File Detail parts/s/4113s01.dat

Unofficial File parts/s/4113s01.dat

~Electric Switch: Cover Female Plugs Front

File Header:

0 ~Electric Switch: Cover Female Plugs Front
0 Name: s\4113s01.dat
0 Author: Javier Orquera [kuramapika1]
0 !LDRAW_ORG Unofficial_Subpart
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2025-04-24 [kuramapika1] Reworked

Show contents

4 16 54.6 21.6 20 54.6 12.6 20 80 0 20 80 23 20
4 16 -5.6 21.6 20 25.6 21.6 20 80 23 20 -80 23 20
4 16 -54.6 12.6 20 -54.6 21.6 20 -80 23 20 -80 0 20
4 16 25.6 12.6 20 -5.6 12.6 20 -80 0 20 80 0 20
3 16 54.6 21.6 20 80 23 20 25.6 21.6 20
3 16 -54.6 21.6 20 -5.6 21.6 20 -80 23 20
3 16 -54.6 12.6 20 -80 0 20 -5.6 12.6 20
3 16 80 0 20 54.6 12.6 20 25.6 12.6 20
4 16 25.6 12.6 20 25.6 21.6 20 -5.6 21.6 20 -5.6 12.6 20
4 16 -54.6 21.6 18 -54.6 12.6 18 -78 2 18 -78 24.5 18
4 16 25.6 21.6 18 -5.6 21.6 18 -78 24.5 18 78 24.5 18
4 16 54.6 12.6 18 54.6 21.6 18 78 24.5 18 78 2 18
4 16 -5.6 12.6 18 25.6 12.6 18 78 2 18 -78 2 18
3 16 -54.6 21.6 18 -78 24.5 18 -5.6 21.6 18
3 16 54.6 21.6 18 25.6 21.6 18 78 24.5 18
3 16 54.6 12.6 18 78 2 18 25.6 12.6 18
3 16 -54.6 12.6 18 -5.6 12.6 18 -78 2 18
4 16 25.6 12.6 18 -5.6 12.6 18 -5.6 21.6 18 25.6 21.6 18
1 16 0 0 10 1 0 0 0 1 0 0 0 1 stug2-1x8.dat
1 16 0 0 -10 1 0 0 0 1 0 0 0 1 stug2-1x8.dat
1 16 0 23.75 -19 0 0 79 .75 0 0 0 38 0 box3u4a.dat
4 16 80 23 20 79 23 19 -79 23 19 -80 23 20
4 16 80 23 -20 79 23 -19 79 23 19 80 23 20
4 16 -80 23 20 -79 23 19 -79 23 -19 -80 23 -20
1 16 0 23 0 0 0 80 0 -23 0 20 0 0 box3u2p.dat
4 16 -79 24.5 -19 -79 24.5 19 -78 24.5 18 -78 24.5 -18
4 16 -78 24.5 18 -79 24.5 19 79 24.5 19 78 24.5 18
4 16 79 24.5 -19 78 24.5 -18 78 24.5 18 79 24.5 19
4 16 72 24.5 -18 78 24.5 -18 79 24.5 -19 72 24.5 -19
4 16 -78 24.5 -18 -72 24.5 -18 -72 24.5 -19 -79 24.5 -19
1 16 -75.5 23.75 -19 0 0 -3.5 -.75 0 0 0 1 0 rect.dat
4 16 -80 23 -20 -79 23 -19 -72 23 -19 -72 23 -20
4 16 -72 23 -20 -72 23 -19 -72 11 -18 -72 11 -20
4 16 -72 11 -18 -72 23 -19 -72 24.5 -19 -72 24.5 -18
4 16 -80 0 -20 -80 23 -20 -72 23 -20 -72 11 -20
3 16 -80 0 -20 -72 11 -20 -6 11 -20
1 16 75.5 23.75 -19 3.5 0 0 0 0 -.75 0 1 0 rect.dat
4 16 72 23 -19 79 23 -19 80 23 -20 72 23 -20
4 16 72 23 -20 72 11 -20 72 11 -18 72 23 -19
4 16 72 11 -18 72 24.5 -18 72 24.5 -19 72 23 -19
4 16 72 23 -20 80 23 -20 80 0 -20 72 11 -20
3 16 72 11 -20 80 0 -20 14 11 -20
1 16 78 13.25 0 0 1 0 0 0 -11.25 -18 0 0 rect.dat
