File Detail parts/32225.dat

Official File parts/32225.dat

Part Attributes:

External Sites:

View on Rebrickable View on BrickLink View on BrickOwl

File Header:

0 Znap Grid  9 x  7 x  4 Motor Holder
0 Name: 32225.dat
0 Author: Gerald Lasser [GeraldLasser]
0 !LDRAW_ORG Part UPDATE 2024-02
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 !HELP Only compatible with 4019.dat 16 Tooth Gear

0 BFC CERTIFY CCW

0 !HISTORY 2023-05-18 [Philo] Basic Sketch
0 !HISTORY 2023-08-25 [OrionP] Official Update 2023-04
0 !HISTORY 2024-03-23 [OrionP] Updated ring primitives
0 !HISTORY 2024-03-24 [OrionP] Official Update 2024-02

Show contents

1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\32225s01.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 -1 s\32225s01.dat

5 24 95 -32 0 95 -50 0 94.4502 -50 -8 94.4502 -32 8
5 24 95 10 0 95 -8 0 94.4502 -8 -8 94.4502 -8 8
5 24 -3 -7 0 -3 -10 0 -2.0107 -10 -4.9751 -2.0107 -10 4.9751

0 // 16T Gear Holder
0 BFC INVERTNEXT
1 16 40 -30 0 0 0 -9.5 0 4 0 9.5 0 0 2-4cylo.dat
1 16 40 -30 0 0 0 -9.5 0 1 0 9.5 0 0 2-4ndis.dat
1 16 40 -26 0 0 0 -9.5 0 -1 0 9.5 0 0 2-4ndis.dat
1 16 80 -32 0 0 0 6 0 -1 0 -6 0 0 2-4ndis.dat
1 16 80 -32 0 0 0 6 0 -1 0 -6 0 0 4-4edge.dat
1 16 80 -32 0 0 0 -2 0 -1 0 2 0 0 2-4ring3.dat
0 BFC INVERTNEXT
1 16 80 -30 0 0 0 -8 0 -2 0 8 0 0 2-4cylo.dat
1 16 80 -30 0 0 0 -8 0 -1 0 8 0 0 2-4ndis.dat
1 16 80 -8 0 -6 0 0 0 1 0 0 0 -6 4-4ndis.dat
1 16 80 10 0 -1 0 0 0 -1 0 0 0 -1 peghole.dat
3 16 57.484 -30 9.9768 72 -30 0 57.484 -30 -9.9768
0 BFC INVERTNEXT
1 16 80 8 0 -6 0 0 0 -16 0 0 0 -6 4-4cylo.dat
1 16 40 -8 0 0 0 -2 0 1 0 2 0 0 2-4ring3.dat
0 BFC INVERTNEXT
1 16 40 -8 0 0 0 -8 0 -2 0 8 0 0 2-4cylo.dat
0 BFC INVERTNEXT
1 16 40 -14 0 0 0 -9.5 0 4 0 9.5 0 0 2-4cylo.dat
1 16 40 -10 0 0 0 -1 0 1 0 1 0 0 2-4ring8.dat
1 16 40 -10 0 0 0 -.5 0 1 0 .5 0 0 2-4ring18.dat
1 16 40 -14 0 0 0 -9.5 0 1 0 9.5 0 0 2-4ndis.dat
1 16 40 -8 0 0 0 6 0 1 0 6 0 0 2-4ndis.dat
1 16 40 10 0 -1 0 0 0 -1 0 0 0 -1 peghole.dat
0 BFC INVERTNEXT
1 16 40 8 0 -6 0 0 0 -16 0 0 0 -6 4-4cylo.dat

1 16 80 -50 0 -1 0 0 0 1 0 0 0 -1 peghole.dat
0 BFC INVERTNEXT
1 16 80 -48 0 -6 0 0 0 16 0 0 0 -6 4-4cyli.dat

4 16 57.484 -30 9.9768 57.484 -30 -9.9768 57.4819 -50 -13.0007 57.4819 -50 13.0007
3 16 70.2983 -50 -1.5 72 -50 0 70.2983 -50 1.5
4 16 60.082 -50 -1.5 70.2983 -50 -1.5 70.2983 -50 1.5 60.082 -50 1.5
4 16 57.4819 -50 -13.0007 60.082 -50 -1.5 60.082 -50 1.5 57.4819 -50 13.0007
3 16 89.7017 -50 1.5 88 -50 0 89.7017 -50 -1.5
4 16 91.9011 -50 -1.5 91.9011 -50 1.5 89.7017 -50 1.5 89.7017 -50 -1.5
3 16 91.9011 -50 1.5 91.9011 -50 -1.5 95 -50 0
2 24 57.4819 -50 13.0007 57.4819 -50 -13.0007
2 24 57.484 -30 9.9768 57.484 -30 -9.9768

3 16 -25 -10 7 -25 -10 -7 -3 -10 0
2 24 -25 -10 -7 -25 -10 7

4 16 -10 10 -1.5 -21 10 -1.5 -21 10 1.5 -10 10 1.5
4 16 -10 10 -1.5 -10 10 1.5 -6 10 1.5 -6 10 -1.5
4 16 -21 10 1.5 -21 10 -1.5 -25 10 -30 -25 10 30
4 16 95 10 0 91.9011 10 -1.5 89.7017 10 1.5 91.9011 10 1.5
4 16 91.9011 10 -1.5 89.7017 10 -1.5 88 10 0 89.7017 10 1.5
3 16 72 10 0 70.2983 10 -1.5 70.2983 10 1.5
4 16 65.9011 10 1.5 70.2983 10 1.5 70.2983 10 -1.5 65.9011 10 -1.5
4 16 65.9011 10 1.5 65.9011 10 -1.5 62.9021 10 -1.5 62.9021 10 1.5
4 16 62.9021 10 1.5 62.9021 10 -1.5 49.7017 10 -1.5 49.7017 10 1.5
3 16 48 10 0 49.7017 10 1.5 49.7017 10 -1.5
3 16 32 10 0 30.2983 10 -1.5 30.2983 10 1.5
4 16 30.2983 10 -1.5 17.0989 10 -1.5 17.0989 10 1.5 30.2983 10 1.5
4 16 14.0989 10 1.5 17.0989 10 1.5 17.0989 10 -1.5 14.0989 10 -1.5
4 16 14.0989 10 -1.5 -6 10 -1.5 -6 10 1.5 14.0989 10 1.5
4 16 -25 -10 -7 -25 -10 7 -25 10 30 -25 10 -30
2 24 -25 10 30 -25 10 -30

0 BFC INVERTNEXT
1 16 -25 0 0 0 -45 0 -10 0 0 0 0 30 box3u2p.dat
1 16 -80 0 0 1 0 0 0 -1 0 0 0 1 connhole.dat
3 16 -70 10 -30 -71 10 0 -70 10 30
3 16 -70 -10 30 -71 -10 0 -70 -10 -30
