File Detail parts/3068bpm2.dat

Download Download zip file View patterns/composites/shortcuts

Official File parts/3068bpm2.dat

Part Attributes: Base Part: 3068b.dat

External Sites:

View on Rebrickable View on BrickLink View on Brickset View on BrickOwl

Tile 2 x 2 with Groove with Dark Orange, Olive Green, Nougat, and Sand Blue Pattern

File Header:

0 Tile  2 x  2 with Groove with Dark Orange, Olive Green, Nougat, and Sand Blue Pattern
0 Name: 3068bpm2.dat
0 Author: Florent Faramond [Makou]
0 !LDRAW_ORG Part UPDATE 2023-02
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !KEYWORDS BrickLink 3068pb2182, Lord of the Rings, LOTR
0 !KEYWORDS Rebrickable 3068bpr0674, Rivendell, Set 10316

0 !HISTORY 2023-04-17 [OrionP] Official Update 2023-02
