File Detail parts/s/14769ps4s01.dat

Official File parts/s/14769ps4s01.dat

~Tile 2 x 2 Round with SW Dark Bluish Grey Imperial Pattern - Quarter

File Header:

0 ~Tile  2 x  2 Round with SW Dark Bluish Grey Imperial Pattern - Quarter
0 Name: s\14769ps4s01.dat
0 Author: Evert-Jan Boer [ejboer]
0 !LDRAW_ORG Subpart UPDATE 2024-04
0 !LICENSE Licensed under CC BY 4.0 : see CAreadme.txt

0 BFC CERTIFY CCW

0 !HISTORY 2024-05-28 [OrionP] Official Update 2024-04
