Official File parts/3460py0.dat
Part Attributes:
Base Part: 3460.dat
File Header:
0 Plate 1 x 8 with Four Black Slots with Orange Outer Frame Pattern
0 Name: 3460py0.dat
0 Author: Massimo Maso [Sirio]
0 !LDRAW_ORG Part UPDATE 2024-05
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !KEYWORDS BrickLink 3460pb01, McLaren, Rebrickable 3460pr0001, Set 76918
0 !KEYWORDS Solus, Speed Champions
0 !HISTORY 2024-06-30 [OrionP] Official Update 2024-05
Show contents
0 // Subparts
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\3460s01.dat
0 // Primitives
1 191 -41 4 -10 0 0 .75 -.75 0 0 0 1 0 1-4ring2.dat
1 191 -68.5 4 -10 0 0 -.75 -.75 0 0 0 1 0 1-4ring2.dat
1 16 -68.5 4 -10 0 0 -2.25 2.25 0 0 0 1 0 2-4ndis.dat
1 0 -68.5 4 -10 0 0 -1.5 1.5 0 0 0 1 0 2-4chrd.dat
1 0 -41 4 -10 0 0 1.5 1.5 0 0 0 1 0 2-4chrd.dat
1 16 -41 4 -10 0 0 2.25 2.25 0 0 0 1 0 2-4ndis.dat
1 484 -68.5 4 -10 0 0 -.75 .75 0 0 0 1 0 1-4ring2.dat
1 484 -41 4 -10 0 0 .75 .75 0 0 0 1 0 1-4ring2.dat
1 191 -4.5 4 -10 0 0 .75 -.75 0 0 0 1 0 1-4ring2.dat
1 191 -32 4 -10 0 0 -.75 -.75 0 0 0 1 0 1-4ring2.dat
1 16 -32 4 -10 0 0 -2.25 2.25 0 0 0 1 0 2-4ndis.dat
1 0 -32 4 -10 0 0 -1.5 1.5 0 0 0 1 0 2-4chrd.dat
1 0 -4.5 4 -10 0 0 1.5 1.5 0 0 0 1 0 2-4chrd.dat
1 16 -4.5 4 -10 0 0 2.25 2.25 0 0 0 1 0 2-4ndis.dat
1 484 -32 4 -10 0 0 -.75 .75 0 0 0 1 0 1-4ring2.dat
1 484 -4.5 4 -10 0 0 .75 .75 0 0 0 1 0 1-4ring2.dat
1 191 4.5 4 -10 0 0 -.75 -.75 0 0 0 1 0 1-4ring2.dat
1 191 32 4 -10 0 0 .75 -.75 0 0 0 1 0 1-4ring2.dat
1 16 32 4 -10 0 0 2.25 2.25 0 0 0 1 0 2-4ndis.dat
1 0 32 4 -10 0 0 1.5 1.5 0 0 0 1 0 2-4chrd.dat
1 0 4.5 4 -10 0 0 -1.5 1.5 0 0 0 1 0 2-4chrd.dat
1 16 4.5 4 -10 0 0 -2.25 2.25 0 0 0 1 0 2-4ndis.dat
1 484 32 4 -10 0 0 .75 .75 0 0 0 1 0 1-4ring2.dat
1 484 4.5 4 -10 0 0 -.75 .75 0 0 0 1 0 1-4ring2.dat
1 191 41 4 -10 0 0 -.75 -.75 0 0 0 1 0 1-4ring2.dat
1 191 68.5 4 -10 0 0 .75 -.75 0 0 0 1 0 1-4ring2.dat
1 16 68.5 4 -10 0 0 2.25 2.25 0 0 0 1 0 2-4ndis.dat
1 0 68.5 4 -10 0 0 1.5 1.5 0 0 0 1 0 2-4chrd.dat
1 0 41 4 -10 0 0 -1.5 1.5 0 0 0 1 0 2-4chrd.dat
1 16 41 4 -10 0 0 -2.25 2.25 0 0 0 1 0 2-4ndis.dat
1 484 68.5 4 -10 0 0 .75 .75 0 0 0 1 0 1-4ring2.dat
1 484 41 4 -10 0 0 -.75 .75 0 0 0 1 0 1-4ring2.dat
0 // Complementary faces
0 // Black faces
4 0 -68.5 2.5 -10 -68.5 5.5 -10 -41 5.5 -10 -41 2.5 -10
4 0 -32 2.5 -10 -32 5.5 -10 -4.5 5.5 -10 -4.5 2.5 -10
4 0 4.5 2.5 -10 4.5 5.5 -10 32 5.5 -10 32 2.5 -10
4 0 41 2.5 -10 41 5.5 -10 68.5 5.5 -10 68.5 2.5 -10
0 // Bright Light Orange
4 191 -68.5 1.75 -10 -68.5 2.5 -10 -41 2.5 -10 -41 1.75 -10
4 191 -32 1.75 -10 -32 2.5 -10 -4.5 2.5 -10 -4.5 1.75 -10
4 191 4.5 1.75 -10 4.5 2.5 -10 32 2.5 -10 32 1.75 -10
4 191 41 1.75 -10 41 2.5 -10 68.5 2.5 -10 68.5 1.75 -10
0 // Light Orange Brown
