Unofficial File parts/s/70694s01.dat
~Arrow with Solid Shaft and Tip Core
File Header:
0 ~Arrow with Solid Shaft and Tip Core 0 Name: s\70694s01.dat 0 Author: Philippe Hurbain [Philo] 0 !LDRAW_ORG Unofficial_Subpart 0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt 0 BFC CERTIFY CCW
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\70694s04.dat 1 16 0 0 0 1 0 0 0 -1 0 0 0 1 s\70694s04.dat 1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\70694s05.dat 1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\70694s05.dat 1 16 0 0 90 0 0 2 -3.5 0 0 0 -1 0 rect.dat 4 16 -2.1 -2.3 -71.4 -2.1 2.3 -71.4 2.1 2.3 -71.4 2.1 -2.3 -71.4
Status:
Not releaseable Needs 2 More Votes (N) Needs 2 More Votes (N)
This part has the following automated holds from the Parts Tracker
Current Votes:

None

Official parents and subparts
Part Events:
Philippe Hurbain [Philo]
Senior Part Reviewer
initially submitted the part.
2023-02-15 07:34:59
Willy Tschager [Holly-Wood]
Senior Part Reviewer
posted a vote of Hold.
2025-06-06 07:48:14
* Some hard rounding: -26.0003, -20.0998,

This overlaps in the main file:

2 368 -.0006 -7.5 -19.4416 -.0006 -7.5 -4.7918
Philippe Hurbain [Philo]
Senior Part Reviewer
submitted a new version of the part.
2025-06-09 12:56:24
Various flipping/shape improvements
Philippe Hurbain [Philo]
Senior Part Reviewer
submitted a new version of the part.
2025-06-09 13:23:45
Added miising conds mentionned in main part
Willy Tschager [Holly-Wood]
Senior Part Reviewer
posted a vote of Certify.
2025-06-09 13:57:04
Takeshi Takahashi [RainbowDolphin]
Senior Part Reviewer
posted a vote of Certify.
2025-06-17 15:20:33
Philippe Hurbain [Philo]
Senior Part Reviewer
submitted a new version of the part.
2025-06-27 08:18:43
Completed shaft tip, refactored subparting, changed description. Not sure about the chosen category...
Magnus Forsberg [MagFors]
Part Library Admin
made the following comment.
2026-03-25 17:48:26
The description need editing. This is not a "... Front Half". What is it?
Philippe Hurbain [Philo]
Senior Part Reviewer
edited the part header.
2026-03-26 08:05:26
Header Edits

description:
~Arrow with Solid Shaft Front Half
to
~Arrow with Solid Shaft and Tip Core

Comment:
Corrected description
Creative Commons Attribution License information

This part is copyright © Philippe Hurbain
Licensed under CC BY 4.0
