File Detail parts/4569.dat

Official File parts/4569.dat

Part Attributes:

External Sites:

View on Rebrickable View on BrickLink View on Brickset View on BrickOwl

File Header:

0 Slope Brick 10  6 x  1
0 Name: 4569.dat
0 Author: Magnus Forsberg [MagFors]
0 !LDRAW_ORG Part UPDATE 2023-07
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2023-12-31 [OrionP] Official Update 2023-07

Show contents

1 16 0 24 -20 0 0 6 0 -1 0 36 0 0 recte4.dat
1 16 0 16 37.5 -6 0 0 0 -1 0 0 0 17.5 recte3.dat
1 16 0 24 -20 0 0 10 0 -1 0 40 0 0 recte4.dat
1 16 0 16 40 -10 0 0 0 -1 0 0 0 20 recte3.dat
2 24 10 24 20 10 16 20
2 24 10 16 20 6 16 20
2 24 -10 24 20 -10 16 20
2 24 -6 16 20 -10 16 20
4 16 -6 24 -56 -10 24 -60 -10 24 20 -6 24 16
4 16 6 24 16 -6 24 16 -10 24 20 10 24 20
4 16 6 24 -56 6 24 16 10 24 20 10 24 -60
4 16 -6 24 -56 6 24 -56 10 24 -60 -10 24 -60
3 16 6 16 20 10 16 20 10 24 20
4 16 -6 16 20 6 16 20 10 24 20 -10 24 20
3 16 -10 24 20 -10 16 20 -6 16 20
4 16 -6 16 55 -6 16 20 -10 16 20 -10 16 60
4 16 6 16 55 -6 16 55 -10 16 60 10 16 60
4 16 6 16 55 10 16 60 10 16 20 6 16 20

0 // inside 1-2
1 16 0 6.717 38 -6 0 0 0 -1 -2.717 0 0 18 rect3.dat
4 16 6 16 20 6 9.434 20 6 4 56 6 16 55
1 16 0 10 55.5 0 0 -6 -6 1 0 .5 0 0 rect2p.dat
4 16 -6 16 20 -6 16 55 -6 4 56 -6 9.434 20
1 16 0 12.717 20 -6 0 0 0 0 -3.283 0 -1 0 rect3.dat

0 // inside 1-4
1 16 0 15 -17 -6 0 0 0 -1 -5 0 0 33 rect3.dat
3 16 6 24 -56 6 21 -56 6 20 -50
4 16 6 10 16 6 24 16 6 24 -56 6 20 -50
1 16 0 17 16 0 0 -6 -7 0 0 0 1 0 rect2p.dat
4 16 -6 10 16 -6 20 -50 -6 24 -56 -6 24 16
3 16 -6 20 -50 -6 21 -56 -6 24 -56
1 16 0 20 -50 6 0 0 0 -1 1 0 0 -6 2-4ndis.dat
1 16 0 20 -50 6 0 0 0 -1 1 0 0 -6 2-4edge.dat
1 16 0 20 -50 6 0 0 0 -1 0 0 0 -6 2-4edge.dat
0 BFC INVERTNEXT
1 16 0 20 -50 0 0 6 0 1 0 6 0 0 1-4cyls2.dat
0 BFC INVERTNEXT
1 16 0 20 -50 0 0 -6 0 1 0 6 0 0 1-4cyls2.dat
2 24 6 20 -50 -6 20 -50
2 24 6 21 -56 6 20 -50
2 24 -6 21 -56 -6 20 -50
1 16 0 20 -50 6 0 0 0 -1 0 0 0 -6 2-4chrd.dat
1 16 0 22.5 -56 -6 0 0 0 0 -1.5 0 -1 0 rect3.dat

0 // outside
1 16 0 9.5 0 0 0 -10 -9.5 1 0 60 0 0 recte4.dat
1 16 0 21.5 -60 0 0 10 2.5 0 0 0 1 0 rect2p.dat
1 16 0 8 60 0 0 -10 8 0 0 0 -1 0 rect2p.dat
3 16 10 16 20 10 16 60 10 0 60
4 16 10 0 60 10 19 -60 10 24 -60 10 16 20
3 16 10 16 20 10 24 -60 10 24 20
3 16 -10 0 60 -10 16 60 -10 16 20
4 16 -10 24 -60 -10 19 -60 -10 0 60 -10 16 20
3 16 -10 16 20 -10 24 20 -10 24 -60

