0 ~Slope Brick Curved 6 x 4 Double without Patternable Surfaces
0 Name: s\78522s01.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Subpart UPDATE 2024-06
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2024-07-29 [OrionP] Official Update 2024-06