4 484 -68.5 5.5 -10 -68.5 6.25 -10 -41 6.25 -10 -41 5.5 -10
4 484 -32 5.5 -10 -32 6.25 -10 -4.5 6.25 -10 -4.5 5.5 -10
4 484 4.5 5.5 -10 4.5 6.25 -10 32 6.25 -10 32 5.5 -10
4 484 41 5.5 -10 41 6.25 -10 68.5 6.25 -10 68.5 5.5 -10
0 // Neutral faces
4 16 -80 0 -10 -80 8 -10 -70.75 4 -10 -70.75 1.75 -10
3 16 -80 0 -10 -70.75 1.75 -10 -68.5 1.75 -10
3 16 -80 0 -10 -68.5 1.75 -10 -41 1.75 -10
3 16 -80 0 -10 -41 1.75 -10 -38.75 1.75 -10
3 16 -80 0 -10 -38.75 1.75 -10 -34.25 1.75 -10
3 16 -80 0 -10 -34.25 1.75 -10 -32 1.75 -10
3 16 -80 0 -10 -32 1.75 -10 -4.5 1.75 -10
3 16 -80 0 -10 -4.5 1.75 -10 -2.25 1.75 -10
4 16 -80 0 -10 -2.25 1.75 -10 2.25 1.75 -10 80 0 -10
3 16 80 0 -10 2.25 1.75 -10 4.5 1.75 -10
3 16 80 0 -10 4.5 1.75 -10 32 1.75 -10
3 16 80 0 -10 32 1.75 -10 34.25 1.75 -10
3 16 80 0 -10 34.25 1.75 -10 38.75 1.75 -10
3 16 80 0 -10 38.75 1.75 -10 41 1.75 -10
3 16 80 0 -10 41 1.75 -10 68.5 1.75 -10
3 16 80 0 -10 68.5 1.75 -10 70.75 1.75 -10
4 16 80 0 -10 70.75 1.75 -10 70.75 4 -10 80 8 -10
4 16 -38.75 4 -10 -34.25 4 -10 -34.25 1.75 -10 -38.75 1.75 -10
4 16 -38.75 4 -10 -38.75 6.25 -10 -34.25 6.25 -10 -34.25 4 -10
4 16 -2.25 4 -10 2.25 4 -10 2.25 1.75 -10 -2.25 1.75 -10
4 16 -2.25 4 -10 -2.25 6.25 -10 2.25 6.25 -10 2.25 4 -10
4 16 34.25 4 -10 38.75 4 -10 38.75 1.75 -10 34.25 1.75 -10
4 16 34.25 4 -10 34.25 6.25 -10 38.75 6.25 -10 38.75 4 -10
3 16 -80 8 -10 -70.75 6.25 -10 -70.75 4 -10
3 16 -80 8 -10 -68.5 6.25 -10 -70.75 6.25 -10
3 16 -80 8 -10 -41 6.25 -10 -68.5 6.25 -10
3 16 -80 8 -10 -38.75 6.25 -10 -41 6.25 -10
3 16 -80 8 -10 -34.25 6.25 -10 -38.75 6.25 -10
3 16 -80 8 -10 -32 6.25 -10 -34.25 6.25 -10
3 16 -80 8 -10 -4.5 6.25 -10 -32 6.25 -10
3 16 -80 8 -10 -2.25 6.25 -10 -4.5 6.25 -10
4 16 -80 8 -10 80 8 -10 2.25 6.25 -10 -2.25 6.25 -10
3 16 80 8 -10 4.5 6.25 -10 2.25 6.25 -10
3 16 80 8 -10 32 6.25 -10 4.5 6.25 -10
3 16 80 8 -10 34.25 6.25 -10 32 6.25 -10
3 16 80 8 -10 38.75 6.25 -10 34.25 6.25 -10
3 16 80 8 -10 41 6.25 -10 38.75 6.25 -10
3 16 80 8 -10 68.5 6.25 -10 41 6.25 -10
3 16 80 8 -10 70.75 6.25 -10 68.5 6.25 -10
3 16 80 8 -10 70.75 4 -10 70.75 6.25 -10
Status:
Official
Unofficial parents
Part Events:
Archived Part Events:
2023-04-03 23:09:58
2024-06-09 18:35:08
If you tell me the code to use, I'll fix it.
2024-06-09 18:55:15
the code itself looks ok because you used quarter rings, maybe just color the lower rings in a darker orange...
(which colors are used in this part?)
(which colors are used in this part?)
I looked at the asset from Lego Builder app and the Bright Light Orange (191) is fine but the Light Orange Brown (507) must be replaced by Dark Orange (484)
2024-06-10 16:37:10
2024-06-10 17:30:59
2024-06-10 17:33:13
2024-06-27 01:55:22
2024-06-30 00:13:52
Release 2024-05
