Official File parts/s/3487s02.dat
File Header:
0 ~Brick 8 x 10 x 2 with 6 x 10 Cutout and 8 Pin Holes on Sides Half
0 Name: s\3487s02.dat
0 Author: Philippe Hurbain [Philo]
0 !LDRAW_ORG Subpart UPDATE 2024-06
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !HISTORY 2024-07-29 [OrionP] Official Update 2024-06
Show contents
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\3487s01.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 -1 s\3487s01.dat
1 16 70 12 0 0 0 -10 0 -12 0 -100 0 0 box2-5.dat
4 16 80 0 -100 80 3 -43.6361 80 3 43.6361 80 0 100
4 16 80 25 -41 80 25 41 80 3 43.6361 80 3 -43.6361
4 16 80 25 41 80 25 -41 80 43 -41 80 43 41
4 16 80 48 100 80 43 41 80 43 -41 80 48 -100
2 24 80 48 -100 80 48 100
2 24 80 48 100 -80 48 100
4 16 60 24 100 31 25 100 -31 25 100 -60 24 100
4 16 -31 43 100 -31 25 100 31 25 100 31 43 100
4 16 -31 43 100 31 43 100 80 48 100 -80 48 100
1 16 0 27 90 -31 0 0 0 -1 0 0 0 6 rect2p.dat
4 16 31 43 96 31 27 96 -31 27 96 -31 43 96
4 16 76 48 96 31 43 96 -31 43 96 -76 48 96
2 24 -76 48 96 76 48 96
4 16 -80 48 100 80 48 100 76 48 96 -76 48 96
4 16 80 48 -100 76 48 -96 76 48 96 80 48 100
4 16 76 43 -41 76 43 41 76 48 96 76 48 -96
2 24 76 48 -96 76 48 96
1 16 76 23 0 0 1 0 -20 0 0 0 0 41 rect1.dat
1 16 70 3 0 -6 0 0 0 -1 0 0 0 41 rect1.dat
4 16 64 3 41 64 3 -41 64 43 -41 64 43 41
4 16 64 48 84 64 43 41 64 43 -41 64 48 -84
2 24 64 48 -84 64 48 84
4 16 62 48 -58 62 48 58 64 48 84 64 48 -84
1 16 61 48 0 -1 0 0 0 -1 0 0 0 42 rect1.dat
1 16 0 37 80 0 0 32 11 0 0 0 1 0 rect1.dat
4 16 32 48 82 32 48 80 -32 48 80 -32 48 82
4 16 -31 43 84 31 43 84 64 48 84 -64 48 84
4 16 48 48 82 -48 48 82 -64 48 84 64 48 84
2 24 64 48 84 -64 48 84
4 16 31 43 84 -31 43 84 -31 27 84 31 27 84
4 16 60 26 -42 60 26 42 60 48 42 60 48 -42
4 16 16 48 -36 16 48 36 20 48 40 20 48 -40
4 16 16 48 36 -16 48 36 -20 48 40 20 48 40
1 16 50 26.6088 10 1.43822 0 7.39901 0 1 0 -7.39901 0 1.43822 2-4edge.dat
1 16 50 27.1088 10 1.27842 0 6.5769 0 1 0 -6.5769 0 1.27842 2-4edge.dat
1 16 50 26.6088 10 0.1598 0 0.82211 0 0.5 0 -0.82211 0 0.1598 2-4con8.dat
1 16 50 27.1088 10 1.27842 0 6.5769 0 -1 0 -6.5769 0 1.27842 2-4chrd.dat
1 16 1.3583 26.8588 -6.98795 50 0 0.0799 0 -1 -0.25 10 0 -0.41105 rect2p.dat
2 24 20 26.6088 -3.6867 20 27.1088 -2.8326
2 24 20 27.1088 10.8326 20 26.6088 11.6867
2 24 16 27.1088 -3.6326 16 26.6088 -4.4867
2 24 16 27.1088 10.0326 16 26.6088 10.8867
2 24 20 27.1088 -2.8326 20 27.1088 10.8326
2 24 16 27.1088 -3.6326 16 27.1088 10.0326
3 16 48.7216 27.1088 16.5769 51.2784 27.1088 3.4231 -48.7216 27.1088 -16.5769
1 16 0 27.1088 0 8 0 0 0 -1 0 0 0 -8 1-8edge.dat
1 16 0 27.1088 0 8 0 0 0 -1 0 0 0 8 3-16edge.dat
1 16 0 26.6088 0 0 0 8 0 -1 0 -8 0 0 1-16edge.dat
2 24 5.5619 27.1088 -5.7202 5.6568 27.1088 -5.6568
2 24 3.0616 26.6088 -7.3912 3.7382 26.6088 -6.939
2 24 5.5619 27.1088 -5.7202 3.7382 26.6088 -6.939
2 24 3.0616 27.1088 7.3912 2.9269 27.1088 7.418
2 24 0.7856 26.6088 7.8438 0 26.6088 8
2 24 2.9269 27.1088 7.418 0.7856 26.6088 7.8438
1 16 0 26.6088 20 1 0 0 0 -5.3478 0 0 0 1 stud4.dat
1 16 11.9006 27.1088 0 -4.0994 0 0 0 15 0 0 0 1 box3u4p.dat
2 24 16 42.1088 -1 16 42.1088 1
2 24 8 42.1088 0 7.8012 42.1088 1
2 24 8 42.1088 0 7.8012 42.1088 -1
