16 8 20 16 8 26 16 -4 26 16 0 20
4 16 24 8 20 24 0 20 24 -4 26 24 8 26
4 16 28.5 8 20 28.5 8 26 28.5 -4 26 28.5 0 20
1 16 -20 4 20 4 0 0 0 0 -4 0 -1 0 rect.dat
1 16 20 4 20 4 0 0 0 0 -4 0 -1 0 rect.dat
1 16 9.25 4 20 2.25 0 0 0 0 -4 0 -1 0 rect.dat
1 16 -9.25 4 20 2.25 0 0 0 0 -4 0 -1 0 rect.dat
1 16 -30.25 4 20 1.75 0 0 0 0 -4 0 -1 0 rect.dat
1 16 30.25 4 20 1.75 0 0 0 0 -4 0 -1 0 rect.dat

Status:

Official

This part has the following warnings

Decimal precision exceeds library recommendation

Line 32: 1 16 0 4 -20 0.70711 0 -0.70711 0 -1 0 -0.70711 0 -0.70711 1-4stud4.dat

Line 33: 1 16 4.95 8 -24.95 0.70711 0 0.70711 0 -4 0 -0.70711 0 0.70711 2-4cylc.dat

Line 34: 1 16 -4.95 8 -24.95 0.70711 0 -0.70711 0 -4 0 0.70711 0 0.70711 2-4cylc.dat
