Unofficial File parts/u9603.dat
Warning: Model breaking changes to unofficial parts may occur anytime prior to release
0 ~Electric Train 12V Transformer Type 1 Bottom
0 Name: u9603.dat
0 Author: Rene Rechthaler [Blechtaler]
0 !LDRAW_ORG Unofficial_Part
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt
0 BFC CERTIFY CCW
0 !CATEGORY ElectricShow file code:
1 16 0 0 0 1 0 0 0 1 0 0 0 1 s\u9603s01.dat
1 16 0 0 0 1 0 0 0 1 0 0 0 -1 s\u9603s01.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 1 s\u9603s01.dat
1 16 0 0 0 -1 0 0 0 1 0 0 0 -1 s\u9603s01.dat
1 16 0 -8 50 50 0 0 0 8 0 0 0 4 box3u8p.dat
1 16 0 -8 -50 50 0 0 0 8 0 0 0 4 box3u8p.dat
1 16 60 -8 0 0 0 4 0 8 0 40 0 0 box3u8p.dat
1 16 -60 -8 0 0 0 4 0 8 0 40 0 0 box3u8p.dat
0 BFC INVERTNEXT
1 16 0 -4 90 50 0 0 0 -4 0 0 0 36 box2-11.dat
0 BFC INVERTNEXT
1 16 0 -4 -90 50 0 0 0 -4 0 0 0 -36 box2-11.dat
0 BFC INVERTNEXT
1 16 100 -4 0 0 0 36 0 -4 0 40 0 0 box2-11.dat
0 BFC INVERTNEXT
1 16 -100 -4 0 0 0 -36 0 -4 0 40 0 0 box2-11.dat
4 16 -50 -8 46 50 -8 46 56 -8 40 -56 -8 40
4 16 -56 -8 40 56 -8 40 56 -8 -40 -56 -8 -40
4 16 -56 -8 -40 56 -8 -40 50 -8 -46 -50 -8 -46
0 // Bottom imprint (view from below)
0 // ╔═╦════════════════════════════╦═╗
0 // ║ ║ Siemens .................. ║ ║
0 // ╠═╬════════════════════════════╬═╣
0 // ║ ║ Transformator~ ....... 740 ║ ║
0 // ║ ║ prim 220V ........ 50/60Hz ║ ║
0 // ║ ║ secI 0-13V-.......... 11VA ║ ║
0 // ║ ║ secII 16V~ .......... 16VA ║ ║
0 // ║ ║ secIII 3,6V~ ......... 6VA ║ ║
0 // ╠═╬════════════════════════════╬═╣
0 // ║ ║ (lotsa electrical permits) ║ ║=== Cable
0 // ╚═╩════════════════════════════╩═╝
0 // electric contacts are on the left side
1 16 0 -8 125 0 0 140 8 0 0 0 5 0 box3u2p.dat
1 16 0 -8 -125 0 0 140 8 0 0 0 -5 0 box3u2p.dat
2 24 50 0 126 -50 0 126
2 24 50 0 -126 -50 0 -126
4 16 140 0 130 50 0 126 -50 0 126 -140 0 130
4 16 -140 0 -130 -50 0 -126 50 0 -126 140 0 -130
1 16 140 -8 0 0 -1 0 8 0 0 0 0 103 rect.dat
0 BFC INVERTNEXT
1 16 -138 -21.6568 -70 0 0 2 0 5.6568 0 11 0 0 box2-11.dat
1 16 -136 -27.3136 -70 0 1 0 0 0 -11 11 0 0 2-4chrd.dat
2 24 -140 0 103 -140 0 -103
2 24 -140 -16 -81 -140 -16 -103
2 24 -140 -16 -81 -140 -16 -59
2 24 -140 -16 -59 -140 -16 103
2 24 -140 0 103 -140 -16 103
2 24 -140 0 -103 -140 -16 -103
3 16 -140 0 -103 -140 -16 -103 -140 -16 -81
3 16 -140 0 103 -140 -16 -59 -140 -16 103
4 16 -140 -16 -59 -140 0 103 -140 0 -103 -140 -16 -81
4 16 140 0 103 140 0 -103 136 0 -40 136 0 40
4 16 -140 0 -103 -140 0 103 -136 0 40 -136 0 -40
2 24 136 0 -40 136 0 40
2 24 -136 0 40 -136 0 -40
1 16 135 -40 -8 1 0 0 0 1 0 0 0 1 s\u9603s02.dat
1 16 135 -75 -8 1 0 0 0 -1 0 0 0 -1 s\u9603s02.dat
1 16 135 -40 -44 1 0 0 0 1 0 0 0 1 s\u9603s02.dat
1 16 135 -75 -44 1 0 0 0 -1 0 0 0 -1 s\u9603s02.dat
1 16 135 -40 -80 1 0 0 0 1 0 0 0 1 s\u9603s02.dat
1 16 135 -75 -80 1 0 0 0 -1 0 0 0 -1 s\u9603s02.datStatus
Errors Found (HN)
Current Votes:
Willy Tschager [Holly-Wood]
This part has the following automated holds from the Parts Tracker
-
Has Uncertified Subfiles
Part Dependencies
Official parents and subparts
Part Events
Rene Rechthaler [Blechtaler]
initially submitted the part.
