Official File parts/s/6177970es07.dat
~Sticker 1.9 x 3.8 with Indicators on Black and Grey Background - Inner Lamp
0 ~Sticker  1.9 x  3.8 with Indicators on Black and Grey Background - Inner Lamp
0 Name: s\6177970es07.dat
0 Author: Massimo Maso [Sirio]
0 !LDRAW_ORG Subpart UPDATE 2025-07
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2025-07-27 [OrionP] Official Update 2025-07
Show file code:
0 // Primitives
1 71 0 0 0 2.5 0 0 0 1 0 0 0 2.5 4-4ndis.dat
1 0 0 0 0 .5 0 0 0 1 0 0 0 .5 4-4ring4.dat
1 0 0 0 0 .25 0 0 0 1 0 0 0 .25 4-4ring7.dat
1 16 0 0 0 1.75 0 0 0 1 0 0 0 1.75 1-8chrd.dat
1 16 0 0 0 0 0 1.75 0 1 0 1.75 0 0 1-8chrd.dat
1 16 0 0 0 -1.75 0 0 0 1 0 0 0 1.75 1-4chrd.dat
1 16 0 0 0 -1.75 0 0 0 1 0 0 0 -1.75 1-4chrd.dat
1 16 0 0 0 0 0 1.75 0 1 0 -1.75 0 0 1-8chrd.dat
1 16 0 0 0 1.75 0 0 0 1 0 0 0 -1.75 1-8chrd.dat
1 16 1.15 0 .4 -.2 0 0 0 1 0 0 0 .2 2-4ndis.dat
1 15 1.15 0 .4 .2 0 0 0 1 0 0 0 .2 2-4chrd.dat
1 16 .05 0 .3 .9 0 0 0 1 0 0 0 -.9 1-4chrd.dat
1 15 .05 0 .3 .9 0 0 0 1 0 0 0 -.9 1-4ndis.dat
1 15 .6 0 -.35 .8 0 0 0 1 0 0 0 -.8 1-4chrd.dat
1 16 .6 0 -.35 .1 0 0 0 1 0 0 0 -.1 1-4ring8.dat
1 16 -.25 0 -.8 0 0 -.2 0 1 0 .2 0 0 2-4ndis.dat
1 15 -.25 0 -.8 0 0 -.2 0 1 0 .2 0 0 2-4chrd.dat
0 // Faces
0 // White faces
4 15 1.4 0 -.35 1.35 0 .4 .95 0 .4 .95 0 .3
3 15 .95 0 -.6 1.4 0 -.35 .95 0 .3
3 15 .95 0 -.6 .6 0 -1.15 1.4 0 -.35
3 15 .95 0 -.6 .05 0 -.6 .6 0 -1.15
4 15 .6 0 -1.15 .05 0 -.6 -.25 0 -.6 -.25 0 -1
0 // Neutral faces
4 16 1.4 0 -.35 1.5 0 -.35 1.75 0 0 1.35 0 .4
3 16 1.75 0 0 1.35 0 .6 1.35 0 .4
3 16 1.75 0 0 1.237425 0 1.237425 1.35 0 .6
4 16 0 0 1.75 1.15 0 .6 1.35 0 .6 1.237425 0 1.237425
3 16 0 0 1.75 .95 0 .6 1.15 0 .6
3 16 0 0 1.75 .95 0 .4 .95 0 .6
4 16 0 0 1.75 .05 0 -.6 .95 0 .3 .95 0 .4
3 16 0 0 1.75 -.25 0 -.6 .05 0 -.6
4 16 0 0 1.75 -1.75 0 0 -.45 0 -.6 -.25 0 -.6
3 16 -1.75 0 0 -.45 0 -.8 -.45 0 -.6
3 16 -1.75 0 0 -.45 0 -1 -.45 0 -.8
3 16 -1.75 0 0 0 0 -1.75 -.45 0 -1
3 16 0 0 -1.75 -.25 0 -1 -.45 0 -1
4 16 0 0 -1.75 .6 0 -1.25 .6 0 -1.15 -.25 0 -1
4 16 0 0 -1.75 1.237425 0 -1.237425 .94442 0 -1.18149 .6 0 -1.25
3 16 1.237425 0 -1.237425 1.2364 0 -.9864 .94442 0 -1.18149
3 16 1.237425 0 -1.237425 1.43149 0 -.69442 1.2364 0 -.9864
3 16 1.237425 0 -1.237425 1.75 0 0 1.43149 0 -.69442
3 16 1.75 0 0 1.5 0 -.35 1.43149 0 -.69442

Status

Official Official
This part has the following errors
  • Decimal precision exceeds 5 significant places
    Line 39: 3 16 1.75 0 0 1.237425 0 1.237425 1.35 0 .6
    Line 40: 4 16 0 0 1.75 1.15 0 .6 1.35 0 .6 1.237425 0 1.237425
    Line 51: 4 16 0 0 -1.75 1.237425 0 -1.237425 .94442 0 -1.18149 .6 0 -1.25
    Line 52: 3 16 1.237425 0 -1.237425 1.2364 0 -.9864 .94442 0 -1.18149
    Line 53: 3 16 1.237425 0 -1.237425 1.43149 0 -.69442 1.2364 0 -.9864
    Line 54: 3 16 1.237425 0 -1.237425 1.75 0 0 1.43149 0 -.69442