4 16 78 2 -18 78 24.5 -18 72 24.5 -18 72 11 -18
3 16 78 2 -18 72 11 -18 14 11 -18
1 16 -78 13.25 0 0 -1 0 0 0 -11.25 18 0 0 rect.dat
4 16 -72 24.5 -18 -78 24.5 -18 -78 2 -18 -72 11 -18
3 16 -72 11 -18 -78 2 -18 -6 11 -18
4 16 14 11 -20 80 0 -20 -80 0 -20 -6 11 -20
4 16 -6 11 -18 -78 2 -18 78 2 -18 14 11 -18
1 16 4 17 -19.5 10 0 0 0 0 6 0 -0.5 0 box2-7.dat
1 16 4 23.75 -19 10 0 0 0 0 -.75 0 1 0 rect.dat
1 16 4 17.75 -18.5 10 0 0 0 6.75 0 0 0 0.5 box2-7.dat
4 16 -6 23 -20 -6 11 -20 -6 11 -18 -6 23 -19
4 16 -6 11 -18 -6 24.5 -18 -6 24.5 -19 -6 23 -19
4 16 14 11 -18 14 11 -20 14 23 -20 14 23 -19
4 16 14 24.5 -19 14 24.5 -18 14 11 -18 14 23 -19
4 16 72 11 -20 14 11 -20 14 11 -18 72 11 -18
4 16 -6 11 -18 -6 11 -20 -72 11 -20 -72 11 -18
2 24 -78 2 -18 78 2 -18
2 24 72 24.5 -18 72 24.5 -19
2 24 -72 11 -18 -72 24.5 -18
2 24 -72 24.5 -18 -78 24.5 -18
2 24 72 23 -20 80 23 -20
2 24 -72 24.5 -19 -72 24.5 -18
2 24 -72 23 -20 -80 23 -20
2 24 78 24.5 -18 72 24.5 -18
2 24 80 23 -20 80 0 -20
2 24 72 11 -18 72 24.5 -18
2 24 -80 23 20 80 23 20
2 24 -78 2 18 78 2 18
2 24 78 24.5 18 -78 24.5 18
2 24 72 23 -20 72 23 -19
2 24 72 11 -18 14 11 -18
2 24 72 11 -20 72 11 -18
2 24 -6 11 -20 -6 11 -18
2 24 -6 11 -20 -6 23 -20
2 24 -72 11 -20 -6 11 -20
2 24 -72 23 -19 -72 23 -20
2 24 -72 11 -20 -72 23 -20
2 24 -6 11 -18 -72 11 -18
2 24 72 11 -20 72 23 -20
2 24 14 11 -20 72 11 -20
2 24 14 11 -18 14 11 -20
2 24 14 23 -20 14 11 -20
2 24 -72 11 -18 -72 11 -20

Status:

Needs More Votes (N)

This part has the following automated holds from the Parts Tracker

No path of certified files to a certified or official parent in the parts folder

Current Votes:

None

Official parents and subparts

Part Events:

Javier Orquera [kuramapika1]

initially submitted the part.

2023-09-11 14:13:59

Magnus Forsberg [MagFors]

posted a vote of Hold.

2023-09-11 15:40:28

The cyli can't be in this file. Will create surface bleeding.
Maybe add the holes when they are needed, only keeping a square hole in this file, making it possible to block the hole with a single quad?

Javier Orquera [kuramapika1]

submitted a new version of the part.

2023-09-11 20:58:12

These is the best I can do.

Javier Orquera [kuramapika1]

submitted a new version of the part.

2023-09-12 00:34:54

Minior errors corrected.

Javier Orquera [kuramapika1]

submitted a new version of the part.

2024-10-12 18:37:12

Magnus Forsberg [MagFors]