2023-07-08 13:06:46
Rene Rechthaler [Blechtaler]
made the following comment.
2023-07-08 13:18:18
why does this not find its subparts but s01 does? they are all linked the same? why does the PT flip / and \ ?
Rene Rechthaler [Blechtaler]
submitted a new version of the part (all votes reset).
2023-07-08 14:01:42
with different subpart links and NBSPs to prevent the table from getting broken
Magnus Forsberg [MagFors]
renamed the part.
2024-01-06 12:35:07
"parts/s/740as03.dat" to "parts/.dat"
Magnus Forsberg [MagFors]
renamed the part.
2024-01-06 12:35:31
"parts/.dat" to "parts/u9603.dat"
Magnus Forsberg [MagFors]
made the following comment.
2024-01-07 08:50:09
Please add an edge ring indicating where the cable end should be placed.
Steffen [Steffen]
posted a vote of Hold
2024-02-11 05:05:05
if this is the bottom, then why does it have 3 floating plug parts?
I suggest to add 1 more ~part file which represents one of these plug innards.
I suggest to add 1 more ~part file which represents one of these plug innards.
Rene Rechthaler [Blechtaler]
made the following comment.
2024-09-27 17:28:44
the 3 "floating plug sockets" are the same part, but I dont know how these are connected (but they are)...
and why the edge ring for the cable? there isnt a cutout in this part (only in the top)
i wanted to include an ASCII table in the code, but the spaces get autodeleted, why?
example: (works better with monoblock fonts like in the code)
__________
/ \
| |
| text |
| |
\__________/
and why the edge ring for the cable? there isnt a cutout in this part (only in the top)
i wanted to include an ASCII table in the code, but the spaces get autodeleted, why?
example: (works better with monoblock fonts like in the code)
__________
/ \
| |
| text |
| |
\__________/
Rene Rechthaler [Blechtaler]
made the following comment.
2024-09-27 17:31:42
damn here too, why does it always delete if there are more than 2 spaces?
Rene Rechthaler [Blechtaler]
made the following comment.
2024-09-27 17:34:52
wanted to generate something like this:
╔══╦══╦══╗
║ ║ ║ ║
╠══╬══╬══╣
║ ║ ║ ║
╠══╬══╬══╣
║ ║ ║ ║
╚══╩══╩══╝
but with aligned lines (imagine a chocolate bar)
╔══╦══╦══╗
║ ║ ║ ║
╠══╬══╬══╣
║ ║ ║ ║
╠══╬══╬══╣
║ ║ ║ ║
╚══╩══╩══╝
but with aligned lines (imagine a chocolate bar)
Rene Rechthaler [Blechtaler]
submitted a new version of the part (all votes reset).
2024-10-01 16:09:37
fixed the origin
Rene Rechthaler [Blechtaler]
submitted a new version of the part (all votes reset).
2024-11-29 17:55:12
bottom imprints with electrical data
Willy Tschager [Holly-Wood]
made the following comment.
2025-08-24 13:41:05
* A part cannot have floating plugs
Rene Rechthaler [Blechtaler]
made the following comment.
2025-08-24 19:10:32
they are connected, but I dont know how...
(i guess there are big side plates, but cant confirm without opening one)
(i guess there are big side plates, but cant confirm without opening one)
Willy Tschager [Holly-Wood]
posted a vote of Hold
2026-06-02 12:16:38
* Upgrading to HOLD
