File Detail parts/s/67696s01.dat

Official File parts/s/67696s01.dat

~Brick 2 x 2 with Axlehole and Ball Socket with Straight Closed Sides Half

File Header:

0 ~Brick  2 x  2 with Axlehole and Ball Socket with Straight Closed Sides Half
0 Name: s\67696s01.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Subpart UPDATE 2024-04
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2024-05-28 [OrionP] Official Update 2024-04

Show contents