0 // studholders
1 16 -6 15.8 45 0 0 1 0 10.4 0 1 0 0 ridgea.dat
1 16 6 15.8 45 0 0 -1 0 10.4 0 1 0 0 ridgea.dat
1 16 -6 15.8 35 0 0 1 0 8.9 0 1 0 0 ridgea.dat
1 16 6 15.8 35 0 0 -1 0 8.9 0 1 0 0 ridgea.dat
1 16 -6 15.8 25 0 0 1 0 7.4 0 1 0 0 ridgea.dat
1 16 6 15.8 25 0 0 -1 0 7.4 0 1 0 0 ridgea.dat

1 16 -6 23.8 5 0 0 1 0 12.4 0 1 0 0 ridgea.dat
1 16 6 23.8 5 0 0 -1 0 12.4 0 1 0 0 ridgea.dat
1 16 -6 23.8 -5 0 0 1 0 10.9 0 1 0 0 ridgea.dat
1 16 6 23.8 -5 0 0 -1 0 10.9 0 1 0 0 ridgea.dat
1 16 -6 23.8 -15 0 0 1 0 9.4 0 1 0 0 ridgea.dat
1 16 6 23.8 -15 0 0 -1 0 9.4 0 1 0 0 ridgea.dat
1 16 -6 23.8 -25 0 0 1 0 7.9 0 1 0 0 ridgea.dat
1 16 6 23.8 -25 0 0 -1 0 7.9 0 1 0 0 ridgea.dat
1 16 -6 23.8 -35 0 0 1 0 6.4 0 1 0 0 ridgea.dat
1 16 6 23.8 -35 0 0 -1 0 6.4 0 1 0 0 ridgea.dat
1 16 -6 23.8 -45 0 0 1 0 4.9 0 1 0 0 ridgea.dat
1 16 6 23.8 -45 0 0 -1 0 4.9 0 1 0 0 ridgea.dat

1 16 -6 5.660389 45 0 0 1 -.150933 1 0 1 0 0 ridgee.dat
1 16 6 5.660389 45 0 0 -1 -.150933 1 0 1 0 0 ridgee.dat
1 16 -6 7.169833 35 0 0 1 -.150933 1 0 1 0 0 ridgee.dat
1 16 6 7.169833 35 0 0 -1 -.150933 1 0 1 0 0 ridgee.dat
1 16 -6 8.679278 25 0 0 1 -.150933 1 0 1 0 0 ridgee.dat
1 16 6 8.679278 25 0 0 -1 -.150933 1 0 1 0 0 ridgee.dat

1 16 -6 11.666667 5 0 0 1 -.151515 1 0 1 0 0 ridgee.dat
1 16 6 11.666667 5 0 0 -1 -.151515 1 0 1 0 0 ridgee.dat
1 16 -6 13.181818 -5 0 0 1 -.151515 1 0 1 0 0 ridgee.dat
1 16 6 13.181818 -5 0 0 -1 -.151515 1 0 1 0 0 ridgee.dat
1 16 -6 14.69697 -15 0 0 1 -.151515 1 0 1 0 0 ridgee.dat
1 16 6 14.69697 -15 0 0 -1 -.151515 1 0 1 0 0 ridgee.dat
1 16 -6 16.212121 -25 0 0 1 -.151515 1 0 1 0 0 ridgee.dat
1 16 6 16.212121 -25 0 0 -1 -.151515 1 0 1 0 0 ridgee.dat
1 16 -6 17.727273 -35 0 0 1 -.151515 1 0 1 0 0 ridgee.dat
1 16 6 17.727273 -35 0 0 -1 -.151515 1 0 1 0 0 ridgee.dat
1 16 -6 19.242424 -45 0 0 1 -.151515 1 0 1 0 0 ridgee.dat
1 16 6 19.242424 -45 0 0 -1 -.151515 1 0 1 0 0 ridgee.dat

0 // top surface
4 16 -10 19 -60 10 19 -60 10 0 60 -10 0 60

Status:

Official

Unofficial parents

Part Events:

Archived Part Events:

Magnus Forsberg [MagFors]

initially submitted the part.

2023-10-06 20:40:49

https://www.newelementary.com/2023/09/lego-icons-new-moulds-review-10318.html#more

Franklin W. Cain [fwcain]

posted a vote of Certify.

2023-10-10 17:21:18
