~Brick 5 x 5 x 3.333 Corner Round with Dome Top and 2 x 2 Cutout - Patternable Surfaces - Half

File Header:

0 ~Brick  5 x  5 x  3.333 Corner Round with Dome Top and  2 x  2 Cutout - Patternable Surfaces - Half
0 Name: s\76776s03.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Subpart UPDATE 2025-02
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2025-02-27 [OrionP] Official Update 2025-02
