Technic Engine Cylinder Head with Side Slots

File Header:

0 Technic Engine Cylinder Head with Side Slots
0 Name: 2850a.dat
0 Author: Jeff Boen [onyx]
0 !LDRAW_ORG Part UPDATE 2018-01
0 !LICENSE Licensed under CC BY 2.0 and CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 1998-03-23 [PTadmin] Official Update 1998-03
0 !HISTORY 1999-05-24 [PTadmin] Official Update 1999-04
0 !HISTORY 2004-06-23 [guyvivan] Made BFC Compliant, added missing lines and quads, Corrected error engine block, Corrected bad vertex sequence
0 !HISTORY 2004-11-06 [PTadmin] Official Update 2004-04
0 !HISTORY 2007-05-20 [PTadmin] Header formatted for Contributor Agreement
0 !HISTORY 2008-07-01 [PTadmin] Official Update 2008-01
0 !HISTORY 2015-02-22 [Philo] Subparted geometry common with 2850b
0 !HISTORY 2015-02-23 [PTadmin] Renamed from 2850
0 !HISTORY 2015-11-12 [MMR1988] Adapted to reworked subpart
0 !HISTORY 2018-01-30 [PTadmin] Official Update 2018-01
